- Page 1 XAG XRTK6 Pro Ground Module User Manual Version 1.0...
- Page 2 To User Dear user, thank you for choosing XAG's products. For safety purposes and better user experience, it is highly recommended that you read this manual carefully and strictly follow the instructions hereof. Contact Us Manufacturer: Guangzhou Xaircraft Technology Co., Ltd.
-
Page 3: List Of Items
Introduction XAG XRTK6 Pro Ground Module (hereinafter referred to as "XRTK6 Pro") is a next-generation rover featuring Mark-to-Map and Portable Base Station Setup. With its stable transmission signals, it effortlessly handles various scenarios, making it a precise and efficient tool for agricultural tasks. - Page 4 Overview ① ⑥ ② ⑦ ③ ⑧ ⑨ ④ ⑩ ⑫ ⑤ ⑪ ⑬ ⑭ ① RTK Antenna ⑧ Portable Base Station Mode Indicator ② Connection Status Indicator ⑨ Mode Switching Button ③ Power indicator ⑩ Power Button ④ Undo Marking Button ⑪...
- Page 5 Indicator Indicators tell you the status of XRTK6 Pro when it is on. Battery Level Indicator Description Solid Green Battery level 51%-100% Solid Yellow Battery level 21%-50% Solid Red Battery level 1%-20% Description Connection Status Indicator Mapping Mode Solid Green...
-
Page 6: Before Use
Before Use Charge Plug the Type-C end of the cable into the charging port of the XRTK6 Pro and the USB end into the adapter, then connect to a power source. When charging the XRTK6 Pro with the fast charging adapter, the power indicator blinks fast, accompanied by two beeps from the buzzer. -
Page 7: How To Use
Add XRTK6 Pro To use XRTK6 Pro to mark points and map a field, or to set up a portable base station, you can add XRTK6 Pro to XAG One as follows. 1. After XRTK6 Pro is turned on, open the XAG One, tap the icon in the upper right corner, and select "Add a Device". - Page 8 ② Hold the XRTK6 Pro and move to the boundary of the field that needs mapping. Short press to mark the boundary points of the field. After marking all the boundary points, tap on the "Auto Close" in the app or long press , and the system will automatically generate the field.
- Page 9 XRTK6 Pro being obstructed, which may cause communication signal interruption. In mapping mode, if the tilt angle of the XRTK6 Pro exceeds 50° , the mapping mode indicator light will flash green rapidly. Please adjust the angle promptly to avoid affecting its normal use.
- Page 10 When mounting the XRTK6 Pro on the tripod, ensure it is placed vertically to the horizontal plane. [1]: The tripod is not included in the XRTK6 Pro's list of items. The tripod model shown in the user manual is for reference only. Actual installation should be based on the physical product.
- Page 11 RTK positioning is divided into two modes: "Cloud RTK" and "CORS". Cloud RTK refers to connecting to the XAG Cloud Base Station to obtain high-precision coordinates, while CORS refers to obtaining coordinates using a third-party CORS account.
-
Page 12: Specifications
Galileo: E1, E5a, E5b Positioning Accuracy Horizontal: ＜5 cm+1 ppm (RMS) (Good RTK Signal) Vertical : ＜7.5 cm+1 ppm (RMS) [1]: A drop in the XRTK6 Pro's battery performance may occur when the operating ambient temperature is below -5℃ . www.xa.com/en... -
Page 13: Compliance Information
Compliance Information FCC Compliance Notice Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 14 Warning:Operation of this equipment in a residential environment could cause radio interference. NB Warning Message “Hereby, [Guangzhou Xaircraft Technology CO.,LTD.], declares that this [XAG XRTK6 Pro Ground Module] is in compliance with the essential requirements and other relevant provisions of 2014/53/EU.
- Page 15 NCC Statement 取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均不得擅自變更頻率、加大功率或 變更原設計之特性及功能。低功率射頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾 現象時，應立即停用，並改善至無干擾時方得繼續使用。前述合法通信，指依電信管理法規定作業之 無線電通信。低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 Without permission granted by the NCC, any company, enterprise, or user is not allowed to change frequency, enhance transmitting power or alter original characteristic as well as perfor- mance to a approved low power radio-frequency devices. The low power radio-frequency devic- es shall not influence aircraft security and interfere legal communications;...
- Page 16 5. To the maximum extent permitted by law, XAG shall not be liable for any losses caused by the user's improper operation. In addition, XAG shall not be liable for any indirect,...
- Page 17 Safety awareness is of great importance during operation. Do NOT use the parts that are not provided or suggested by XAG. Please install and use the product in strict accordance with XAG's instructions. www.xa.com/en...
- Page 18 @XAGofficial @xag_official @XAG Official This User Manual is subject to update without prior notice. ©Guangzhou Xaircraft Technology Co., Ltd. All Rights Reserved. All information in this User Manual (including but not limited to any text description, illustrations, photos, methods, processes, etc.) belongs to Guangzhou Xaircraft Technology Co., Ltd. and is protected by copyright law.
