    TABLE OF CONTENTS Product Chapter Table of contents 1 General Information 6 Malfunction and maintenance 1.1 Introduction 6.1 Cleaning and upkeep 1.2 Health and safety information 6.1.1 Cleaning the enclosure 1.3 Warnings 6.1.2 Cleaning the measuring window 1.4 Users and operating requirements 6.2 Maintenance 1.5 Intended use 6.2.1 Check functionality...
  • Page 4: General Information

    In this manual you will find all the information about microFlu HC that you need for commissioning. Technical specifications as well as detection limits and the dimensions can be found in chapter 7.
  • Page 5: Health And Safety Information

    Devices that radiate strong electromagnetic waves can influence the measurement data or result in a malfunc- tion of the sensor. Avoid using the following devices in the same room as the TriOS sensor: mobile phones, cordless phones, transmitters/ receivers and other electrical devices that produce electromagnetic waves.
  • Page 6: Warnings

    Make sure that the cable is not run near hot surfaces. • If the sensor cable is damaged, it must be replaced with an original part by TriOS Mess- und Datentechnik GmbH or an authorized TriOS technician.
  • Page 7: Intended Use

    The use of other media can damage the sensor. For the use of the microFlu HC in media other than those specified here, please contact the technical support of TriOS Mess- und Datentechnik GmbH (support@trios.de).
  • Page 8: Introduction

    HC fluorometers are low-cost, submersible miniature fluorometers for highly accurate and selective measurement of polycyclic aromatic hydrocarbons (PAH) and oils. microFlu HC is mainly used to detect leaks. Therefore microFlu HC is perfect for monitoring waters, in which industrial water is discharged or other waters located close to industry.
  • Page 9: Purchased Parts Package

    Filter Lens Photo diodes Essentially, the microFlu HC consists of four parts: a defined light source, a lens system, the optical path, and a detector with equal-light suppression. The arrangement of these parts is represented schematically in the above illustration.
  • Page 10: Fluorescence

    Double-bond electrons are excited more easily, because the p-electrons of the double bond are distributed over both atoms and are therefore not so strongly bound. Molecules with a conjugated double bond are particularly suitable for fluorescence; the electrons are distributed over several atoms and are therefore very easy to excite. D01-030en202409 microFlu HC Manual...
  • Page 11: Commissioning

    5. Voltage output +5 V (optionally +10 V) 6. Current output 4–20 mA 7. Analog ground 8. Not connected Connect the male end of the connecting cable into the connector by making the pins align with the slots of the cable. D01-030en202409 microFlu HC Manual...
  • Page 12: Fixed Cable With M12 Industrial Plug

    3. Voltage output +5 V (optionally +10 V) 4. Analog ground 5. Current output 4–20 mA 6. Not connected 7. Ground 8. Supply voltage +12–24 VDC Ensure correct polarity of the operating voltage, because otherwise the sensor NOTICE may be damaged. D01-030en202409 microFlu HC Manual...
  • Page 13: Interfaces

    3.2.1 Serial interface The microFlu HC provides a line for digital serial communication with a control unit. It is equipped with a con- figurable digital serial interface as RS-485 (also EIA 485). The interface cannot be switched and is already defined when delivered.
  • Page 14: Use

    4.1.3 FlowCell / Bypass With the optional flow cell, the microFlu HC can be installed as a bypass. Together with the flow cell, a panel is available on which the microFlu HC and the flow cell can be easily mounted.
  • Page 15: Cleaning System

    3. Now bring the pressure ring from the cable/connector side onto the microFlu HC. 4. Insert the microFlu HC into the flow cell, making sure that the O-ring does not slip into the FlowCell. 5. Tighten the screw connection (without tools).
  • Page 16: Calibration

    5 Calibration 5.1 Manufacturer calibration All TriOS sensors are delivered calibrated. The calibration factors of the microFlu HC are stored in the sen- sor,meaning all output values are calibrated values. The conversion from the original measurement parameter to the scaled measurement parameter is carried out by means of the following equations.
  • Page 17 A = parameter – offset B = A ∙ Scaling With A as the parameter output that is output by microFlu HC. offset corrected value offset value...
  • Page 18 The offset is also given by the ab- scissa of the straight line (X-axis intersection). For the above example, this means: 90 – 30 scaling factor = 40 – 20 offset = 40 – = 40 – 30 = 10 D01-030en202409 microFlu HC Manual...
  • Page 19 Calibration Measured concentration [µg/L] All TriOS controllers have the ability to set scaling factors and offset values for the measurement parameters. Please refer to the appropriate manual. Customer calibration can be used as a fine adjustment of the sensor for special media and is not intended to replace the manufacturer calibration.
  • Page 20: Malfunction And Maintenance

    Even very low concentrations of hydrochloric acid can damage components made NOTICE of stainless steel. In addition, TriOS Mess- und Datentechnik GmbH cautions against using strong acids, even if the sensor should have a titanium housing. D01-030en202409 microFlu HC Manual...
  • Page 21: Cleaning The Measuring Window

    6.1.2 Cleaning the measuring window You can clean the window with a lint-free cloth, a clean paper towel or a special optical paper from TriOS Mess- und Datentechnik GmbH with a few drops of acetone. Make sure that you do not touch the window surface...
  • Page 22: Technical Data

    70 mW Power supply 12‒24 VDC (± 10 %) Required supervision Typically ≤ 0.5 h/month Calibration / Maintenance interval 24 months Warranty 1 year (EU & US 2 years) *Dependent on the type of oil D01-030en202209 Manual microFlu HC...
  • Page 23 +2...+40 °C ~ +36 °F...+104 °F Relative humidity 0...95%, non-condensing Storage conditions -20...+80 °C ~ -4 °F...+176 °F Relative humidity 0...95%, non-condensing Transport conditions Such as storage conditions Inflow velocity 0,1...10 m/s ~ 0.33 ...33 fps D01-030en202209 Manual microFlu HC...
  • Page 24: External Dimensions

    Technical Data microFlu HC 7.3 External dimensions Version with SubConn see chapter 3.1.1 D01-030en202409 microFlu HC Manual...
  • Page 25 HC Technical Data Version with fixed cable see chapter 3.1.2 D01-030en202409 microFlu HC Manual...
  • Page 26: Accessories

    8.2 TriBox ,ini Digital 2-channel controller Mini controller with two digital sensor inputs and two 4–20 mA outputs. All measurement data and diagnos- tic data can be read out via a built-in web browser. D01-030en202409 microFlu HC Manual...
  • Page 27: Warranty

    Damage due to improper handling and use of the device is not covered by the warranty. • Damage caused by modification or unprofessional attachment of accessories by the customer is not covered by the warranty NOTICE Opening the sensor voids the warranty! D01-030en202409 microFlu HC Manual...
  • Page 28: Customer Service

    HC 10 Customer service If you are having a problem with the sensor, please contact TriOS customer service. We recommend sending the sensor in for maintenance and calibration every 2 years. To do this, please request an RMA number from customer service.
  • Page 29: Contact

    If you have found an error or bug in one of our devices or programs, please let us know: Customer service: support@trios.de General questions / sales: sales@trios.de Website: www.trios.de TriOS Mess- und Datentechnik GmbH Bürgermeister-Brötje-Str. 25 26180 Rastede Germany Tel.: +49 (0) 4402 69670 - 0 Fax:...
  • Page 30: Keyword Index

    Cleaning the measuring window Contact Copyright Customer calibration Customer service M12 industrial plug Manufacturer calibration Measurement principle Declaration of conformity Modbus Detection Limit Dimensions Disposal Nano coating Normal operation Electrical installation Electromagnetic waves Offset Operating requirements Fluorescence D01-030en202409 microFlu HC Manual...
  • Page 31 HC Keyword Index Parameter Warnings Product identification Warranty Purchased parts package Waste Rating plate Reagents Return RMA number Safety instructions Scaling factor Software updates Specifications Structure of the sensor SubConn 8-pin connector Technical specifications User requirements D01-030en202409 microFlu HC Manual...
  • Page 32: Annex

    Bürgermeister-Brötje-Str. 25 D- 26180 Rastede Konformitätserklärung Declaration of Conformity Déclaration de Conformité Die TriOS GmbH bescheinigt die Konformität für das Produkt The TriOS GmbH herewith declares conformity of the product TriOS GmbH déclare la conformité du produit Bezeichnung microFlu HC...
  • Page 33: Modbus Rtu

    Modbus RTU Software version This Modbus protocol refers to software version 1.0.11 and higher. Serial interface In the delivery state, microFlu HC has the following settings for the serial interface (RS485): • Baud rate: 9600 bps • Data bits: 8 •...
  • Page 34 Continuous Mode Register (#101) always contains the stored operating mode. Determines the state of the analog current and voltage output pins. Values: 0: Off Analog Output Mode Uint8 1: 4–20 mA 2: 0–10 V 3: 0–5 V D01-030en202409 microFlu HC Manual...
  • Page 35 Modbus interactions. Attention: After answering this request, the send- Modbus Bit Settings Uint16 er will most likely have to change his Modbus settings or the communication will fail from this point on. D01-030en202409 microFlu HC Manual...
  • Page 36 TriBox3 or similar controller. Configurable value. Used together with the Cus- tom#2 c1 to calculate the user-defined output Custom#2 c0 Float parameter in Custom#2 according to the formula (variant ∙ c1) + c0 D01-030en202409 microFlu HC Manual...
  • Page 37 The measured value. What this value represents depends on what exactly this sensor can meas- ure (see #600). This tab contains the raw result Parameter 1000 Float of the last measurement, without modification by the moving average filter or any offset/scaling settings. D01-030en202409 microFlu HC Manual...
  • Page 38 The sensor name, serial number and firmware version are each answered as a null-terminated ASCII string. Example: O S 0x00 m i c r o F l u 0x00 0 0 A 0x00 1 . 0 . 11 D01-030en202409 microFlu HC Manual...
  • Page 39 HC Annex D01-030en202409 microFlu HC Manual...
  • Page 40 TriOS Mess- und Datentechnik GmbH Bgm.-Brötje-Str. 25 · 26180 Rastede · Germany + 49 (0) 4402 / 69 67 0 - 0 info@trios.de + 49 (0) 4402 / 69 67 0 - 20 www.trios.de...
