- Page 1 INSTRUCTION MANUAL INSTRUCTION MANUAL QUIK SPRAY QUIK SPRAY 12 VOLT 12 VOLT REEL REEL QR100 QR100 info@quikcorp.com.au info@quikcorp.com.au 07 5493 8944 07 5493 8944 15 Research Street 15 Research Street www.quikspray.com.au www.quikspray.com.au 07 5493 8957 07 5493 8957 Coolum Beach QLD 4573 Coolum Beach QLD 4573...
- Page 2 Proudly Australian Owned and Operated info@quikcorp.com.au 07 5493 8944 15 Research Street www.quikspray.com.au 07 5493 8957 Coolum Beach QLD 4573...
- Page 3 Quik Spray QR Reel Manual Quik Spray QR Reel Manual KEY FEATURES BERTOLINI PUMPS e r i o i t y t i l o t i n i We have sourced only the best high quality parts to incorporate into our Quik Spray range. POWERED BY HONDA Every engine that sports the ‘Green and Gold Approved’Honda symbol has been “matched”...
- Page 4 As an Australian owned business your investment has enabled our every success. As a division of Quik Corp, our team have provided over three decades of high-quality agricultural products into the Australian market. From our humble beginnings in 1988, our product range has continually expanded and our innovation sparks from the passion and commitment we have for the agricultural industry.
- Page 5 Quik Spray QR Reel Manual Unpacking Your Unit Product Range Overview Pre-operation Checklist Operation Instructions 915 MHz Radio Receiver & Transmitter Tuning 915 MHz Transmitter Receiver Maintenance Troubleshooting Parts Diagrams – Wiring Schematic Warranty Policy...
-
Page 6: Unpacking Your Unit
Quik Spray QR Reel Manual Quik Spray QR Reel Manual MODEL QR100 WARNING THIS UNIT IS DESIGNED TO REWIND THE HOSE AND SHOULD NOT BE USED TO SUPPORT THE WEIGHT OF THE OPERATOR OR PULL OTHER EQUIPMENT WHEN RETRACTING. UNPACKING YOUR UNIT When unpacking your new Quik Spray unit, please check it thoroughly for any transport damage that may have occured during transit. - Page 7 Quik Spray QR Reel Manual Quik Spray QR Reel Manual WARNING PLEASE FOLLOW ALL WARNINGS AS FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY, PERMANENT INJURY OR DEATH DO NOT start the unit until you have read this manual carefully. DO NOT let any person near the unit while it is operating.
-
Page 8: Product Range Overview
Quik Spray QR Reel Manual Quik Spray QR Reel Manual PRODUCT RANGE OVERVIEW STAND ALONE REEL QR100 QR100 Reel Description T-400 spray gun (additional accessory) ON/OFF power switch for radio recevier and manual 915 MHz antenna aerial operation 3/8” ID Supa-Slip® hose (50 or 100m options) Hose roller head guide Aerial base Nozzle holder... - Page 9 Quik Spray QR Reel Manual Quik Spray QR Reel Manual STAND ALONE REEL QR100 QR100 Reel Interior Description 12V Motor Main receiver board power light 1x Anderson plug 50amp power in 915MHz receiver board function power light Resettable circuit breaker 40amp Radio receiver dip-switch code (This must match the Operation switch momentary on/off radio transmitter)
-
Page 10: Pre-Operation Checklist
Quik Spray QR Reel Manual Quik Spray QR Reel Manual PRE-OPERATION CHECKLIST Prior to operating your spray system, please read the following instructions carefully. Check all spray guns are connected and water tight. Reel drag adjustment bolt. Turn bolt clockwise for more drag when pulling the hose out in steep country. - Page 11 CAUTION Quik Spray QR Reel Manual Quik Spray QR Reel Manual Do not pull hose out too fast, as the reel may “run on”, causing the hose to become entangled. When you are ready to retract the hose, press and hold the transmitter button to retract the hose back to the unit. OPERATION INSTRUCTIONS CAUTION USING THE TRANSMITTER TO RETRACT HOSE...
- Page 12 Quik Spray QR Reel Manual Quik Spray QR Reel Manual 915 MHz RADIO RECEIVER & TRANSMITTER QR100 Reel Interior Description 915MHz radio receiver Full integrated 915 MHz receiver board with relay Main receiver board power light and pre-regulator board 915MHz receiver board function power light Radio receiver dip-switch code (This must match the radio transmitter)
- Page 13 CAUTION The working range of Quik Corp Radio transmitters can be affected by the many factors that typically affect all 915 MHz radio Transmissions. These include operating in the vicinity of high tension power lines, buildings and other obstructions.
-
Page 14: Maintenance
Quik Spray QR Reel Manual Quik Spray QR Reel Manual MAINTENANCE DAILY Check the battery condition, water level and voltage (12 volt). Make sure all safety guards and decals are in place. Inspect all nuts and bolts for missing or loose items. Check all hoses and hose fittings for damage or leaks. -
Page 15: Troubleshooting
Quik Spray QR Reel Manual Quik Spray QR Reel Manual TROUBLE SHOOTING PROBLEM PROBABLE CAUSE REMEDY Reel does not retract and ON\OFF switch not ON of faulty Switch ON or replace switch manual button does not work Discharged 12 volt battery Recharge battery Loose connection on 12 volt battery Fix losse connection... - Page 16 Quik Spray QR Reel Manual Quik Spray QR Reel Manual QR100 PARTS DIAGRAMS T-400 NOZZLE PARTS EXPLOSION...
- Page 17 CGA do not apply. To the fullest extent permitted by law in New Zealand, Quik Corp excludes any liability for any direct or indirect loss or “Product” means the goods or machinery that the Customer acquired, and which were manufactured by Quik Corp.
- Page 18 6.1. If the Product has been acquired for the purposes of a business, then pursuant to section 43(2) of the Consumer Guarantees Act 1993 (“CGA”) it is agreed that provisions of the CGA do not apply. To the fullest extent permitted by law in New Zealand, Quik Corp excludes any liability for any direct or indirect loss or damage of the provisions of the CGA do not apply.
-
Page 19: Your Notes
YOUR NOTES ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ __________________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ __________________________________ _________________________________________________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ ____________________________________________________________________ _______________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ ___ _______________________________________________________________________________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ ______________________________________ _____________________________________________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ ___________________________________________________________________________________________________ ________________________________________________________________________... - Page 20 WARRANTY PROCESS Please fill out form on our website at https://quikspray.com.au/warranty-claim-submission/ Before submitting a claim, please ensure the issue encountered is covered under our Warranty Policy, you can access this policy by clicking the link below. To complete the following form, you will need the following details at hand: •...
