INSTRUCTIONS FOR USE

Washing machine

W4086R.W.AU

WM75.1

Carefully read the instructions for use before using the washing machine.

Table of Contents

Need help?

Do you have a question about the W4086R.W.AU and is the answer not in the manual?

Questions and answers

Summary of Contents for Asko W4086R.W.AU

Page 1 INSTRUCTIONS FOR USE Washing machine W4086R.W.AU WM75.1 Carefully read the instructions for use before using the washing machine.
Page 2: Table Of Contents
Dear Customer, We thank you for purchasing this quality ASKO product. We hope it meets all your expectations. Scandinavian design combines pure lines, everyday functionality, and high quality. These are the key characteristics of all our products, and the reason why they are highly appreciated across the globe.
Page 3: Safety Precautions
Keep the instruction manual handy, near the washing machine. • Instructions for use are available on our website at www.asko.com. • Your washing machine is intended solely for household use.
Page 4: Child Safety
• Bleaches that contain chlorine can be replaced with oxygen-based bleaches. Otherwise, a neutralization cycle should be performed by running the Cotton program at the highest temperature. For best results, use hydrogen peroxide or oxygen-based detergents. • Do not use colourants (dyes) or bleaching substances (substances for discolouration or removal of colourants) as they contain sulphuric compounds that could cause corrosion.
Page 5 regarding safe use of the washing machine, and if they understand the hazards of inappropriate use. Make sure children do not play with the appliance. Make sure the children do not clean the washing machine or perform any maintenance tasks without supervision. DANGER OF HOT SURFACE •...
Page 6: Washing Machine Description
WASHING MACHINE DESCRIPTION Main switch (ON/OFF) Program selector knob Display unit Program settings buttons Button (start/pause) Detergent compartment QR and AUID code (on the inside of the washing machine door) Rating plate with information about the washing machine (on the inside of the washing machine door) Washing machine door 10.
Page 7: Before Using The Appliance For The First Time
BEFORE USING THE APPLIANCE FOR THE FIRST TIME PACKAGING Remove all packaging. Please sort the materials in compliance with local recommendations (see chapter ”DISPOSAL”). TRANSPORT PROTECTION Before using the appliance, remove the three transport bolts and plastic plugs which protect the appliance during transport.
Page 8: Settings Before First Use
CLEANING Disconnect the washing machine from the power mains and open the door. Clean the washing machine drum with a damp cloth and a mild detergent. Connect the washing machine to the power mains and run the dedicated drum cleaning program. See chapter "WASHING PROCESS;...
Page 9 In models with ADS the amount of detergent dispensed also depends on the water hardness setting. Before using the AD system for the ﬁ rst time, run one of the programs (without any laundry), after ﬁ lling the A or B tank with liquid detergent (see chapter ”SPECIAL FEATURES”). Before the product is dispatched from the factory, every appliance is tested.
Page 10: Installation And Connection
INSTALLATION AND CONNECTION POSITIONING THE WASHING MACHINE Clearances around the washing machine The washing machine can be installed as a built- in (integrated) or a free-standing unit. Place the machine on a level surface so that the power outlet on the wall is accessible. min.
Page 11 Stacking an ASKO dryer on top of an ASKO concept or closet installation washing machine To stack an ASKO dryer on top of a washing ASKO's front panel controls make it possible to machine, use the extra vacuum feet and the tipping install the washers and dryers in a cabinet or closet.
Page 12: Adjusting The Feet
ADJUSTING THE FEET MOVING THE WASHING MACHINE AND TRANSPORT AFTER INSTALLATION Place the washing machine so that it is stable. 1. Level the washing machine in longitudinal and If you are moving the washing machine without traverse direction by rotating the adjustable feet packaging, open the washing machine door and pull (using a No.
Page 13: Connecting To Water Supply
CONNECTING TO WATER SUPPLY CONNECTING TO HOT/COLD WATER SUPPLY The machine has to be connected to water (Only available in some models) supply by an adequately trained person. If your appliance has connections for both hot and cold water, then connect one hose to the cold Use the water supply hose to connect the appliance.
Page 14: Installing The Drain Hose
INSTALLING THE DRAIN HOSE Upon delivery, the appliance has a drain hose attached. This drain hose must be connected to a drain. Drain hose can also be attached to a wall drain with a trap; such trap should be properly installed to allow cleaning.
Page 15: Connecting To The Power Mains
CONNECTING TO THE POWER MAINS After installation, the washing machine should stand still for two hours before it is connected to the power mains. Connect the appliance to an earthed power outlet. After installation, the wall outlet should be freely accessible.
Page 16 ASKO LAUNDRY CARE - HIDDEN HELPERS* Laundry care ironing board The ironing board is a clever solution. It is always handy when you need to iron your clothes, and it can be easily, safely and invisibly stored away when not in use.
Page 17 Laundry care plinth Thanks to the stainless steel plinth, your appliance will be raised by 30 cm, which makes loading and unloading of laundry easier. *AVAILABILITY DEPENDING ON MARKET DENOMINATION ART. No. IRONING BOARD HI1153 White 576552 IRONING BOARD HI1153 Stainless steel 732756 IRONING BOARD HI1153 Titanium 576553...
Page 18: Tips Before Washing
TIPS BEFORE WASHING LAUNDRY SYMBOLS This chapter includes several tips on how to prepare the laundry for washing. Observe the laundry symbols. Textile maintenance symbols: LAUNDRY SORTING Washing Sort the laundry according to: • how soiled it is, Normal Delicate •...
Page 19 DYED COTTON ECONOMY AND EFFICIENCY Laundry made of dyed cotton which is to be washed You can save a lot of energy by not using the at 60 °C should be ﬁ rst washed at a temperature of programs operating at higher temperatures. 60 °C to remove the excess dye.
Page 20: Washing Process, Step By Step (1 - 8)
WASHING PROCESS, STEP BY STEP (1 – 8) STEP 1: SORT THE LAUNDRY See chapter "TIPS BEFORE WASHING" Use a washing net for underwire bras. Empty the pockets. Coins, nails etc. could damage the machine and the fabric. STEP 2: TURN ON THE MAIN SWITCH.
Page 21 STEP 4: ADD THE DETERGENT AND THE CONDITIONER. Recommended amount of detergent is usually speciﬁ ed on the detergent packaging. When washing a smaller amount of laundry, the amount of detergent used can be decreased. Observe manufacturers' recommendations regarding the type of detergent suitable for certain temperatures, load size, and water hardness.
Page 22 STEP 5: CHOOSE THE PROGRAM. Choose the program by rotating the Program selector knob in either direction. The Program selector knob can be used when arrows appear on the display. Choose the program depending on the type of laundry and how heavily soiled it is (see chapter "TIPS BEFORE WASHING").
Page 23 Program Description 7. AUTO This program automatically adjusts the duration of the main wash and number of rinses depending on the amount of laundry in the machine. No extra program settings are possible. 8. QUICK Quick program for laundry that only needs refreshing. The program operates at certain temperatures;...
Page 24 Program Description 17. QUICK PRO A quick program with high efficiency for smaller amounts of lightly soiled laundry. The program washes with intensive tumbling and 1200 rpm. (4 kg, 40 °C, 59 min) 18. RINSE This program includes 2 cold rinses and a short spinning cycle. The program is suitable for laundry that only needs rinsing, and for cleaning cloths or mops.
Page 25 STEP 6: CHOOSING THE PROGRAM SETTINGS Using the program settings, the washing programs can be further adjusted to your wishes. Some program settings may not be available for your selected program. Selected program settings will remain stored after the end of the washing cycle and may be changed subsequently (except for delayed start which is not stored after the wash is complete).
Page 26 3. Spin speed By consecutively pressing the button 3, you can set the spin speed, choosing from the following available values: d (no drain) /... / max. (rpm) (max rpm = depends on the model) Default setting is 1400 rpm; it depends on the selected program (spin rate can be changed – reduced or increased (only in some models)).
Page 27 5. Delay start Press the button 5 to choose the delayed start when you wish the washing program to start after a certain period of time (30´ to 24 hours after you press the Start button). The estimated time remaining until the Normal Normal 60°C...
Page 28: Start The Wash
STEP 7: START THE WASH Close the washing machine door and press the Start/Pause button. Start (short press of the button – start/resume) Pause (short press of the button – pause) Stop (press and hold for 3 seconds – stop or cancel) Info 2:20 Starting...
Page 29 Pausing, stopping or changing the program To pause the program, shortly press the Stop program Paused Add clothes Start/Pause button. To resume a program, press the Start/ Pause button again. To stop the washing program, press and hold for 3 seconds button Start/Pause. Use the button 1 to choose "Stop program".
Page 30: Step 8: End Of Program
STEP 8: END OF PROGRAM After the end of the washing program, Start Cycle completed succsessfully the display will indicate that the program has been successfully completed ("Cycle completed successfully"). If you have selected the Anti-Crease Anti Stop anti creasing Cycle completed succsessfully creasing extra function, gentle tumbling will...
Page 31 Changing a favourite program If you wish to store a program after the end of the washing cycle, but there is no more room for another favourite program (only 4 favourite program slots are available), then one of the existing stored favourite programs can be substituted with a new one.
Page 32: System Settings
SYSTEM SETTINGS In the main menu, use the Program Enter System settings selector knob to select System Settings. Conﬁ rm the selection by pressing the button 2. Then, use the Program selector knob to scroll the list of the following settings that you can adjust: •...
Page 33 AUTO DOSE SYSTEM (ADS) Press the ON/OFF button to switch on/oﬀ the ADS display in the main menu. Main Main For ADS settings, see chapter "SPECIAL Russian Auto Dosing Language Auto Dose Info Back Back Back Colour White FEATURES". ON = display the ADS menu in the Main Normal Normal 40°C...
Page 34 How to use the test strip: 1. Turn on the water tap and let the water run for a minute or so. 2. Fill a glass with cold water. 3. Remove the test strip from its packaging. 4. Dip the test strip in the water for about one second. 5.
Page 35: Display Unit
DISPLAY UNIT Set the contrast and logo display. Display Contrast Logotype Back Use the buttons 1 to 5 to set the Contrast Back contrast. Use the button 1 to toggle logo display Logotype Back or oﬀ If you choose on , the logo will be displayed on the display unit when the washing machine is turned on.
Page 36: Special Features
SPECIAL FEATURES AUTO DOSE SYSTEM (ADS) 1. ADS display in the Main menu (see chapter "SYSTEM SETTINGS") 2. Choosing the ADS settings in the Main menu 3. Filling the ADS tank 4. Choosing the ADS settings by opening the detergent compartment 5.
Page 37 a = amount of liquid detergent Auto Dose Clean tank Black Back 1 dose 10 ML b = choosing the liquid detergent for the B compartment c = cleaning the selected compartment a. Amount of liquid detergent (ml/cycle from the compartment, A or B. Choose the amount of detergent according to liquid detergent manufacturer's recommendations speciﬁ...
Page 38 Add 500 ml water to tank B. Close If you do not wish to rinse the tank with Auto Dose Back compartment and press start. water, the process can be cancelled by pressing 6 (Back) button. If you have already started adding the water, the process can no longer be cancelled and water ﬁ...
Page 39 4. Choosing the ADS settings by opening the detergent compartment Pull out the detergent compartment as far as it will go, to its end position! The ADS setting in the Main Menu will be displayed. All steps are the same as with section 2 (Choosing the ADS settings in the Main menu). If you selected OFF in the System Settings (i.e.
Page 40: Cleaning And Maintenance
CLEANING AND MAINTENANCE CLEANING THE FILTER The washing machine has a ﬁ lter that will retain smaller objects such as coins, buttons, hair etc. Before cleaning, drain the water from the washing machine using the Drain program, and disconnect the washing machine from the power mains. Open the pump ﬁ...
Page 41 CLEANING THE DETERGENT COMPARTMENT AND DOOR RUBBER GASKET Press the tab to completely remove the detergent compartment from its housing. Rinse and thoroughly clean the tray. You may also remove the cap from the plug in the conditioner compartment (A). Clean any residue from the cap and tube.
Page 42 CLEANING THE AUTO DOSE SYSTEM (ADS) Cleaning the detergent compartment: Remove the detergent compartment from the detergent compartment housing by pulling it out and pressing the release tab (1). Open the cover for detergent compartment A and B (2). Rinse the detergent compartment by directing a stream of running water through it.
Page 43: Cleaning The Appliance Exterior
CLEANING THE APPLIANCE EXTERIOR Clean the appliance exterior and the display unit using a soft damp cotton cloth and water. Do not use solvents or abrasive cleaners that could damage the appliance (please observe the recommendations and warnings provided by the manufacturers of the cleaning agents). Do not clean the washing machine with a jet of water! Always disconnect the washing machine from the power mains before cleaning.
Page 44 CLEANING THE RINSING HOLES (UNDER THE AGITATOR IN THE DRUM) If you believe that objects like nails or paper clips fell into the washing machine drum, check the area underneath the agitator. Such objects may rust (corrode) and cause stains on your clothes. Nails and other sharp objects can also cause holes in the fabric.
Page 45: Errors - What To Do
ERRORS – WHAT TO DO? Disturbances from the environment (e.g. the power grid) may result in various error reports (see Troubleshooting table). In such case: • Switch oﬀ the appliance, wait for 1 minute, switch the appliance back on, and repeat the washing program. •...
Page 46 Problem/error Cause What to do? There are traces • The laundry was very greasy. • Wash the laundry again. When your laundry is of grease (or this heavily soiled, add more washing powder or grease rolls) on the use a liquid detergent in combination with a more clothes.
Page 47 Manual opening of washing machine door Washing machine door may be opened manually if the appliance is not connected to the power mains and if the water has been pumped out of the machine. A Choose the Spinning or Drain program to pump the water from the machine. If this does not work, water has to be drained from the washing machine drum manually.
Page 48: Failure Display
FAILURE DISPLAY In case of a failure while a program is in progress, the relevant Error X is indicated on the display unit. Press the INFO button to display the Error 3 Info Exit error description. Switch oﬀ the appliance and turn it back Errors indicated on the display unit may include the following: Error Error indication on the display...
Page 49 Error Error indication on the display What to do? unit E13.1 UNBALANCE EMPTY DRUM Call a service technician. E13.2 INERTIA ERROR Call a service technician. DOOR UNLOCK ERROR Door is closed, but it cannot be unlocked. Turn off the washing Error while unlocking the door.
Page 50: Service
SERVICE BEFORE CALLING A SERVICE TECHNICIAN 1, 2, 3 When you contact a service centre, please state the model (1), type (2), and serial number (3) of your washing machine. Model, type, and serial number are indicated on the rating (type) plate located on the washing machine door casing.
Page 51: Technical Information
TECHNICAL INFORMATION Information for test institute ENERGY LABELLING Australian standard AS/NZS 2040.1:2005 Washing program Normal, 40 °C, 8 kg cotton Connection Cold water 20 °C Test method for noise measurement IEC-60704-2-4 Power requirement when machine turned off < 0,3 W Power requirement for Delayed Start <...
Page 52 Loading procedure for standard test: Detergent, PBIS and Anti-Sudsing Agent (16ml) must be added via the detergent compartment. Loading procedure for standard test: When loading the machine for testing according to AS/NZS 2040:2005 it shall be loaded according to the table below.
Page 53 TECHNICAL INFORMATION Height 850 mm Width 595 mm Depth 585 mm Weight 77,5 kg Drum volume 60 l Rated power See rating plate Heater power See rating plate Water pressure 0,1–1 MPa 1–10 kp/cm 10–100 N/cm Material for the drum and dispenser Stainless steel Housing material Hot-dip galvanized and powder coated sheet metal, or...
Page 54: Program Table
PROGRAM TABLE Program 1. Normal * 1600 60/56** 0,67/059** 3:54 2. Cotton 1600 1,30 2:59 3. Mix/Synthetics 1200 0,60 1:54 4. Wool/Hand 0,28 0:52 5. Dark wash 1200 0,53 1:15 6. Time program 1000 7. Auto 1600 8. Quick Cold 1200 0,50 0:50...
Page 55 Adjustment of the displayed washing time Advanced technology allows the appliance to sense the amount of laundry and add the required amount of water during the washing process. Depending on the washing load, washing time can be longer or shorter and the time displayed will be adjusted accordingly.
Page 56 TABLE: WASHING MODE/TEMPERATURE Washing mode Program 1. Normal -90°C 20°C-90°C -90°C 30°C-90°C 40°C-90°C 2. Cotton 20°C-90°C 40°C-90°C -90°C -90°C 3. Mix/Synthetics -60°C 20°C-60°C -60°C 30°C-60°C 40°C-60°C 4. Wool/Hand ,30°C-40°C ,30°C-40°C 5. Dark wash 30°C-40°C 40°C ,30°C-40°C ,30°C-40°C 6. Time program -60°C 7.
Page 57: Option Table
OPTION TABLE Options Program 1. Normal 1600 2. Cotton 1600 3. Mix/Synthetics 1200 4. Wool/Hand 5. Dark wash 1200 6. Time program 1000 7. Auto 1600 8. Quick 1200 9. Heavy 1600 10. Easy care 1200 11. Jeans 1200 12. Shirts 1200 13.
Page 58: Disposal
DISPOSAL Disposal / recycling of packaging Our product packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. To this end, packaging materials are labelled appropriately. The symbol on the product or its packaging indicates that the product should not be treated as normal household waste.
Page 59: Quick Guide
QUICK GUIDE SORT THE LAUNDRY. Close the zippers fasteners. Empty the pockets and turn them inside out. Check the laundry care symbols. Sort the laundry based on how heavily soiled it is, by colour, and by material. SWITCH ON THE MAIN ON/OFF SWITCH (ON/OFF) OPEN THE WASHING MACHINE DOOR AND INSERT THE LAUNDRY.
Page 60 WM75.1 ADS AU/NZ en (02-20)
