Summary of Contents for Bosch WQH245B9SN
- Page 1 Tumble dryer WQH245B9SN [en] User manual and installation instructions...
-
Page 2: Table Of Contents
en Table of contents You can find additional information and explanations online. Scan the QR code on the title page. Table of contents Table of contents 1 Safety .......... 3 10.2 Care symbols on the care la- bels .......... 2 5 1.1 General information... -
Page 3: Safety
Safety en 14.7 Intelligent programme recom- 17.2 Condensation container fil- mendation ........ 3 1 ter .......... 3 6 14.8 Remote diagnostics .... 3 2 18 Troubleshooting ...... 3 6 14.9 Data protection ...... 3 2 19 Transportation, storage and 15 Basic settings... -
Page 4: Restriction On User Group
en Safety 1.3 Restriction on user group This appliance may be used by children aged 8 or over and by people who have reduced physical, sensory or mental abilities or inadequate experience and/or knowledge, provided that they are supervised or have been instructed on how to use the appliance safely and have understood the resulting dangers. - Page 5 Safety en Never let the power cord come into contact with sharp points or edges. Never kink, crush or modify the power cord. WARNING ‒ Risk of fire! It is dangerous to use an extended power cord and non-approved adapters. Do not use extension cables or multiple socket strips. Only use adapters and power cords approved by the manufac- turer.
-
Page 6: Safe Use
en Safety If hoses and power cords have been laid incorrectly, this causes a tripping hazard. Lay hoses and power cords in such a way that there is no risk of tripping. If the appliance is moved by holding onto protruding components, such as the appliance door, the parts may break off. - Page 7 Safety en WARNING ‒ Risk of suffocation! Children may breathe in or swallow small parts, causing them to suffocate. Keep small parts away from children. Do not let children play with small parts. WARNING ‒ Risk of explosion! If there is coal dust or flour in the air around the appliance, this may cause an explosion.
-
Page 8: Safe Cleaning And Maintenance
en Safety Unwashed laundry that has come into contact with solvents, oil, wax, wax remover, paint, grease or stain remover may ignite when drying is in progress. Do not place laundry in this appliance to be dried if the laundry has not been washed first. Rinse the laundry thoroughly with warm water and detergent be- fore drying it in the machine. -
Page 9: Preventing Material Damage
Preventing material damage en If the power cord of this appliance is damaged, it must be re- placed by the manufacturer, the manufacturer's Customer Ser- vice or a similarly qualified person in order to prevent any risk. An ingress of moisture can cause an electric shock. Before cleaning, pull out the mains plug or switch off the fuse in the fuse box. -
Page 10: Environmental Protection And Saving Energy
en Environmental protection and saving energy Foam and foam rubber may deform Do not exceed the programme's or melt during the drying process. maximum load capacity. Pro- Page 21 Do not dry laundry that contains grammes foam or foam rubber. After drying, clean the fluff filter. "Cleaning the fluff filter", Unsuitable cleaning products may Page 27... -
Page 11: Contents Of Package
Installation and connection en Remove any accessories from the If residual water in the appliance drum. freezes, this may cause damage to Close the door. the appliance. Do not install or operate this appli- 4.2 Contents of package ance anywhere that is liable to ex- perience frost or outdoors. -
Page 12: Water Outlet Hose
en Installation and connection Against a wall water outlet hose properly to the connecting piece. Requirements The appliance and the accessory Page 10 have been unpacked. The appliance is installed at the in- stallation location. Pull out the condensation hose from the connecting piece. Do not trap the hoses and power cord between the wall and the appli- ance. -
Page 13: Aligning The Appliance
Installation and connection en Push the water outlet hose as far away quickly and eliminate any as it will go into the connecting blockages. piece. Drainage into a Secure the con- siphon. nection point with a (12-22 mm) hose clamp. Secure the water outlet hose with a hose guide at a height of at least... -
Page 14: Connecting The Appliance To The Electricity Supply
en Installation and connection To align the appliance, turn the ap- All appliance feet must stand firmly pliance feet. Check that the appli- on the ground. ance is level using a spirit level. 4.6 Connecting the appliance to the electricity supply Insert the mains plug of the appli- ance's power cable in a socket nearby. -
Page 15: Familiarising Yourself With Your Appliance
Familiarising yourself with your appliance en 5 Familiarising yourself with your appliance Familiarising yourself with your appliance 5.1 Appliance You can find an overview of the parts of your appliance here. On certain models, specific details such as the colour and shape may differ from those pictured. -
Page 16: Control Panel
en Display 5.2 Control panel You can use the control panel to configure all functions of your appliance and to obtain information about the operating status. tings by pressing the buttons. The ac- Page 21 Programmes tivated settings are highlighted Buttons Page 18 brightly on the display. - Page 17 Display en If a software update is available, you can find further information in the Home Connect app. Example: Display Indicator Description 1 0:40 Expected programme duration or programme time re- maining in hours and minutes. 1 max 9.0 Recommendation for the maximum load capacity for the selected program in kg.
-
Page 18: Buttons
en Buttons Indicator Description Page 20 Gentle) Gentle drying is activated for delicate fabrics. Page 20 4.5 kg Half Half load is activated. load) You can remove or add laundry, and interrupt the current Page 26 programme. Page 28 Empty and insert the condensation container. ... - Page 19 Buttons en Note: Additional functions may be available as a result of software updates. Page 31 If a software update is available, you can find further information in the Home Connect app. Button Selection Description Start Start, cancel or pause the Cancel programme.
- Page 20 en Buttons Button Selection Description Drying Aim The dryness level defines how damp or dry the laundry is after the pro- gramme ends. "Dryness level", Page 29 Anti Crease Activate Activate or deactivate the Deactivate crease-reduction function. Once the programme has ended, the drum moves the laundry at regular in- tervals for 120 minutes to prevent creasing.
-
Page 21: Programmes
Programmes en Button Selection Description gramme for drying the laundry. Note: The washing ma- chine must be compatible with Home Connect. The washing machine and dryer must be connected to your home network and registered in your Home Connect app. Remote Start Activate Activate or deactivate re- Page 31 Deactivate... - Page 22 en Programmes Programme Description Max. load (kg) Dry hard-wearing, heat-resistant fabrics made of cotton or linen. Energy-saving programme. Easy Care Dry items made of synthetic materials or blended fabrics. Dry items made of cotton and synthetics. Bed linen Dry duvet covers, pillowcases and sheets made of cotton.
-
Page 23: Timed Programmes
Programmes en Programme Description Max. load (kg) Note: For optimal drying results, dry a maximum of 5 shirts or 5 blouses at the same time. Once the laundry is dry, iron it or hang it up. The residual moisture is then distrib- uted evenly. -
Page 24: Accessories
en Accessories 9 Accessories Accessories Use original accessories. These have been made especially for your appliance. Tip: Some accessories are available in other colours. Contact customer ser- Page 41 vice. Order number Connection kit To save space, stack the WTZ27510 appliance on a suitable washing machine of the same width and depth and that is from the... -
Page 25: Laundry
Laundry en 10 Laundry 11 Basic operation Laundry Basic operation 10.1 Preparing the laundry 11.1 Switching on the appli- ance ATTENTION Objects remaining in the laundry may Note: If you switch the appliance on damage the laundry and the drum. the first time after you have connec- Remove all items from any pock- ted it to the electrical system, the ets in your laundry before using... -
Page 26: Opening The Door
en Basic operation 11.4 Opening the door Press The display shows the programme Grip under the door handle and duration or the programme end pull on the door. time. After the programme has ended, the display shows: "End". Note: When "Hot" is shown on the display, the appliance cools the laun- dry. -
Page 27: Fluff Filter
Basic operation en 11.11 Fluff filter Remove the fluff from the recess. During drying, fluff from the laundry is collected in the fluff filter. The fluff fil- ter protects the appliance from fluff. Cleaning the fluff filter If the drying programme has finished or the display shows a notification while the appliance is in operation, clean the fluff filter after the pro-... -
Page 28: Condensation Container
en Basic operation cleaning, pour the contents of the If you connect the water outlet hose, container through a filter, e.g. a you do not have to regularly empty coffee filter. the condensation container. "Emptying the condensation con- Dispose of the coffee filter with the tainer", Page 28 household waste in order to pre- vent the water from being contam-... -
Page 29: Dryness Level
Dryness level en Empty the condensation container. Dryness Description level For multi-layered, thick laundry that does not dry readily. For normal, single- layered laundry. For normal, single- layered laundry. The laundry is still slightly damp after the Check the condensation container programme ends. -
Page 30: Childproof Lock
en Childproof lock Press and hold Drying Aim for just its basic settings and monitor its approx. 3 seconds. operating status. The display shows "d:0", "d:1", The Home Connect services are not "d:2" or "d:3". available in every country. The avail- Press Ready to adjust the selec- ability of the Home Connect function ted dryness level from "d:0"... -
Page 31: Deactivating Wi-Fi On The Ap
Home Connect en 14.2 Deactivating Wi-Fi on the 14.5 Resetting the appliance appliance network settings Press and hold Remote Start for Press and hold Remote Start for approx. 3 seconds. approx. 3 seconds. Press Remote Start repeatedly Press Remote Start repeatedly until the display shows "on". until the display shows "rES". -
Page 32: Intelligent Programme Recom
en Basic settings Intelligent programme recom- ted to the Internet, your appliance will transmit the following types of data to mendation the Home Connect server (initial re- Requirements gistration): Your washing machine has the Unique appliance identification Home Connect function. (consisting of appliance codes as Your washing machine and your well as the MAC address of the in- dryer must be connected to your... -
Page 33: Tings
Appliance care en If a software update is available, you 15.2 Changing the basic set- can find further information in the tings Home Connect app. To call up the basic settings, press Basic Settings . The display shows Basic Settings). Use the programme selector to se- lect the required basic setting. -
Page 34: Preparing For Appliance
en Appliance care 16.1 Preparing for appliance Press Basic Settings . Set the programme selector to po- care Page 32 sition 5. Preparing the appliance "CP1" and the programme dura- tion alternate on the display. Requirement: The drum is empty. Press Put the appliance into standby The appliance care programme Page 26 mode. -
Page 35: Cleaning And Servicing
Cleaning and servicing en Set the programme selector to po- stopper from the underside of the Page 32 sition 5. condensation container and insert "CP1" and the programme dura- it into the recess in the top of the Page 34 tion alternate on the display. condensation container. -
Page 36: Condensation Container Fil
en Troubleshooting Open the door. Remove the filter. Clean the moisture sensor with a sponge. Clean the filter under warm, run- ning water. Note: Collect the cleaning water in 17.2 Condensation container a container, e.g. a bucket. After filter cleaning, pour the contents of the container through a filter, e.g. - Page 37 Troubleshooting en WARNING Risk of electric shock! Improper repairs are dangerous. Never make any technical modifications to the appliance or its features. Repairs to the appliance should only be carried out by trained specialist staff. Only use genuine spare parts when repairing the appliance. If the power cord of this appliance is damaged, it must be replaced by the manufacturer, the manufacturer's Customer Service or a similarly qualified person in order to prevent any risk.
- Page 38 en Troubleshooting Fault Cause and troubleshooting "CrE" The basic appliance care programme should be run. Run the basic appliance care programme Page 33 . Fluff filter is soiled. Page 27 Clean the fluff filter. Not a fault. The automatic self-cleaning function rinses the appliance's heat exchanger.
- Page 39 Troubleshooting en Fault Cause and troubleshooting The drying time is too The appliance's ventilation opening is blocked. long. Ensure that the ventilation opening of the appliance is kept clear. Heat exchanger is soiled. Run the basic appliance care programme Page 33 . ...
-
Page 40: Transportation, Storage And Disposal
en Transportation, storage and disposal Fault Cause and troubleshooting Creasing. The laundry lies in the drum for too long after drying. Remove the laundry from the drum as soon as the drying programme has finished. Spread the items of laundry for cooling. Easy Care fabrics have been dried for too long. -
Page 41: Customer Service
Customer Service en Unplug the appliance from the Detailed information about the war- mains. ranty period and the warranty condi- Cut through the power cord. tions in your country is available via Dispose of the appliance in an en- the QR code on the enclosed docu- vironmentally friendly manner. - Page 42 en Consumption values (EU) No 932/2012. The consumption values for this programme that are de- clared on the energy label refer to a moisture content of the laundry of 60%. The values specified for other programmes are indicative only and were de- termined in accordance with the applicable standard EN61121.
-
Page 43: Technical Data
Technical data en Programme Final Load Spin Initial Pro- Energy mois- (kg) speed mois- gramm con- ture (rpm) ture e dura- sump- level level tion tion (h:min) (kWh/ cycle) Cotton + 12.0 1000 2:28 1.27 Cotton + 12.0 1000 1:35 0.70 Cotton + 12.0 2:51... -
Page 44: Information Regarding Free
BSH Hausgeräte GmbH hereby declares that the appliance with Home Connect functionality conforms to the essential requirements and other relevant provi- sions of Directive 2014/53/EU. A detailed RED Declaration of Conformity can be found online at www.bosch- home.com among the additional documents on the product page for your ap- pliance. -
Page 45: Statement Of Compliance For Great Britain
Connectable Products) Regulations to maintain the main functions free of 2023 can be found online at charge until at least 28/02/2034. www.bosch-home.co.uk among the additional documents on the product page for your appliance. Product type This statement of compliance covers... - Page 48 You'll find it here. Expert advice for your Bosch home appliances, help with problems or a repair from Bosch experts. Find out everything about the many ways Bosch can support you: www.bosch-home.com/service Contact data of all countries are listed in the attached service directory.
