JOLT JLR90R Instructions

1. Contact Probes
2. LED Flashlight
3. Function Select Switch
(Stun/Light/Off)
4. Charging Port
5. Stun ON/OFF Switch
6. Charging Indicator Light
7. Stun Activation Button
1
2
CHARGING
1. The rechargeable batteries are already installed. Please do not attempt to open the unit, as this will void
the warranty.
2. We recommend charging the Lightning Rod before it is used. Simply plug the charging cord into the bottom
of the unit and into a standard outlet. The red light on the bottom of the unit will illuminate while the
charging cord is plugged in. Note that the red light does not turn off or change color when fully charged.
Simply charge for 5 hours then unplug it from the charging cord. IMPORTANT: Do not charge for more
than 8 hours at a time. Overcharging can damage the unit and void the warranty. When used infrequently
the unit will need to be recharged for 5 hours every 60 days. If the flashlight is not as bright or if the
electrical current becomes noticeably weaker, the unit will need to be recharged.
USING THE FLASHLIGHT
Note: The flashlight will work with the Stun ON/OFF Switch in either the ON or OFF position. If you are in a
situation where you might need to quickly activate the stun gun (like walking at night) we recommend you use
the ON position. If you don't anticipate needing the stun gun (at home during a power outage) we recommend
the OFF position.
1. Slide the Function Select Switch up to the middle position.
2. The flashlight will come on either: Hi, Low, or Strobe Mode.
3. If you want to change to another light mode move the Switch down to the bottom position, then back up to
the middle position.
TESTING THE STUN GUN
We recommend test firing the stun gun and becoming familiar with its operation before you need to use it to
defend yourself. WARNING: Do not test fire the stun gun for more than 1 second as this will damage the unit and
void the warranty.
1. Slide the ON/OFF switch (located on the bottom of the unit) to the ON position.
2. Slide the Function Select Switch up to the top position.
JLR90R Lightning Rod
Instructions
7
3
4
5
6
Revised 12/20/2018
