Model 504 5-section Couch
Models: 504E & 504H
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Medical 504 and is the answer not in the manual?

Questions and answers

Related Manuals for Plinth Medical 504

Summary of Contents for Plinth Medical 504

  • Page 1 Model 504 5-section Couch Models: 504E & 504H USER MANUAL...

  • Page 2: Table Of Contents

    7. Maintenance 8. Guarantee and Service 9. Technical Specification 10. Revisions to Manual Plinth Medical Ltd is an ISO Audited company to ISO9001:2008 Our products are CE marked in conformity with the EC Directive MDD 93/42/EEC P a g e...

  • Page 3: Introduction

    Model 504 User Manual Introduction Thank you for purchasing a product from Plinth Medical Ltd. We use the highest quality components and manufacturing techniques to ensure that our products are simple to use and will last a long time. It is recommended that all users read and retain this User Manual for reference.

  • Page 4: Installation

    Model 504 User Manual Installation Although this couch comes complete and is virtually ready to use it is important to remove all packaging and read the following before use. Retractable Castors The castors can be operated from either side of either end of the couch. Press the pedal down to engage the castors and lift the pedal to retract the castors.

  • Page 5: Power Supply

    Model 504 User Manual Power Supply (electric version only) Ensure that hand or foot switch leads are clear of the moving parts of the couch before operation. Connect the couch to a normal domestic type power supply observing the following notes. WARNING Ensure that the mains lead, plug and socket are in good condition before connecting the equipment.

  • Page 6: Electric Operation

    Model 504 User Manual Operation Plinth Medical offers 2 models of 504; 504E being the electric version and 504H being the hydraulic version. Electrical Operation General WARNING Safely position patient before operating any functions. Position the switch in a place where it is clear of the moving parts of the couch and where accidental operation is not possible.

  • Page 7: Manual Head & Foot Sections

    Model 504 User Manual Electrical Operation (foot) As an option this couch may be supplied with a foot switch to operate the electrical functions. It will operate in the same way as the hand switch but must be placed on the floor and operated by foot.

  • Page 8: Accessories Operation

    Model 504 User Manual NOTE – the castors are not designed for patient transport. Press the pedal down fully to operate the castors and lift the pedal to retract the castors. Castor WARNING Castors must be locked before the couch is used and whilst patients get on or off. Disconnect and coil electrical leads and switch away from the couch mechanism prior to moving the couch.

  • Page 9: Foot Switch (Single Motor)

    Model 504 User Manual For model 504E couches fitted with optional motorised back-rest and or motorised foot- rest the following hand switch is used. Height Back-rest Foot-rest Foot switch Operation (single motor) An optional fitment foot switch may be specified for the couch and the switch fitted will look similar to the one pictured below.
  • Page 10 Model 504 User Manual An optional fitment foot switch may be specified for the couch and for couches fitted with optional motorised back-rest and or foot-rest the switch fitted will look similar to the one pictured below. Height (up/down) Back-rest (up/down) Foot-rest (up/down) 10 | P a g e...

  • Page 11: Cleaning And Decontamination

    Model 504 User Manual Cleaning and Decontamination WARNING If contamination is suspected then decontaminate the couch before use. Torn or damaged upholstery should be replaced immediately. CAUTION Do not use Alkalis or other organic solvents for routine cleaning. Always cover the vinyl with paper towelling or couch covers if it can come into contact with bare skin.

  • Page 12: Troubleshooting

    Model 504 User Manual Troubleshooting In the unlikely event of the couch failing to operate and having carried out the normal practical fault finding steps below then please contact our Customer Service Team on +44 (0)1449 767887 or email customerservice@plinthMedical.com. Please have the serial number to hand before making contact so we can help you more efficiently.

  • Page 13: Maintenance

    Plinth products clean and regularly checked will assist in prolonging their working life. The following is a guide of simple checks that the user can carry out on a six monthly basis. We would also recommend an annual service visit by a Plinth Medical trained engineer.

  • Page 14: Guarantee And Service

    Model 504 User Manual Guarantee and Service (UK only) Plinth Medical Ltd offer a 5 year parts guarantee on all 500 Range products delivered from January 2013 and a lifetime frame guarantee. The only exclusion to this guarantee is for negligent damage or damage to upholstery coverings. This guarantee does not...

  • Page 15: Technical Specification

    Model 504 User Manual Technical Specifications 504H 504E (1 motor) 504E (2 motor) 504E (3 motor) Head Length (cm) 63 Seat Length (cm) Foot Length (cm) Width (cm) Overall Length (cm) Height Range 47-98 47-98 47-98 47-98 (cm) Max Working 250kg 250kg 250kg...

  • Page 16: Revisions To Manual

    Barric Lane Occold Suffolk IP23 7PX ENGLAND Plinth Medical Ltd In association with Plinth 2000 are an ISO Audited company to ISO9001:2008 Our products are CE marked in conformity with the EC Directive MDD 93/42/EEC 16 | P a g e...
