Page 1 2D Bluetooth Scanner User Guide v3.0 For P303BT, P135BT, P50BT Scanners...
Page 2 Please read through the manual carefully before using the product and operate it according to the manual. It is advised that you should keep this manual for future reference. Do not disassemble the device or remove the seal label from the device. Otherwise, Element Ltd. Does not assume responsibility for the warranty or replacement.
Page 3: Revision History
Revision History Revision Issue Data Description V1.0 2020/3/1 Initial release. V2.0 2022/11/10 Add FAQ. V3.0 2024/5/29 Add data formatting.
Page 4: Table Of Contents
Table of Contents Disclaimer ............................... 2 Revision History ............................3 Preface ..............................1 Chapter 1 Product Overview ........................3 Introduction ..................................3 Products .................................... 3 User Scenario ................................... 3 Installation Instruction ..............................3 Prepare the scanner ..............................3 Connecting the scanner to the host ........................4 Use of products ................................
Page 5 Reread Delay .................................. 28 Illumination ..................................28 On/Off ..................................28 Illumination Level - Trigger Mode ........................29 Illumination Level - Presentation Mode ......................30 Aiming ..................................... 32 Auto-Sense ..................................33 Good Read Vibration ..............................33 Good Read Beeper ................................. 34 On/Off ..................................
Page 6 Hanxin ..................................77 Postal Code ..................................78 China Postal Code ..............................78 Telepen ..................................78 Chapter 6 Data Formatter .........................80 Introduction ................................... 80 Add a Data Format ..............................80 Change Data Format for Single Scan ........................81 Clear All Data Formats ............................82 Data Formatting ................................
Page 7 AIM ID ................................... 114 Code ID..................................116 Terminal ID ................................... 116 Unicode Key Maps ............................... 117 Key Modifiers ................................117...
Page 8: Preface
Preface About This Manual This manual mainly provides the function introduction and settings of the Element 2D Bluetooth Scanner of Element Ltd. by scanning the programming barcode, the users can change the parameter settings of the products. Chapter Outline Chapter1 Product Overview : Introduce products’...
Page 9: Disclaimer
Tools Download The users can download the driver, Config Utility, user guide by visiting the website www.elementpos.co Programming Barcode ① 0E01000. ② Trigger Mode ③ The Trigger Mode Barcode ① The Trigger Mode Command ② The description of the feature, * indicates factory defaults settings. ③...
Page 10: Chapter 1 Product Overview
Powered by area-imaging technology and Element 2D Barcoder Reader patented “Hercules” technology, the Element 2D Barcoder Reader features fast scanning and decoding accuracy. Barcodes rotated at any angle can still be read with ease. When scanning a barcode, simply center the aiming beam or pattern projected by the Element 2D Barcoder Reader over the barcode.
Page 11: Connecting The Scanner To The Host
Step2: Restore the Bluetooth scanner to factory Settings. Restore All Factory Defaults Connecting the scanner to the host Generally, there are three ways to connect the Element 2D Bluetooth Scanner, Connect by searching for product’s Connect with Cradle Connect with Dongle.
Page 12 1. The scanner will be discoverable in 120s. the user needs to scan the Bluetooth Keyboard again after more than 120 seconds. 2. In this way, the scanner can automatically reconnect to the current host device after it reboot. Connect with Cradle For PC, POS users, you can choose a USB or RS-232 cable to connect the cradle to the host.
Page 13: Use Of Products
Connect with Dongle For PC, POS users Step1: Plug the Element USB Dongle into your PC. Step2: Scan the address barcode on the Dongle. Waiting for the connection to be established, the LED on the Dongle will turn blue when the connect is complete.
Page 14 Connect with Cradle/Dongle 1. When the scanner is connected to the host with Dongle or Cradle via USB cable, there are three communication methods. a. Cradle/Dongle USB HID-KB Step1: Scan the programming barcode Cradle/Dongle USB HID-KB. Step2: Open a notepad, put the cursor in the blank. Step3: Press and hold the trigger.
Page 15: Power Off
If the barcode is decoded successfully, the scanner will emit a good read beep and the decoded data will be displayed in the POS tool; if it cannot be decoded, the scanner will release the trigger after 30 second, the illumination and aiming will go off, and the scanning will stop. 2.
Page 16: Query The Product Information
Query The Product Information Display The Cradle/Dongle Version Scanning the programming barcode below can display the version of the Cradle or Dongle. Display The Cradle/Dongle Version Display The Bluetooth Hardware Version Scanning the programming barcode below can display the Bluetooth hardware version. Display The Bluetooth Hardware Version Display The Decoder Version Scanning the programming barcode below can display the firmware version of the decoder.
Page 17: Display The Battery Level
Display The Battery Level Scanning the programming barcode below can display the battery level. Display The Battery Level...
Page 18: Chapter 2 Bluetooth Settings
Chapter 2 Bluetooth Settings Bluetooth Scanner Factory Defaults Scan the programming barcode below can restore the scanner to the factory defaults. Restore All Factory Defaults (Scanner) Please use this feature with discretion. Bluetooth Keyboard Bluetooth Keyboard Bluetooth Serial Port Bluetooth Serial Port...
Page 19: Cradle/Dongle Settings
Cradle/Dongle Settings Factory Defaults Scan the programming barcode below can restore the Cradle or Dongle to the factory defaults. Restore All Factory Defaults (Cradle/Dongle) Please use this feature with discretion. Cradle/Dongle USB HID-KB When you connect cradle to the host, you can enable the Cradle/Dongle USB HID-KB by scanning the programming barcode below.
Page 20: Cradle Usb Hid-Pos
Cradle USB HID-POS When you connect cradle to the host and want to use the scanner on the POS, you can scan the programming barcode below to switch. Cradle USB HID-POS RS-232 Communication When the cradle uses the RS-232 communication interface, the communication parameters between the cradle and the host must be fully matched to ensure that the communication and output are correct.
Page 21 9600 19200 38400 57600 115200 Data Bit & Parity, Check & Stop Bit None Parity/8 Data Bits/1 Stop Bit...
Page 22 None Parity/7 Data Bits/1 Stop Bit None Parity/7 Data Bits/2 Stop Bits Even Parity/8 Data Bits/1 Stop Bit Even Parity/7 Data Bits/1 Stop Bit Even Parity/7 Data Bits/2 Stop Bits Odd Parity/8 Data Bits/1 Stop Bit Odd Parity/7 Data Bits/1 Stop Bit Odd Parity/7 Data Bits/2 Stop Bits Some products only support None Parity/8 Data Bits/1 Stop Bit.
Page 23: Standby Time
Standby Time The scanner will power off if no operation is done within the standby time. 10min 30min Never Power Off Keyboard Type USB HID (Windows/Android) USB HID (Mac/iOS)
Page 24: Input Method
Input Method Switch Input Method (Android/Windows) Switch Input Method (iOS/Windows) iOS Popup/Hide Virtual Keyboard When the scanner is connected to the iPhone, user can popup or hide the iOS keyboard by scanning the programming barcode below. iOS Popup/Hide Virtual Keyboard Convert Case Convert all to upper case: All letters in the barcode data are converted to uppercase letters regardless of whether they are uppercase or lowercase.
Page 25: Country Keyboard Types
No Case Conversion Convert All to Upper Case Convert All to Lower Case This feature is not affected by CapsLock. Country Keyboard Types Keyboard layouts vary from country to country. The default setting is U.S. Keyboard. There are two ways to convert the country keyboard types.
Page 26 Finnish_Swedish French German Italian Swiss_German British Danish...
Page 27 Novwegian Spanish Method 2 When the scanner is connected to the Cradle or Dongle, scan the programming barcode below to change this layout. Belgian Finnish_Swedish French...
Page 28 German Italian Swiss_German British Danish Novwegian Spanish Work for Cradle/Dongle USB HID-KB.
Page 29: Transmission Rate
Transmission Rate When the scanner is connected to the host by searching for product’s SN, scan the programming barcode below to set the transmission rate. Slow Medium High When the scanner is connected to the host with the dongle cradle via USB cable, scan the programming barcode below to set the transmission rate.
Page 30: Transmission Mode
Transmission Mode Bluetooth scanner supports three transmission modes: Synchronous Transmission Mode, Asynchronous Transmission Mode, Batch Storage Mode. when Bluetooth is connected when Bluetooth is disconnected Transmission Mode Transmission Storage Transmission Storage Synchronous √ × × × Transmission Mode Asynchronous √ ×...
Page 31: Batch Storage Mode
Batch Storage Mode Data is stored when Bluetooth is connected and not when disconnected. Batch Storage Mode Count the total number of stored data You can scan the programming barcode below to query the total number of stored data. Count the total number of stored data Upload Method Upload all data at once Step1: Open the text editor on the host.
Page 32: Clear All Stored Data
Upload data one by one in sequence Step1: Open the text editor on the host Step2: Scan the Upload the next data programming barcode to upload the first data from the initial transmission location, scan the programming barcode again to upload the next data. Upload the next data Upload the last data If the users forget which data was uploaded, scan the programming barcode below to restore the initial transmission...
Page 33: Chapter 3 System Settings
Chapter 3 System Settings Scan Mode Trigger Mode If the Trigger Mode is enabled, you could activate the scanner by pressing an external button. When the external button is pressed, the scanner will continue scanning until the decoding is successful or the external key is manually released.
Page 34: Good Read Delay
Presentation Mode - Continue Scan The scanner automatically starts one decode session after another. To suspend/resume barcode reading, simply press the trigger. Reread Timeout can avoid undesired rereading of same barcode in a given period of time. Presentation Mode - Continue Scan In this scan mode, enable reread delay can avoid undesired rereading of same barcode in a given period of time.
Page 35: Reread Delay
Reread Delay Reread delay can avoid undesired rereading of same barcode in a given period of time. This feature is only applicable to the presentation mode (Normal and Continue scan). Delay 500 ms Delay 750 ms Delay 1000 ms Illumination On/Off Illumination On Illumination Off...
Page 36: Illumination Level - Trigger Mode
Illumination Level - Trigger Mode The higher the illumination level, the brighter the illumination. For different series of products, the lighting level of the manual trigger mode is set differently. Illumination mode 1 Level-4 Level-3 Level-2 Level-1 Illumination Mode 2 Level-4...
Page 37: Illumination Level - Presentation Mode
Level-3 Level-2 Level-1 Some products due to hardware limitations, lighting level 1, 2, 3 do not make a difference. Illumination Level - Presentation Mode The higher the illumination level, the brighter the illumination. For different series of products, the lighting level of the presentation mode is set differently. Illumination Mode1 Level-4 Level-3...
Page 38 Level-2 Level-1 Illumination Mode 2 Level-4 Level-3 Level-2 Level-1 Some products due to hardware limitations, lighting level 1, 2, 3 do not make a difference.
Page 39: Aiming
Aiming When scanning or capturing images in the trigger mode, the scanner projects an aiming pattern which allows positioning the target barcode within its field of view and thus makes decoding easier.  OFF: Aiming pattern is off all the time ...
Page 40: Auto-Sense
Auto-Sense When the Auto-Sense is enabled and the scanner is placed on the Cradle, the scan mode will be automatically switched to the Presentation Mode-Normal. Good Read Vibration After this feature is turned on, the scanner will have a vibration after the decoding is successful.
Page 41: Good Read Beeper
Good Read Beeper On/Off Good Read Beeper Volume Middle High...
Page 42: Good Read Beeper Duration
Good Read Beeper Duration Normal Short Good Read Beeper Frequency Extra Low Medium High...
Page 43: Inverse Colour
Inverse Colour Only Inverse ON Inverse and Normal Both ON...
Page 44: Chapter 4 Prefix & Suffix
Chapter 4 Prefix & Suffix General Configuration Add CR Add LF Add CRLF Add TAB...
Page 45: Add Prefix
Add Prefix Set Custom Prefix Steps for adding prefix Step1: Scan the programming barcode: Set Custom Prefix Step2: Select the symbology to which the prefix is applied (Appendix Code ID), scan the Digit Barcode. Step3: Set the prefix, scan the Digit Barcode for hex values for characters to be added.
Page 46: Add Suffix
Add Suffix Set Custom Suffix Steps for adding suffix Step1: Scan the programming barcode: Set Custom Suffix Step2: Select the symbology to which the suffix is applied (Appendix Code ID), scan the Digit Barcode. Step3: Set the suffix, scan the Digit Barcode for hex values for characters to be added.
Page 47: Clear All Prefix And Suffix
Clear All Prefix and Suffix Clear All Prefix And Suffix...
Page 48: Chapter 5 Symbologies
Chapter 5 Symbologies General Setting Enable All Symbologies If the Enable All Symbologies feature is enabled, the scanner will be able to read any barcodes supported by the product. Enable All Symbologies Disable All Symbologies If the Disable All Symbologies feature is enabled, the product will not be able to read any non- programming barcodes except the programming barcodes.
Page 49: 1D Symbologies
1D Symbologies Code 128 Enable/Disable Code 128 Enable Code 128 Disable Code 128 Message Length Message length can be set to the maximum value or minimum value. The value between the maximum and the minimum is valid. The maximum value and minimum value can be set using Programming Command.
Page 50: Transmit Check Digit
EAN-8 Enable/Disable EAN-8 Enable EAN-8 Disable EAN-8 Transmit Check Digit EAN-8 is 8 digits in length with the last one as its check digit used to verify the accuracy of the data. Transmit EAN-8 Check Digit Do Not Transmit EAN-8 Check Digit Add-On Code An EAN-8 barcode can be augmented with a two-digit or five-digit add-on code to form a new one.
Page 51 2-Digit Add-On Code Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code 5-Digit Add-On Code Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code...
Page 52: Addenda Separator
Add-On Code Required When this feature is enabled, the scanner can only read the EAN-8 barcodes with add-on code. EAN-8 Add-On Code required EAN-8 Add-On Code Not Required Addenda Separator When this feature is enabled, there is a space between barcode and addenda. When this feature is disabled, there is no space.
Page 53 EAN-13 Enable/Disable EAN-13 Enable EAN-13 Disable EAN-13 Transmit Check Digit EAN-13 is 13 digits in length with the last one as its check digit used to verify the accuracy of the data. Transmit EAN-13 Check Digit Do Not Transmit EAN-13 Check Digit...
Page 54 Add-On Code 2-Digit Add-On Code Enable 2-Digit Add-On Code Disable 2-Digit Add-On Code 5-Digit Add-On Code Enable 5-Digit Add-On Code Disable 5-Digit Add-On Code *...
Page 55: Isbn Translate
Add-On Code Required When this feature is enabled, the scanner can only read the EAN-13 barcodes with add-on code. EAN-13 Add-On Code Required EAN-13 Add-On Code Not Required Addenda Separator When this feature is enabled, there is a space between barcode and addenda. When this feature is disabled, there is no space.
Page 56: Upc-E
Enable ISBN Translate Disable ISBN Translate UPC-E Enable/Disable UPC-E0 Enable UPC-E0 Disable UPC-E0 Enable/Disable UPC-E1 Enable UPC-E1...
Page 57: Upc-E0 Expand
Disable UPC-E1 UPC-E0 Transmit Check Digit Transmit Check Digit Do Not Transmit Check Digit UPC-E0 Expand When enable this feature, convert UPC-E decode data to UPC-A format before transmission. Enable UPC-E0 Expand Disable UPC-E0 Expand...
Page 58: Upc-E0 Number System
UPC-E0 Number System The number system digit of UPC-E0 symbol is normally transmitted at the beginning of the scanned data, but the unit can be programmed so it will be not transmitted. Enable UPC-E0 Number System Disable UPC-E0 Number System Add-On Code 2-Digit Add-On Code Enable UPC-E0 2-Digit Add-On Code...
Page 59 5-Digit Add-On Code Enable UPC-E0 5-Digit Add-On Code Disable UPC-E0 5-Digit Add-On Code Add-On Code Required When this feature is enabled, the scanner can only read the UPC-E0 barcodes with add-on code. UPC-E0 Add-On Code Required UPC-E0 Add-On Code Not Required...
Page 60: Enable/Disable Upc-A
Addenda Separator Enable UPC-E0 Addenda Separator Disable UPC-E0 Addenda Separator UPC-A Enable/Disable UPC-A Enable UPC-A Disable UPC-A...
Page 61: Number System
Transmit Check Digit Enable UPC-A Transmit Check Digit Disable UPC-A Transmit Check Digit Number System The number system digit of UPC-A symbol is normally transmitted at the beginning of the scanned data, but the unit can be programmed so it will be not transmitted. Enable UPC-A Number System Disable UPC-A Number System...
Page 62 Add-On Code 2-Digit Add-On Code Enable UPC-A 2-Digit Add-On Code Disable UPC-A 2-Digit Add-On Code 5-Digit Add-On Code Enable UPC-A 5-Digit Add-On Code Disable UPC-A 5-Digit Add-On Code...
Page 63 Add-On Code Required When this feature is enabled, the scanner can only read the UPC-A barcodes with add-on code. UPC-A Add-On Code Required UPC-A Add-On Code Not Required Addenda Separator When this feature is enabled, there is a space between barcode and addenda. When this feature is disabled, there is no space.
Page 64: Interleaved 2 Of 5
Interleaved 2 of 5 Enable/Disable Interleaved 2 of 5 Enable Interleaved 2 of 5 Disable Interleaved 2 of 5 Message Length Message length can be set to the maximum value, minimum value. The data between the maximum and the minimum is valid. The maximum value and minimum value can be set using Programming Command. Max length command: 020404.
Page 65: Matrix 2 Of 5
Validate And Transmit Matrix 2 of 5 Enable/Disable Matrix 2 of 5 Enable Matrix 2 of 5 Disable Matrix 2 of 5 Message Length Message length can be set to the maximum value, minimum value. The value is valid between the maximum and the minimum.
Page 66: Industrial 2 Of 5
Industrial 2 of 5 Enable/Disable Industrial 2 of 5 Enable Industrial 2 of 5 Disable Industrial 2 of 5 Message Length Message length can be set to the maximum value, minimum value. The value is valid between the maximum and the minimum. The maximum value and minimum value can be set using Programming command.
Page 67: Start/Stop Character
Enable Code 39 Disable Code 39 Message Length Message length can be set to the maximum value, minimum value. The value is valid between the maximum and the minimum. The maximum value and minimum value can be set using Programming command.
Page 68: Code 39
No Check Char Validate Not Transmit Validate And Transmit Code 39 Full ASCII Enable Code 39 Full ASCII Disable Code 39 Full ASCII Code 39 Append This function allows the scanner to append several Code 39 barcode data together before transmitting to host.
Page 69: Enable/Disable Codabar
Enable Code 39 Append Disable Code 39 Append Codabar Enable/Disable Codabar Enable Codabar Disable Codabar Message Length Message length can be set to the maximum value, minimum value. The data between the maximum and the minimum is valid. The maximum value and minimum value can be set using Programming command. Coda bar max length command: 020206.
Page 70 Start/Stop Character Transmit Start/Stop Character Do Not Transmit Start/Stop Character Check Digit No Check Char Validate Not Transmit Validate And Transmit...
Page 71: Code 93
Code 93 Enable/Disable Code 93 Enable Code 93 Disable Code 93 Message Length Message length can be set to the maximum value, minimum value. The data between the maximum and the minimum is valid. The maximum value and minimum value can be set using Programming command. Code 93 max length command: 020D03.
Page 72: Gs1-128
Enable Code 93 Append Disable Code 93 Append GS1-128 Enable/Disable GS1-128 Enable GS1-128 Disable GS1-128 Message Length Message length can be set to the maximum value, minimum value. The data between the maximum and the minimum is valid. The maximum value and minimum value can be set using Programming command. GS1-128 max length command: 020B03.
Page 73: Msi
Enable/Disable MSI Enable MSI Disable MSI Message Length Message length can be set to the maximum value, minimum value. The data between the maximum and the minimum is valid. The maximum value and minimum value can be set using Programming command. MSI max length command: 020E04.
Page 74 One Check Character (MOD10) And Transmit Two Check Characters (MOD10/MOD11), Not Transmit Two Check Characters (MOD10/MOD11) And Transmit Two Check Characters (MOD10/MOD10), Not Transmit Two Check Characters (MOD10/MOD10) and Transmit Disable...
Page 75: Code 11
Code 11 Enable/Disable Code 11 Enable Code 11 Disable Code 11 Check Digit One Check Digit Two Check Digits...
Page 76: Code 32
Code 32 Enable/Disable Code 32 Enable Code 32 Disable Code 32 CodaBlock F Code Enable/Disable CodaBlock F Code Enable CodaBlock F Code Disable CodaBlock F Code...
Page 77: Gs1 Databar
GS1 DataBar Enable/Disable GS1 DataBar Enable GS1 DataBar Disable GS1 DataBar GS1 DataBar Limited Enable/Disable GS1 DataBar Limited Enable GS1 DataBar Limited Disable GS1 DataBar Limited...
Page 78: Gs1 Databar Expanded
GS1 DataBar Expanded Enable/Disable GS1 DataBar Expanded Enable GS1 DataBar Expanded Disable GS1 DataBar Expanded 2D Symbologies PDF417 Enable/Disable PDF417 Enable PDF417 Disable PDF417...
Page 79: Enable/Disable Micropdf417
Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum. The maximum value and minimum value can be set using Programming command. PDF417 max length command: 021F06. The parameter of this command can be set from min to 2750. PDF417 min length command: 021F05.
Page 80: Qr Code Append
Disable QR Code Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum is valid. The maximum value and minimum value can be set using Programming command. QR max length command: 023703.
Page 81: Data Matrix
Data Matrix Enable/Disable Data Matrix Enable Data Matrix Disable Data Matrix Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum. The maximum value and minimum value can be set using Programming command.
Page 82: Aztec
Enable Maxi Code Disable Maxi Code Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum. The maximum value and minimum value can be set using Programming command.
Page 83: Aztec Append
Disable Aztec Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum. The maximum value and minimum value can be set using Programming command. Aztec max length command: 023306. The parameter of this command can be set from min to 3832. Aztec min length command: 023305.
Page 84: Hanxin
Hanxin Enable/Disable Hanxin Enable Hanxin Disable Hanxin Message Length Message length can be set to the maximum value, minimum value. The data is valid between the maximum and the minimum. The maximum value and minimum value can be set using Programming command.
Page 85: Postal Code
Disable ECI Postal Code China Postal Code Enable/Disable China Postal Code Enable China Postal Code Disable China Postal Code Telepen Enable/Disable Telepen Enable Telepen...
Page 86 Disable Telepen...
Page 87: Chapter 6 Data Formatter
Chapter 6 Data Formatter Introduction You may use the Data Formatter to modify the scanner’s output. For example, you can use the Data Formatter to insert characters at certain points in barcode data. Normally, When you create a data format, you can save a total of four different data formats (Format 0, Format 1, Format 2 and Format 3) , Format 0 is primary format in the program.
Page 88: Change Data Format For Single Scan
Step7 Scan the programming barcode: Save. To save your data format. If you want to discard this setting, scan the programming barcode: Not Save. Save Not Save Program a Format 0 data format using data formatting, Code 128 containing 10 characters applicable, send all characters followed by “A”...
Page 89: Clear All Data Formats
Single Scan Format 0 Single Scan Format 1 Single Scan Format 2 Single Scan Format 3 This setting will be lost by removing power from the scanner, or turning off/rebooting the device. Clear All Data Formats If you want remove the data format created from your scanner, scan the programming barcode below. Clear All Data Formats Default data formatting is null.
Page 90: Data Formatting
Data Formatting Send all characters Syntax Description Include in the output message all of the characters from the input message, starting from current cursor position, followed by an insert character. F1xx xx stands for the insert character’s hex value for its ASCII code.
Page 91 Command string: F20341 F2: the “Send a number of characters” command 03: the number of characters to send 41: the hex value of “A” the data is output as: 123A Data Formatting: F1&F2 Example Split the content of the barcode below into two lines for output, the first line outputs the first 10 characters and the second line outputs the remaining content.
Page 92: Send All Characters Up To A Particular Character
Send all characters up to a particular character Syntax Description Include in the output message all characters from the input message, starting with the character at the current cursor position and continuing to, but not including, the search character “ss”, followed by an insert character. The cursor is moved forward to the “ss” F3ssxx character.
Page 93: Send All But The Last Characters
Command String: B900024243 B9: the “Send all characters up to a string” command 0002: the length for the added string 4243: The hex value combination of the string "BC" The data is output as: 1234567890A Data Formatting: Send all but the last characters Syntax Description Include in the output message all but not the last “nn”...
Page 94: Insert A Character Multiple Times
Insert a character multiple times Syntax Description Send “xx” character “nn” times in the output message, leaving the cursor in the current position. F4xxnn xx stands for the insert character’s hex value for its ASCII code. nn is the numeric value (00-99) for the number of times it should be sent. Insert the character A three times.
Page 95: Insert A String
Data Formatting: Insert a string Syntax Description Send “ss” string of “nn” length in the output message, leaving the cursor in the current position. BAnnnns…s nnnn stands for the length of the string. s...s stands for the string. Insert a string “abc”. Command string: BA0003616263 BA: the “Insert a string”...
Page 96: Insert Symbology Name
0003: the length of the string to be added (3 characters) 414243: the hex value for the string “ABC” The data is output as: 1234567890AABC Data Formatting: Insert symbology name Syntax Description Insert the name of the barcode’s symbology in the output message, without moving the cursor.
Page 97: Insert Bar Code Length
Insert bar code length Syntax Description Insert the barcode’s length in the output message, without moving the cursor. Output the length of the barcode below. Barcode 1: Barcode 2: Command string: B4 B3: the “Insert barcode length” command The data is output as: Barcode 1: 8 Barcode 2: 12 Data Formatting:...
Page 98: Insert Key Strokes
F4: the “Insert a character multiple times” command 20: the hex value for CR 01: the number of times the space character is sent F1: the “Send all characters” command 00: the hex value for <NUL> The data is output as: Code 128 20 1234567890ABCDEFGHIJ Data Formatting: Insert Key Strokes Syntax...
Page 99 Under the U.S. style keyboard, insert an “a”. Command string: B501001F B5: the “Insert Key Strkes” command 01: the number of keys pressed 00: No Key Modifier 1F: the key number of “a” The data is output as: a Data Formatting: Under the U.S.
Page 100: Insert A Delay
Insert a Delay Syntax Description Insert a delay of up to 49995 milliseconds (in multiples of 5), starting from the current cursor position. EFnnnn nnnn stands for the delay in 5ms increments, up to 9999. this command can only be used with USB HID-KB. Insert a delay (2s) after the 5th and 11th characters of the barcode below.
Page 101: Move The Cursor Forward A Number Of Characters
Move the cursor forward a number of characters Syntax Description Move the cursor ahead (right) “nn” characters from current cursor position. F5nn nn is the numeric value (00-99) for the number of characters the cursor should be moved ahead. Delete the first three characters of the bar code and output the remaining content. Command string: F503F100 F5: the “Move the cursor forward a number of characters”...
Page 102: Move The Cursor To The Beginning
EA: the “Move the cursor to the end” command F6: the “Move the cursor backward a number of characters” command 03: the number of characters to move the cursor F1: the “Send all characters” command 0D: the hex value for <NUL> The data is output as: GHIJ Data Formatting: Move the cursor to the beginning...
Page 103: Move The Cursor To The End
Move the cursor to the end Syntax Description Move the cursor to the last character in the input message. EA&F1 Example Output the symbology name and the last barcode content, separated by Space. Command string: EAB3F42001F100 EA: the “Move the cursor to the end” command B3: the “Insert symbology name”...
Page 104: Search Backward For A Character
Command string: F844F100 F8: the “Search forward for a character” command 44: the hex value for the “D” F1: the “Send all characters” command 0D: the hex value for <NUL> The data is output as: DEFGHIJ Data Formatting: Search backward for a character Syntax Description Search the input message backward (left) for “xx”...
Page 105: Search Forward For A String
Search forward for a string Syntax Description Search forward for “s...s” string from the current cursor position, leaving cursor pointing to “s..s” string. B0nnnns…s nnnn is the string length (up to 9999). s...s consists of the hex value of each character in the match string. Output all the content after “EFG”...
Page 106: Search Forward For A Non-Matching Character
Command string: EAB10003454647F100 EA: the “Move the cursor to the end” command B1: the “Search backward for a string” command 0003: the string length (3 characters) 454647：the hex value combination of the “EFG” F1: the “Send all characters” command 0D: the hex value for <NUL> The data is output as: EFGHIJ Data Formatting: Search forward for a non-matching character...
Page 107: Search Backward For A Non-Matching Character
Search backward for a non-matching character Syntax Description Search the input message backward for the first non-”xx” character from the current cursor position, leaving the cursor pointing to the non-”xx” character. E7xx xx stands for the search character’s hex value for its ASCII code.
Page 108: Stop Suppressing Characters
Command string: FB03205F2AF10D FB: the “Suppress characters” command 03: the number of character types to be suppressed 20: the hex value for a space 5F: the hex value for “_” 2A: the hex value for “*” F1: the “Send all characters” command 00: the hex value for <NUL>...
Page 109: Replace Characters
00: the hex value for <NUL> The data is output as: 123 456*789_A! Data Formatting: Replace characters Syntax Description Replaces up to 15 characters in the output message, without moving the cursor. E4nnxx ...zz nn is the total count of the number of characters in the list (characters to be replaces plus replacement characters).
Page 110: Stop Replacing Characters
Stop replacing characters Syntax Description Terminates characters replacement. Replace the "1" and "0" in the bar code data below with "A", but terminate this replacement. Command string: E40331413041E5F100 E4: the “Replace characters” command 04: the total count of characters to be replaced (“1”、“0”), plus the replacement character (“A”、 “A”) 31: the hex value for “1”...
Page 111: Compare String
Output the number in the bar code below. Command string: FE41FE42FE43F100 FE: the “Compare characters” command 41: the hex value for “A” FE: the “Compare characters” command 42: the hex value for “B” FE: the “Compare characters” command 43: the hex value for “C” F1: the “Send all characters”...
Page 112: Check For A Number
41: the hex value for “A” 42: the hex value for “B” 43: the hex value for “C” F1: the “Send all characters” command 00: the hex value for <NUL> The data is output as: 123456789 Data Formatting: Check for a number Syntax Description Check to make sure there is an ASCII number at the current cursor position.
Page 113: Check For Non-Numeric Character
Check for non-numeric character Syntax Description Check to make sure there is a non-numeric ASCII character at the current cursor position. The format is aborted if the character is numeric. Add suffix "A" to barcode beginning with a letter only. Barcode 1: Barcode 2: Barcode 3:...
Page 114: Chapter 7 Frequently Asked Questions
Chapter 7 Frequently Asked Questions How to switch the host? 1. When Bluetooth scanner connect to the host device by searching for product’s serial number, If user want to switch hosts, first ignore or delete this device in the Bluetooth list of the currently connected host, and then connect by searching for the device serial number of the product on the host to be connected.
Page 115: How To Switch To The Wired Mode
How to switch to the wired mode? Step1: Connect the scanner to the host by using TYPE-C or Micro USB cable (depending on scanner model). Step2: Scan the programming barcode below. Switch to the Wired Mode Step3: Waiting for the scanner to restart automatically. When the Bluetooth scanner is used as a wired device, the default interface is USB HID-KB, if you want to use the ElementConfig, scan the programming barcode USB COM Port Emulation.
Page 116: How To Print Out The Chinese Information In The Qr Code
How to print out the Chinese information in the QR code? When the scanner is connected to a Bluetooth Cradle or Dongle, scan the programming barcode below. Application Environment QR Coding Rule(UTF8/GB2312) Word Excel or Notepad++； The system language on the PC is Chinese.
Page 117: Appendix
Appendix Digit Barcode...
Page 118: Ascii Table
ASCII Table Char " &...
Page 119 Char < >...
Page 120 Char...
Page 121: Aim Id
AIM ID Symbology AIM ID Note Standard EAN-13 EAN-13 EAN-13 + 2-Digit Add-on Code EAN-13 + 5-Digit Add-on Code Standard EAN-8 ]E4...]E1. EAN-8 + 2-Digit Add-on Code EAN-8 ]E4...]E2. EAN-8 + 5-Digit Add-on Code Standard UPC-E UPC-E UPC-E + 2-Digit Add-on Code UPC-E + 5-Digit Add-on Code Standard UPC-A UPC-A...
Page 122 Two check digit, MOD10/MOD11; Transmit check digit Do not transmit check digit after parity check No parity check GS1-DataBar (RSS） ]e0 Standard GS1-DataBar Plessey Standard Plessey One check digit, MOD10; Transmit check digit One check digit, MOD10; Do not transmit check digit MSI-Plessey Two check digits No parity check...
Page 123: Code Id
Code ID Symbology Code ID All Symbologies Codabar Code 11 Code 128 EAN-13 EAN-8 GS1 DataBar GS1 DataBar Limited GS1 DataBar Expandede GS1 128 China Post(Hong Kong 2 of 5) China Post Interleaved 2 of 5 Matrix 2 of 5 Telepen UPC-A UPC-E...
Page 124: Unicode Key Maps
Unicode Key Maps Key Modifiers Key Modifiers No Key Modifier Shift Left Shift Right Alt Left Alt Right Control Left Control Right Key Modifiers can be added to together when needed. Example: Control Left + Shift Left = 11.
