- Page 1 CT-CovertConfigurationKit Configuration kit for individual setup of In-Ear hearing systems for covert communication Installation and operation Example English Revision/01/0716 DOK 1737-be 1 / 12...
-
Page 2: Table Of Contents
Use CeoTronics products only without damage and abrasion. If repair work of any kind needs to be done to CeoTronics products, arrange for it to be performed only by the company CeoTronics or by a specialized workshop that is authorized by CeoTronics. - Page 3 If in doubt, ask your safety officer or company doctor. Road traffic hazard! Do not leave CeoTronics products lying around loose in cars, e.g. on the parcel shelf. Stow these products in a suitable, safe place in the car so that they do not present a danger to you or to other occupants of the car, if emergency braking is effected.
- Page 4 Damage to charger or rechargeable batteries! Charge rechargeable batteries only using the corresponding appropriate CeoTronics charger. Regard voltage and current data, also on the mains side (e.g. 230 V AC or 115 V AC).
- Page 5 The end user has to check and decide that the products can be used without risk. CeoTronics does not take over responsibility for any damage or material losses nor injuries to persons, caused by the use described above or by any other abnormal use of the products.
-
Page 6: General
The kit makes it possible to fine-tune radio volume and the transparency of ambient sounds Up to three different operation modes can be configured and saved into a profile. The profile can be assigned to a user and ear piece. A database with the CT-CovertConfigurationKit manages the different profiles and the user’s preferences. - Page 7 Inspect the goods immediately upon receipt for completeness and INFO possible transport damages! Notify transport damages immediately to the forwarder and CeoTronics Danger of ingestion and choking! Packaging materials, e.g. filling materials and plastic bags are not toys and have to be kept out of reach of children. There is a risk of children ingesting...
-
Page 8: Installation Of The Software (Standard)
Installation of the software (Standard) The installation of the software is necessary when the standard version of the kit is used (cf. Figure 1). In the version “Full set” the software is already installed on the system’s tablet and the system is ready for operation. - Page 9 Figure 5 Figure 6 Place the connection cable in the system gently. Check for proper orientation and alignment. PC / Tablet Connect the in-ear system to the programming box and the programming box via the USB-cable to the PC/tablet After a successful connection to the PC/tablet, the middle LED (PWR) of the programming box turns green and a brief start melody is audible in the in-ear hearing system.
-
Page 10: Menu "File
Click “Save” after all settings have been made. Signal tones indicate when the settings have been applied to the device. The number of tones indicates the currently active mode on the device. Menu “File” Select profile – XML file – navigate to the appropriate folder Usually the drivers have already been installed on the system with the first start of the program. -
Page 11: Finish Configuration
Finish configuration When you are done with the configuration of a single earpiece, save your settings and click “Disconnect” to disconnect the earpiece from the software. After that, detach the connection cable from the device and attach the cover of battery compartment. - Page 12 06295 Lutherstadt Eisleben Tel. +34 91 4608250 51 Tel. +49 34776 6149-0 Fax +34 91 4603193 Fax +49 34776 6149-11 E-Mail ventas@ceotronics.es E-Mail ctv.info@ceotronics.com Revision/01/0716 DOK 1737-be Änderungen vorbehalten Copyright © 03/2016 CeoTronics AG, 63322 Rödermark, Deutschland, Internet www.ceotronics.com...
