HT902SB-R1.NA1ULL7_ENG_5848
© Copyright 2007, LG Electronics U.S.A., Inc.
DVD RECEIVER
OWNER'S MANUAL
MODEL: LHT754
Main Unit - LHT754
Speakers - SH92SB-S
Before connecting, operating or adjusting this product, please
read this instruction booklet carefully and completely.
SH92SB-C
SH92SB-W
R
For service/
support Call:
Toll Free Number
1-800-243-0000
(http://us.lgservice.com)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SH92SB-S and is the answer not in the manual?

Questions and answers

Related Manuals for LG SH92SB-S

Summary of Contents for LG SH92SB-S

  • Page 1 Main Unit - LHT754 Speakers - SH92SB-S SH92SB-C SH92SB-W Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely. For service/ support Call: Toll Free Number 1-800-243-0000 (http://us.lgservice.com) © Copyright 2007, LG Electronics U.S.A., Inc.
  • Page 2 FCC COMPLIANCE: The responsible party for this product’s compliance is: CAUTION: The apparatus should not be exposed to water Marketed and Distributed by LG Electronics U.S.A., Inc., (dripping or splashing) and no objects filled with liquids, such 1000 Sylvan Avenue, Englewood Cliffs, NJ.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL. AND THOSE MARKED ON THE PRODUCT. RETAIN THIS MANUAL FOR FUTURE REFERENCE. This product has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard.

  • Page 4: Table Of Contents

    Troubleshooting .....30-31 SIMPLINK function. • LG TV with SIMPLINK function has the logo as Specifications ......32...

  • Page 5: Before Use

    Introduction Before use Types of Playable Discs To ensure proper use of this product, please read this (8 cm / 12 cm disc) owner’s manual carefully and retain it for future reference. Audio CD (8 cm / 12 cm disc) This manual provides information on the operation In addition, this unit can play a DVD±R, DVD±RW, and maintenance of your DVD/CD Receiver.

  • Page 6: Front Panel/Rear Panel

    Front Panel/Rear Panel POWER DISC Tray DISPLAY Window VOLUME controller TUNING(-/+)/SKIP/ Remote Sensor . /> > ) SEARCH(. STOP (x) AUDIO IN connector PAUSE ( X X )/ MONO/STEREO (ST.) USB port FUNC.(-)/PLAY(B) Connect to a USB port of a memory Press and hold down this button device (USB memory etc.) about 3 seconds, then press...

  • Page 7: Remote Control

    Remote Control OPEN/CLOSE (Z Z ) POWER Opens and closes the disc tray. TUNER Selects the System’s tuner (FM ,AM and TUNER OPEN/CLOSE Selects the output source (CD/DVD). POWER XM bands). iPod Selects the iPod source. Selects input source. S-TITLE iPod Selects a subtitle language (DVD).

  • Page 8: Installation And Setup

    Installation and Setup TV Connection Make one of the following connections, depending on Video connection the capabilities of your existing equipment. Connect the MONITOR OUT jack from the DVD/CD Receiver to the VIDEO IN jack on the TV using the Tips: video cable (V).

  • Page 9: Optional Equipment Connection

    Optional Equipment Connection OPTICAL IN connection (O) Auxiliary device Connect an optical output of DVD Player (or Digital DVD Player (or Digital Device etc) to the OPTICAL IN connector. Device, etc) VIDEO AUDIO IN connection (D) AUDIO (L) AUDIO (R) Connect a output of portable device (MP3 or PMP etc) OPTICAL To AUDIO OUT (L/R)

  • Page 10: Antenna Connection

    Antenna Connection Speaker System Connection Connect the speakers using the supplied speaker Connect the supplied FM/AM antenna for listening to wires. the radio. To obtain the best possible surround sound, adjust the Connect the AM Loop antenna to the AM antenna speaker parameters (volume, distance, etc.).

  • Page 11: Hdmi Connection

    HDMI Connection Rear of DVD/CD Receiver About HDMI HDMI (High Definition Multimedia Interface) supports INPUT MONITOR L - AUX - R both video and audio on a single digital connection for an HDMI OUT HDMI OUT XM IN easy all- digital output to an HDMI or DI-equipped TV. COMPONENT VIDEO (PROGRESSIVE SCAN) i Pod Connection to an HDMI TV requires an HDMI cable...

  • Page 12: Displaying Disc Information On-Screen

    Displaying Disc Information LANGUAGE On - screen LANGUAGE You can display various information about the disc English Disc Audio Original loaded on-screen. Disc Subtitle Disc Menu Original 1. Press DISPLAY to show various playback information. The displayed items differ depending on the disc type or playing status.

  • Page 13: Audio

    AUDIO 5.1 Speaker Setup Make the following settings for the built-in 5.1 channel Each DVD disc has a variety of audio output options. surround decoder. Set the receiver’s AUDIO options according to the type of audio system you use. 1. Press ENTER, and the 5.1 Speaker Setup menu appears.

  • Page 14: Lock (Parental Control)

    LOCK (Parental Control) OTHERS OTHERS LOCK Select DivX(R) Registration Rating Unlock Password **** Area Code Move Select Move Select Rating DivX(R) Registration Blocks playback of rated DVDs based on their ® We provide you the DivX VOD (Video On Demand) contents.

  • Page 15: Operation

    Operation General features Buttons Operations Discs Z (OPEN / CLOSE) Opens or closes the disc tray. X (PAUSE) During playback, press X to pause playback. Press X repeatedly to play Frame-by-Frame. DivX SKIP (. / >) During playback, press SKIP (. or >) to go to the next chapter/track or to return to the beginning of the current chapter/track.

  • Page 16: Additional Features

    Screen Saver Notes on general features: Zoom may not work on some DVDs. The screen saver appears when you leave the unit in Stop mode for about five minutes. The A-B repeat function is available only in the current title. Last Scene Memory This receiver memorizes the last scene from the last Additional features...

  • Page 17: Playing An Audio Cd Or Mp3/Wma File

    Playing an Audio CD or Programmed Playback MP3/WMA file The program function enables you to store your favorite tracks from any disc in the receiver memory. A This unit can play Audio CDs or MP3/WMA files. program can contain 300 tracks. MP3/ WMA/ Audio CD 1.

  • Page 18: Viewing A Jpeg File

    Viewing a JPEG file JPEG JPEG disc compatibility with this player is limited as follows: This unit can play discs with JPEG files. • Depending upon the size and the number of Before playing JPEG recordings, read the notes on JPEG files, it could take a long time for the JPEG Recordings on the right.

  • Page 19: Playing A Divx Movie File

    Playing a DivX Movie file DivX disc compatibility with this player is limited as follows: Using this DVD/CD Receiver you can play DivX disc. • Available resolution size of the DivX file is under 1. Insert a disc and close the tray. The MOVIE menu 800x600 (W x H) pixel.

  • Page 20: Using Ipod

    Using iPod Notes: You can enjoy playback of your iPod using the • It works with all iPod models that have a dock supplied remote control. connector. iPod is a trademark of Apple Computer, Inc, registered • Compatibility with your iPod may vary depending in the U.S.
  • Page 21 Playing the iPod in the OSD iPod iPod message mode When you connect the unit and Remote iPod You can operate your iPod by controlling OSD menu TV to COMPONENT VIDEO Please use Monitor output for viewing Video and photo on the TV screen with the supplied remote control.

  • Page 22: Dvd Audio Discs

    DVD Audio Discs Moving to another GROUP Some DVD Audio discs divide content into different DVD Audio is a new disc format building on the groups. Your player enables you to quickly access success of DVD to provide high quality, different groups during playback via the on-screen uncompressed, multi-channel audio for a new display.

  • Page 23: Presetting The Radio Stations

    Presetting the Radio Stations Listening to the Radio You can preset 50 stations for FM and AM (MW). Preset radio stations in the DVD/CD Receiver’s Before tuning, make sure that you have turned down memory first (see “Presetting radio stations” on the the volume.

  • Page 24: Sleep Timer Setting

    The SLEEP indicator and the sleep time appears in the display window. XTS-P ON The unique sound quality of the LG Technology 2. Each time you press SLEEP the setting creates the optimum sound for you to play the changes in the following order.

  • Page 25: Xm Satellite Radio Operation

    XM Satellite Radio Operation Activating Your Service A one-time activation fee is required to establish an What is XM Satellite Radio? account and activate service with XM Satellite Radio. Applicable activation changers will be added to your XM Radio is the satellite radio service with millions of first bill.
  • Page 26 Category search mode is released below case. Presetting the XM Satellite Radio Stations CAT is inputted in Category search mode. • You can preset 50 stations for XM. Before tuning, No input of PRESET (-/+), XM CH - or XM CH + key make sure that you have turned down the volume.

  • Page 27: Controlling Your Tv With The Suppllied Remote Control

    Supplied Remote Control MUTE You can control the sound level, input source, and power switch of non-LG TVs as well. If your TV is listed in the table below, set the appropriate manufacturer code. (refer to page 28) 1. While holding down TV POWER button, press the CAT/HDMI XM MODE/RESOL.
  • Page 28 SHARP 09,22,23,24,60,66 HITACHI 09,14,15,43 SIGNATURE 2000 01,06,08,09,10, JC PENNEY 01,08,10,27,35 23,24,33,34 20,21,63,67 SONY 12,62 KIOTE SOUNDESIGN SYLVANIA 01,04,05,06,07, 01,08,09,31 08,35,51 LG (GOLDSTAR) 01,07,08,09,35,39,40 SYMPHONIC 46,47 LODGENET TATUNG LOGIK TEKNIKA 07,09,16,33,51 09,24,25,26,27,28,29 TELERENT 09,33 MAGNAVOX 01,02,04,05,06, THOMSON 07,08,09,20, YORX 34,35,43,51,61,62,65 TOSHIBA...

  • Page 29: Reference

    Reference Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Abkhazian 6566 Fiji 7074 Lingala 7678 Singhalese 8373 Afar 6565 Finnish 7073 Lithuanian...

  • Page 30: Troubleshooting

    Troubleshooting Check the following guide for the possible cause of a problem before contacting service. Correction Symptom Cause • Plug the power cord securely into the • The power cord is disconnected. No power. wall outlet. • Insert a disc. (Check that the DVD or, •...
  • Page 31 Cause Correction Symptom • The antenna is positioned or connected Radio stations cannot • Connect the antenna securely. poorly. be tuned in. • Adjust the antennas and connect an external antenna if necessary. • The signal strength of the stations is too •...

  • Page 32: Specifications

    Subwoofer*: 225 W (3Ω at 30 Hz, THD 10 %) Inputs AUDIO IN, OPTICAL IN Outputs MONITOR OUT, HDMI OUT, COMPONENT VIDEO OUT Front/Rear Speaker Center speaker Passive Subwoofer (SH92SB-S) (SH92SB-C) (SH92SB-W) Type 1 Way 1 Speaker 2 Way 3 Speaker 1 Way 1 Speaker 4 Ω 4 Ω...
  • Page 33 Limited Warranty - USA This LG Electronics product, will be repaired or replaced, at LG’s option, if it proves to be defective in material or workmanship, under normal use, during the warranty period (“Warranty Period”) listed below, effective from the date (“Date of Purchase”) of original consumer purchase of the product.
