- Page 1 ODP8000 Series Programmable DC Power Supply User Manual ■ ODP8353 ■ ODP8354 For product support, visit:www.owon.com.hk/download ※:The illustrations, interface, icons and characters in the user manual may be slightly different from the actual product. Please refer to the actual product.
- Page 2 LILLIPUT will continue to improve products and reserves the rights to change specification at any time without notice. is the registered trademark of the LILLIPUT Company. Fujian LILLIPUT Optoelectronics Technology Co., Ltd. No. 19, Heming Road Lantian Industrial Zone, Zhangzhou 363005 P.R. China Tel: +86-596-2130430 Fax: +86-596-2109272 Web: www.owon.com E-mail: info@owon.com.cn...
-
Page 3: General Warranty
General Warranty We warrant that the product will be free from defects in materials and workmanship for a period of 2 years from the date of purchase of the product by the original purchaser from our company. The warranty period for accessories is 12 months. This warranty only applies to the original purchaser and is not transferable to a third party. -
Page 4: Table Of Contents
Table of Contents 1. General Safety Requirements ................. 1 2. Safety Terms and Symbols ................2 3. Quick Start ......................3 3.1 Front/Rear Panel and User Interface ..............3 3.1.1 Front Panel ........................3 3.1.2 Rear Panel .........................5 3.1.3 User Interface ........................6 Status Icons ............................ - Page 5 4.8 Port Settings ......................21 4.8.1 Serial Setting ........................21 4.8.2 LAN Setting ........................22 4.9 System Information ....................23 4.9.1 View System Information ....................23 4.9.2 Default Setting ......................... 23 4.9.3 Update ..........................24 4.10 Other Settings ....................... 26 4.10.1 Knob Setting ........................26 4.10.2 Screen Test ........................
-
Page 6: General Safety Requirements
1.General Safety Requirements 1. General Safety Requirements Before use, please read the following safety precautions to avoid any possible bodily injury and to prevent this product or any other connected products from damage. To avoid any contingent danger, ensure this product is only used within the ranges specified. -
Page 7: Safety Terms And Symbols
2.Safety Terms and Symbols 2. Safety Terms and Symbols Safety Terms Terms in this manual (The following terms may appear in this manual): Warning: Warning indicates conditions or practices that could result in injury or loss of life. Caution: Caution indicates the conditions or practices that could result in damage to this product or other property. -
Page 8: Quick Start
3.Quick Start 3. Quick Start 3.1 Front/Rear Panel and User Interface This manual uses the four-channel example for illustration. For the three-channel version, please refer to the four-channel instructions. 3.1.1 Front Panel Figure 3- 1 Front panel overview ① LCD User interface display. - Page 9 3.Quick Start ③ Knob Select menu or change the value, pressing it has the same effect as pressing the enter key. ④ Left and right Set sub menu or move the cursor. direction key ⑤ Function keys Utility key: Menu of output mode, utility, info, port settings.
-
Page 10: Rear Panel
3.Quick Start ⑬ CH3 output Channel 3 output connectors. terminals ⑭ Menu selection Include 4 buttons, press it to select corresponding menu. button ⑮ Power button Turn on/off the instrument Instructions for panel key indicator ON/OFF key: Press the button, and the channel light and the button light will turn 3.1.2 Rear Panel Figure 3- 2 Rear panel overview ①... -
Page 11: User Interface
3.Quick Start interface Channel 2. ③ LAN interface The power supply can be connected to the network for remote control via this connector. ④ Fan Fan inlet. ⑤ RS232 interface Serial port for connecting the instrument to external devices. ⑥ Power socket AC input connector. -
Page 12: General Inspection
3.Quick Start The beeper is turned on 3.2 General Inspection When you receive your new power supply, it is recommended that you check the instrument following these steps: 1. Check for transportation damage. If it is found that the packaging carton or the foamed plastic protection cushion has suffered serious damage, do not throw it away first till the complete device and its accessories succeed in the electrical and mechanical property tests. -
Page 13: Output Inspection
3.Quick Start 3.4 Output Inspection Output inspection is to ensure that the instrument can achieve its rated outputs and properly respond to operation from the front panel. For the procedures below, it is suggested that you read "Turn On/Off the Channel Output" on page 10 and "Set the Output Voltage/Current"... - Page 14 3.Quick Start rating. (6) Turn off the channel output and remove the short circuit from the output terminals.
-
Page 15: Front Panel Operation
4.Front Panel Operation 4. Front Panel Operation 4.1 Turn On/Off the Channel Output Yellow On/Off button: Pressing the On/Off button will turn on the output of Channel 1, and the button light will turn on. Pressing the button again will turn off the output of Channel 1, and the button light will turn off. -
Page 16: Set The Output Current
4.Front Panel Operation Press the CH3 button to select Channel 3, then press the Volt Set key to enter edit mode. You can set the value in the same way as CH1 above. Set the output voltage of CH4 Press the CH4 button to select Channel 4, then press the Volt Set key to enter edit mode. -
Page 17: Set Ovp
4.Front Panel Operation a warning will show on the screen. Note: When the instrument disables the output due to protection, after you make some adjustments, the channel must be restarted to output normally. This function can keep the power output from exceeding the load rating to protect the load. -
Page 18: Save Settings/Auto Record
4.Front Panel Operation set OCP is flashing, indicating the value is editable. The following methods can be used to set the value: Turn the knob to change the value. Press the ＜ / ＞ key to move the cursor. Press the key to confirm. -
Page 19: Auto Record
4.Front Panel Operation 4.4.2 Auto Record Press the Record key. Then press Auto to enter automatic record menu. (1) Press ▲ / ▼ to select Interval. Use the numeric keys to set the record interval, press the key to confirm. (2) Press ▲... -
Page 20: Programmable Output
4.Front Panel Operation If the display mode is set to Sheet, the records will be displayed in table format; if the display mode is set to Wave, the records will be displayed in waveform format. Sheet display mode Wave display mode 4.5 Programmable Output The programmable output function can preset up to 100 groups of timing parameters. -
Page 21: Output Set
4.Front Panel Operation Program_XXXXXXXX.csv, where XXXXXXXX represents the serial number. The file must be placed in the Program subfolder to be recognized. (2) Press ▲ / ▼ to select Export . Insert U disk and press the key to export data. -
Page 22: Output Mode
4.Front Panel Operation (1) In the data processing interface, Press the ＜ / ＞ key to turn the page. Press the ▲ / ▼ key to move the cursor up and down. Turn the knob to move the cursor between CH1 and CH2. Use the After selecting the parameter, use the numeric keys to enter a desired value, press the key to confirm. -
Page 23: Parallel Mode
4.Front Panel Operation Parallel mode When CH1 and CH2 are connected in parallel, you can select this mode to simplify the parameter inputting. You just need to set the parameters of the combined channel. The voltage rating is same as the single channel; the current rating is the sum of CH1 and CH2 current rating. -
Page 24: Series Mode
4.Front Panel Operation Series mode When CH1 and CH2 are connected in series, you can select this mode to simplify the parameter inputting. You just need to set the parameters of the combined channel. The voltage rating is the sum of CH1 and CH2 voltage rating;... - Page 25 4.Front Panel Operation Channel track In independent output mode, set the output parameters of CH1 and CH2, and then enter the channel track mode, if the parameters of any one channel are changed, the other channel will change proportionally. For example, in independent output mode, set the CH1 voltage to 2V, current to 1A;...
-
Page 26: Utility Settings
4.Front Panel Operation To set the output mode: (1) Press the Utility key. Then press Mode to enter output mode menu. (2) Press the ▲ / ▼ key to select the Output. Press the ＜ / ＞ key to choose Independ, Series, Parallel or Track as current output mode. -
Page 27: Brightness
4.Front Panel Operation 4.7.2 Brightness (1) Press the Utility key. Then press System to enter system setting menu. (2) Press the ▲ / ▼ key to select the Screen. Use the knob or numeric keypad to set the desired value. 4.7.3 Beeper (1) Press the Utility key. -
Page 28: Lan Setting
4.Front Panel Operation (6) Press the ▲ / ▼ key to select Parity. Press the ＜ / ＞ key to select None, Odd, or Even. 4.8.2 LAN Setting (1) Press the Utility key. Then press Interface to enter interface setting menu. (2) Press the Interface key to select the Lan. -
Page 29: Default Setting
4.Front Panel Operation 4.9.2 Default Setting (1) Press the Utility key. Then press Info to enter system information menu. (2) Press the ▲ / ▼ key to select the Default. Press the key to use the factory defaults, see table below. Output VOLT CURR... -
Page 30: Update
4.Front Panel Operation Port 3000 Save Channel Interval Recor Auto Points 1000 Channel Channel View Display Sheet Cycle Order Progra Output Range Begin: 1 ~ End: 100 Channel 4.9.3 Update Use the front-panel USB port to update your instrument firmware using a USB memory device. -
Page 31: Other Settings
4.Front Panel Operation instrument. If the status icon appears on the left of the screen, the USB memory device is installed successfully. (5) Press the ▲ / ▼ key to select the Update. Press the key to start update. (6) The instrument displays a message telling you not to remove the USB device or power off the instrument until the update process is complete. -
Page 32: Screen Test
4.Front Panel Operation 4.10.2 Screen Test The instrument has a screen self test function, which can test the LCD screen. (1) Press the Utility key. Then press Other to enter other setting menu. (2) Press the ▲ / ▼ key to select the Screen. Press the key to enter the screen test interface. -
Page 33: Troubleshooting
5.Troubleshooting 5. Troubleshooting 1. The instrument is powered on but no Display. Check if the power is connected properly. Check if the fuse which is below the AC Power socket is used appropriately and in good condition (the cover can be pried open with a straight screwdriver). -
Page 34: Technical Specifications
6.Technical Specifications 6. Technical Specifications The specifications below are based on the instrument having run for at least 30 minutes continuously under the specified operating temperature. 6.1 ODP8353 Parameter Parameter Description CH1: 30V/5A, Maximum 90W constant power output Voltage/ CH2: 30V/5A, Maximum 90W constant Current power output CH3: 24V/3A, Maximum 24W constant... - Page 35 6.Technical Specifications Voltage ≤0.01%+3mV Series Current ≤0.01%+3mA Voltage Indepen dent Current Settings Voltage Parallel Resolution Current Voltage Series Current Indepen Voltage dent Current Voltage Read Back Parallel Resolution Current Voltage Series Current Indepen Voltage ±(0.03% of reading+10)mV Settings dent Current ±(0.1% of reading+5)mA Accuracy Voltage...
- Page 36 6.Technical Specifications Voltage(Vp-p) ≤5mVp-p Parallel Voltage(rms) ≤1mVrms Current(rms) ≤10mArms Voltage(Vp-p) ≤10mVp-p Series Voltage(rms) ≤1mVrms Current(rms) ≤5mArms Indepen Voltage 100ppm/℃ dent Current 200ppm/℃ Temperatu Voltage 100ppm/℃ Parallel Current 200ppm/℃ Coefficient Voltage 100ppm/℃ Series Current 200ppm/℃ Storage 1M points Groups saved Programmable in internal 100 groups output...
-
Page 37: Odp8354 Parameter
6.Technical Specifications 6.2 ODP8354 Parameter Parameter Description CH1: 30V/5A, Maximum 90W constant power output CH2: 30V/5A, Maximum 90W constant Voltage/ power output Current CH3: 24V/3A, Maximum 24W constant power output CH4: 24V/3A, Maximum 24W constant power output Output Ratings (0℃-40℃) CH1,CH2 Parallel 60V/5A, Maximum 180W constant power... - Page 38 6.Technical Specifications Current ≤0.01%+3mA Indepe Voltage ndent Current Settings Voltage Parallel Resolution Current Voltage Series Current Indepe Voltage ndent Current Read Back Voltage Parallel Resolution Current Voltage Series Current Indepe Voltage ±(0.03% of reading+10)mV Settings ndent Current ±(0.1% of reading+5)mA Accuracy Voltage ±(0.03% of reading+10)mV...
-
Page 39: General Parameter
6.Technical Specifications Voltage(rms) ≤1mVrms Current(rms) ≤10mArms Voltage(Vp-p) ≤10mVp-p Series Voltage(rms) ≤1mVrms Current(rms) ≤5mArms Indepe Voltage 100ppm/℃ ndent Current 200ppm/℃ Temperatu Voltage 100ppm/℃ Parallel Current 200ppm/℃ Coefficient Voltage 100ppm/℃ Series Current 200ppm/℃ Storage 1M points Groups saved Programmable in internal 100 groups output memory Time setting... - Page 40 6.Technical Specifications Supply 110 VAC ± 10% or 220 VAC ± 10%; AC input 50/60Hz 110 V 250 V，F5A ODP8353 220 V 250 V，F3A Fuse 110 V 250 V，F5A ODP8354 220 V 250 V，F3A Environment Characteristics Description Working temperature: 0℃～40℃ Temperature Storage temperature: -20℃～60℃...
-
Page 41: Appendix
7.Appendix 7. Appendix 7.1 Appendix A: Packaging (The accessories subject to final delivery.) Standard Accessories: Power Cord User Manual USB Cable Fuse Options: Banana plug to crocodile clip test leads 7.2 Appendix B: General Care and Cleaning General Care Do not store or leave the instrument where the liquid crystal display could be exposed to direct sunlight for long periods of time. - Page 42 7.Appendix Warning: Before re applying power, ensure that the instrument is completely dry, avoiding any electric shock or electrical short circuit resulting from moisture.
