BluArmor C20 Manual

WHAT'S IN THE BOX
THIS TOP LIST HIGHLIGHTED IN BLUE
ARE THE ESSENTIAL PARTS OF
THE C20 SYSTEM
SPEAKER
SPACERS
THIS BOTTOM LIST HIGHLIGHTED IN
GREEN ARE OPTIONAL MOUNTS,
MIC OR SPARES
KEY THINGS TO KNOW ABOUT YOUR C20
1. C20 box has a number of spares that you might need later. Keep them in a safe place.
2. THE USB-C to USB-C CLICKDOCK CABLE is a custom C20 cable and should NOT be used for charging the C20 or any
other electronic device.
3. The speaker must be positioned in the helmet to line up with your ear canal for optimum audio experience
4. For better control, we suggest using the C20 with the BluArmor App.
5. C20 auto-adjusts for your phone's audio level when the app connects for the first time (one-time calibration).
Music might distort at max volume if the app is not installed.
6. When you turn on RIDEGRID for the first time, the C20 starts in Two Rider Public Mode (Channel 1) and automatically
connects to the nearest C20 that is also in Two Rider Public Mode (Channel 1).
3 BUTTON
MODULE
CLICKDOCK
WINGMOUNT
CLICKDOCK
CABLE
CHARGING
CABLE
THIS SIDE
INTO C20,
MATCH PLUG
SHAPE WITH
SOCKET
THIS SIDE
INTO HARNESS
THIS CABLE SHOULD NOT
BE USED FOR CHARGING ANY
ELECTRONIC DEVICE
INSTALL THE APP TO
ACCESS ALL FEATURES
BUTTON
MIC
HARNESS
+
SPEAKERS
BOOM
MIC
NEED HELP?
WHATSAPP
+91 96067 18202
TURN SHEET FOR
INSTRUCTIONS
TOLL FREE
+91 95387 25827
