- Page 1 Summer Horizontal Dresser SKU WHIF2247 60 min. assembly 2 person C:\Users\Nur Salam\Downloads\TIME.png A S S E M B L Y I N S T R U C T I O N S * The estimated assembly time may vary depending on the individual.
-
Page 2: Tools Required
Hey,there Now is assembly time! Thank you for purchasing this LuxenHome product. This product has been manufactured with the Deeeeeep breathe..and again..highest standards of safety and quality. Tools ready, Easy peasy! PLEA E READ ALL IN TRU TION ARE ULLY E ORE A Unpack all parts from the packaging inside the... - Page 3 Furniture components: 1 Top Panel x1 2 Bottom Panel x1 3 Side Panel (L) x1 4 Side Panel (R) x1 5 Center Panel x1 6 Back Support Panel x1 7 Back Mdf Board (A) x1 Back Mdf Board (B) x1 9 Internal Support Panel x4 1st &...
- Page 4 Step 1 Bottom View : Top View : HARDWARE : Cam Pin x16 B Cam Lock x10 C Wood Dowel M8x30MM x10 COMPONENTS : 1 Top Panel x1 2 Bottom Panel x1 3 Side Panel (L) x1 Side Panel (R) x1 5 Center Panel x1 19 Leg Panel x2 Installation Minifix Screw:...
- Page 5 Step 2 HARDWARE : B Cam Lock x10 C Wood Dowel M8x30MM x24 D White Leg Pin x4 COMPONENTS : 6 Back Support Panel x1 9 Internal Support Panel x4 18 Long Front Leg Frame x1 19 Long Back Leg Frame x1 x4 Pcs x2 Pcs Installation Hardware:...
- Page 6 Step 4 Installation Screw: Please insert the screw H on panel using a allen key. HARDWARE : F Allen Key x1 H Screw M6x50MM x4 COMPONENTS : 2 Bottom Panel x1 Insert White Leg Pin: Press insert the white leg pin on the leg panel with using hammer.
- Page 7 Step 6 HARDWARE : Allen Key x1 COMPONENTS : 3 Side Panel (L) x1 4 Side Panel (R) x1 6 Back Support Panel x1 9 Internal Support Panel x4 Installation: As shown, the head of minifix housing goes into the open mouth of the mini fix bolt. Use Allen Key then turn the minifix housing so it tightens over the mini fix bolt.
- Page 8 Step 8 Installation: As shown, the head of minifix housing goes into the open mouth of the mini fix bolt. HARDWARE : Use Allen Key then turn the minifix housing F Allen Key x1 so it tightens over the mini fix bolt. Funiture Leg x1 I 2 Screw M3.5x16MM x4 COMPONENTS :...
- Page 9 Step 10 HARDWARE : J Screw M3.5x16MM x4 K Screw M4x32MM x2 Installation Screw: Please insert the screw J & K on panel using a screwdriver. Step 11 HARDWARE : L 1 Stub x4 L 2 Screw M4x20MM x4 Installation Screw: Please insert (L 1) inside the groove fasten it with screw (L 2) Please save this manual for future reference.
- Page 10 Step 12 HARDWARE : Ball Bearing 12"(LEFT)x6 Ball Bearing 12"(RIGHT)x6 Screw M3.5x16MM x36 Part A Part A Part A Part A Down Part B Part A Release the lock Part A iii) Step 1: Separate the Slide: Release the Lock: Inside the slide, locate a lock.
- Page 11 Step 13 x2 Sets x2 Sets HARDWARE : Screw M4x38MM x48 COMPONENTS : 10 1st & 2nd Drawer Face Panel (L) x2 11 3rd Drawer Face Panel (L) x1 1st & 2nd Drawer Face Panel (R) x2 3rd Drawer Face Panel (R) x1 14 Drawer Side Panel x12 15 Drawer Back Panel x6 16 Drawer Mdf Board x6...
- Page 12 Step 15 Insert the Drawer: * X-Ray view Please insert the drawer according the numbering. Please save this manual for future reference.
- Page 13 VOILA! Now enjoy. Warning !!! DO NOT climb,sit or stand on the dresser as this may damage the product and cause serious bodily injury. Please save this manual for future reference.
- Page 14 Something not right? We are always here to help. We make mistakes like every human does. Though we always strive to provide the best possible products at competitive prices and the best service in the industry, it’s not possible to completely eliminate mistakes. If you experience any dissatisfaction, feel free to contact us immediately.
- Page 15 Happy with our product? Leave us a review Share with others It really help us as a small business Our customers look for REAL stuff Find the product you purchased on · Follow us on IG @luxen.home our website (tip: search by SKU) ·...
