- Page 1 Instruction Manual DIN-CONNECT DIN-LINK to Rako Wired Network Connector 2025 Version 1.0.0...
-
Page 2: Table Of Contents
Contents 1.0 What is the DIN-CONNECT?..................... 3 1.1 Product Image......................3 1.2 Features of the DIN-CONNECT...................3 1.3 Example DIN Layout with the DIN-CONNECT............3 2.0 Installation..........................4 3.0 Terminating the DIN-CONNECT..................5 4.0 Troubleshooting the Rako Wired Network.................5 5.0 Wiring Examples........................ 6 5.1 Radial Wired System....................6 5.2 STAR Wired System......................7... -
Page 3: What Is The Din-Connect
RJ45 port for DIN-LINK connection Krone connector supporting up to two CAT5 connections or two CAT6 connections to the Rako Wired Network Work in both Radial and Star wiring arrangements on the Rako Wired Network Detailed wiring examples are available in 5.0 Wiring Examples. -
Page 4: Installation
Once all cables are fitted, use the cable ties provided to secure them to the base via the cable restraining points. Replace the cover of the DIN-CONNECT and screw on the lid. DIN-LINK Instruction Manual | Page 4 Manual Version 1.0.0... -
Page 5: Terminating The Din-Connect
The termination requirements depend on the nature of the installation and the position of the DIN-CONNECT within the system. No TERM - Both Jumpers removed When the DIN-CONNECT is not at the end of line. This is usually identifiable by two cables being punched down to the DIN-CONNECT. -
Page 6: Wiring Examples
5.0 Wiring Examples 5.1 Radial Wired System Connection & Termination Rules: ● End-of-Line Termination: The final device on each end of the radial must be set to the TERM position. ● Intermediate Devices: All other devices on the radial must be set to UN TERM. DIN-LINK Instruction Manual | Page 6 Manual Version 1.0.0... -
Page 7: Star Wired System
● Intermediate Devices: All other devices on a leg (between the RAK-STAR and the end-of-line device) must be set to UN TERM. 8.3 Systems with Multiple DIN-LINKs If the DIN system requires more than one DIN-LINK, they must be connected via the Rako Wired Network. DIN-LINK Instruction Manual | Page 7... - Page 8 ® Rako and the Rako logo are registered trademarks of Rako Controls Ltd. Unauthorised use of these trademarks is prohibited. All other product names, company names, and logos mentioned herein may be trademarks of their respective owners. DIN-LINK Instruction Manual | Page 8...
