Linisher Installation Manual
808438 – AA362
812145 – AA482
Protect yourself and others by observing all safety information, warnings and cautions.
Failure to comply with instructions could result in personal injury and/or damage to product
or property.
Please retain instructions for future reference!
Abbott & Ashby AA362 / AA482 Linisher Installation Manual
1
Advertisement
Table of Contents
Related Manuals for ABBOTT & ASHBY AA482
Summary of Contents for ABBOTT & ASHBY AA482
- Page 1 Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. Please retain instructions for future reference! Abbott & Ashby AA362 / AA482 Linisher Installation Manual...
-
Page 2: Table Of Contents
6. Standards and Approvals ..................6 7. Technical Specifications..................7 8. Safety Instructions ....................8 9. Product pieces ..................... 8 10. Installation ......................9 11. Maintenance ......................13 12. Warranties – Terms and Conditions ..............14 Abbott & Ashby AA362 / AA482 Linisher Installation Manual... -
Page 3: Introduction
100 Grit 178mm (7”) diameter disc • 89mm (3.1/2”) contact wheel • Optional Abbott & Ashby Mitre Table (AAMT) accessory is also available • Linishing Attachment fully assembled out of the box Abbott & Ashby AA362 / AA482 Linisher Installation Manual... -
Page 4: Iso 7010 Symbols Used In This Manual
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock. Abbott & Ashby AA362 / AA482 Linisher Installation Manual... -
Page 5: Work Area
Power tools are dangerous in the hands of untrained users. e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tools Abbott & Ashby AA362 / AA482 Linisher Installation Manual... -
Page 6: Standards And Approvals
Ensure that the installation will comply with all applicable local regulations. 6. Standards and Approvals CTick – ACN002 123 337 Patent 2020902087 Pending Abbott & Ashby AA362 / AA482 Linisher Installation Manual... -
Page 7: Technical Specifications
Trade/factory bench grinder – Perfect for Abbott & Ashby Bench Grinders Belt – 1,220mm x 50mm (48" x 2") Disc – 178mm (7") Linishing surface Contact Wheel – 89mm (3 ½") Weight 6.5kg Abbott & Ashby AA362 / AA482 Linisher Installation Manual... -
Page 8: Safety Instructions
H) Drive Pulley C) Abrasive Disc I) 3 x 6x20mm fasteners for main bracket D) Backing Plate J) 16mm Nut E) 6 x Fasteners for backing plate K) Washer F) Linishing Guard Abbott & Ashby AA362 / AA482 Linisher Installation Manual... -
Page 9: Installation
(not pictured) to the shaft and then place the drive pully onto the shaft to ensure there is a snug fit. Place the washer (K) over the shaft onto the drive pulley Abbott & Ashby AA362 / AA482 Linisher Installation Manual... - Page 10 Install the backing plate (D) to the drive pulley with the 6 x fasteners (E) Attach the abrasive disc (C) to the backing plate. Hold firmly for a few seconds to ensure the adhesive activates. Abbott & Ashby AA362 / AA482 Linisher Installation Manual...
-
Page 11: Switching On And Off
Connect to the mains supply and press the rocker switch to the ON position (l). To stop the machine simply press the rocker switch to the OFF position (O). We also recommend the use of the E-Stop switch ATPED-ESTOP (sold separately) Abbott & Ashby AA362 / AA482 Linisher Installation Manual... - Page 12 If required you can lift the lever out of its seat to reset the lever turning position. Abbott & Ashby AA362 / AA482 Linisher Installation Manual...
-
Page 13: Maintenance
If visual and audible check immediately turn off the tools and contact a relevant repair agent to inspect and service Regularly check that all the fixing screw, nuts and bolts are tight. They may vibrate loose over time. Abbott & Ashby AA362 / AA482 Linisher Installation Manual... -
Page 14: Warranties - Terms And Conditions
White International Pty Ltd – Abbott & Ashby Linisher AA362 has a 3 Year Limited Product Warranty not including abrasives White International Pty Ltd – Abbott & Ashby Linisher AA482 has a 3 Year Limited Product Warranty not including abrasives... - Page 15 This page has been left intentionally blank Abbott & Ashby AA362 / AA482 Linisher Installation Manual...
- Page 16 For any queries regarding use of the contained information please feel free to contact White International Pty Ltd. Abbott & Ashby AA362 / AA482 Linisher Installation Manual...
