  • Page 1 TTurb OPERATING INSTRUCTIONS...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS TTurb Chapter Table of Contents 1 General Information 5 Calibration 1.1 Introduction 5.1 Manufacturer Calibration 1.2 Health and Safety Information 5.2 Customer Calibration 1.3 Warnings 5.2.1 Calibration with TTurbCAL 1.4 Users and Operating Requirements 5.2.2 Calibration with Formazine Standard Solution 1.5 Intended Use...

  • Page 4: General Information

    In this manual, you will find all the information you will need to commission the TTurb sensor. Technical specifi- cations as well as detection limits and the dimensions can be found in chapter 7.

  • Page 5: Health And Safety Information

    Devices that radiate strong electromagnetic waves can influence the measurement data or result in a malfunc- tion of the sensor. Avoid using the following devices in the same room as the TriOS sensor: mobile phones, cordless phones, transmitters/ receivers and other electrical devices that produce electromagnetic waves.

  • Page 6: Warnings

    1.4 User and Operating Requirements The TTurb sensor has been developed for use in industry and science. The target group for the operation of the TTurb sensor is technically skilled staff in plants, sewage treatment plants, water plants and institutes. The use of this device often requires the handling of hazardous substances.

  • Page 7: Disposal Information

    • Drinking water monitoring Use in other media can damage the sensor. For the use of the TTurb sensor in other media than those specified in this manual, please contact the customer service of TriOS Mess- und Datentechnik GmbH (support@trios.

  • Page 8: Introduction

    As an immersion sensor, the TTurb can be used directly in the measuring medium, but is also available in the FlowCell-optimized version for bypass applications. In addition, it is possible to obtain the TTurb directly in a set with the dry-standard TTurbCAL.

  • Page 9: Scope Of Delivery

    Formazine is used internationally as the standard for calibrating turbidity sensors and thus makes them com- parable with each other. Supply cable Status LED Photo diode (detector) Principle of 90° scattered light measurement Display Detector NTU / FNU 90° Scattered Light Emitted Light Light Source Sample D01-070en202211 Manual TTurb...

  • Page 10: Browser

    TTurb 2.4 Browser TTurb is equipped with a web interface, which can be used to configure and calibrate the sensor. For example, offsets and scaling factors can be assigned, interfaces can be configured and further settings can be entered. To access the web interface, you will need the G2 InterfaceBox and an Ethernet-capable device with a web browser, e.g.
  • Page 11 “Measurement” includes the results of the last measurements performed and allows the interval to be set for automatic measurements. The new measurement can be triggered at any time. To do this, press “Measure Now!”. A new measurement will be triggered with the saved settings. D01-070en202211 Manual TTurb...
  • Page 12 Introduction TTurb Scaling factors can be entered for all parameters under , see Chapter 5. Customer Calibration for details. In “Moving average” an average correction for N (number) measured values can be defined. D01-070en202211 Manual TTurb...
  • Page 13 An interval for the automatic measurements can be specified. Please note that the factory setting for automatic measurement is set to “off”. To record data sets, please activate the automatic measurement only under a NOTICE permanent power supply! D01-070en202211 Manual TTurb...
  • Page 14 Peripherals "Peripherals" is used to configure the interface, select a protocol, and change the Modbus address by clicking “Edit“. The factory settings are: Protocol: Modbus RTU Baud rate: 9600 Flow control: None Parity: None Stop bits: 1 D01-070en202211 Manual TTurb...
  • Page 15 This calibration file (config.ini) must be stored and kept safe. Use the “Upload” function to restore a previously downloaded calibration file or to upload a calibration file generated by the customer support of TriOS Mess- und Datentechnik GmbH to the TTurb.

  • Page 16: Commissioning

    The sensor is ready for commissioning as soon as the installation of accessories is complete, it is connected to your control device and the configuration is complete. Ensure correct polarity of the supply voltage, because otherwise the sensor might NOTICE get damaged. D01-070en202211 Manual TTurb...

  • Page 17: Interfaces

    A line is put on the B line. The A-B difference is decisive, where the transmission is most resistant to interactive interference signals. The protocol used is Modbus RTU. A detailed description of the Modbus RTU protocol for TTurb can be found in the annex.

  • Page 18: Use

    TTurb 4 Use TTurb can be operated with all TriOS controllers. Instructions for correct installation can be found in the relevant controller manual. The sensor is automatically detected during the sensor scan after switching on the TriOS controller. If the sensor is operated with the DIN rail module HS 100 or directly with a process control system or SCADA system, the customer is responsible for correct commissioning and programming.

  • Page 19: Operation With Type Approval According To Imo Regulations

    Follow the steps below to install the TTurb into the FlowCell. 1. Remove the pressure ring from the FlowCell. It can easily be opened by hand. 2. First push the O-ring (which is attached to the FlowCell in the bag) onto the TTurb. Next insert the TTurb into the FlowCell.

  • Page 20: Calibration

    For the standard manufacturer calibration, the sensor is calibrated in a big container with Formazine standard. 5.1.2 Calibration for FlowCell use For use in a TriOS FlowCell, the calibration is directly performed in a TriOS FlowCell. The sensor is factory calibrated with Formazine or a polymer traceable to Formazine.

  • Page 21: Calibration With Tturbcal

    Each TTurbCAL generates a specific turbidity signal corresponding to a turbidity concentration in FNU. The ex- act concentration of the TTurbCAL is noted on the ID label. The serial number (TTurb SN) of the corresponding TTurb-1000 is also noted. The figure below shows an example of such a ID label.
  • Page 22 Application with EGC Water Analyzer and TriBox3 The application described here is for the operation of a TTurb-1000 in a TriOS EGC Water Analyzer, which has a special TTurbCAL holder for mounting on a FlowCell for associated TpH-D. The TTurbCAL can also be used without a TpH-D FlowCell or such a holder.
  • Page 23 3. If not already done, stop the water flow in the system and empty the FlowCell. 4. Unscrew the pressure ring of the sensor and remove the TTurb-1000 sensor from the FlowCell. 5. Leave the O-ring and the pressure ring on the TTurb-1000.
  • Page 24 9. If the TTurbCAL is clean and shows no optical defects, place the TTurbCAL on the sensor. The shape of the standard is designed to fit the TTurb perfectly. TTurbCAL will find the correct position on its own, if you slightly press it down on the sensor head. To find the correct position, put the TTurbCAL three times on the sensor head.
  • Page 25 3. When the TTurb has warmed up and both the sensor and the TTurbCAL are free from contamination, you can start checking the TTurb-1000. 4. Hold the sensor in your hand with the head upright and place the TTurbCAL on the TTurb. Note the previous section Nr. 9.

  • Page 26: Calibration With Formazine Standard Solution

    If you do not have a TriBox3, you can check your TTurb-1000 as follows: Set the measuring interval of the TTurb-1000 to 10 seconds (via Web Interface or Modbus) and let the sensor warm up for at least 10 minutes before calibration.

  • Page 27: Malfunction And Maintenance

    Please read the following procedure for your returns. Prior to returning the sensor to TriOS, please contact our technical support to assure a smooth return process and avoid incorrect shipments. You will then receive a numbered RMA form, which you need to complete, sign and return to us.

  • Page 28: Technical Data

    Turbidity as FNU; mg/L; NTU; TSSeq Measuring range 0–100, 0–400, 0–1000 FNU Measurement accuracy ±(5 % + 0.5); max. ±2 FNU 0.5 FNU for TTurb 100 Detection limit 2 FNU for TTurb 400 2 FNU for TTurb 1000 Measurement wavelength...

  • Page 29: External Dimensions

    TTurb Technical Data 7.2 External Dimensions D01-070en202211 Manual TTurb...

  • Page 30: Accessories

    8.3 TTurbCAL The TTurbCAL is a solid standard, which provides an FNU or NTU value for reagent-free calibration of TriOS TTurb sensors. The standard is very easy to use and makes device calibration on site much easier. D01-070en202211 Manual TTurb...

  • Page 31: Warranty

    Damage due to improper handling and use of the device is not covered by the warranty. • Damage resulting from modification or unprofessional attachment of accessories by the customer is not cov- ered by the warranty. NOTICE Opening the sensor voids the warranty! D01-070en202211 Manual TTurb...

  • Page 32: Customer Service

    Customer Service TTurb 10 Customer Service If you are having a problem with the sensor, please contact the TriOS customer service. Technical support contact: support@trios.de Telephone: +49 (0) 4402 69670 - 0 Fax: +49 (0) 4402 69670 - 20 For quick help, please send us the sensor ID number by e-mail.

  • Page 33: Contact

    If you have found an error or bug in one of our devices or programs, please let us know: Customer service: support@trios.de General questions / sales: sales@trios.de Website: www.trios.de TriOS Mess- und Datentechnik GmbH Bürgermeister-Brötje-Str. 25 26180 Rastede Germany Telephone +49 (0) 4402 69670 - 0 Fax:...

  • Page 34: Keyword Index

    Biological safety Intended Use Bypass installation ID label Calibration CE certification Certificates & approvals Cleaning Contact Copyright Customer Service M12 industrial plug Maintenance Measurement Properties Dimensions Disposal Normal Operation Electrical Installation Electromagnetic Waves Operating requirements Flow cell D01-070en202211 Manual TTurb...
  • Page 35 TTurb Keyword Index Product Identification Warnings Warranty Waste Reagents Return RMA number Safety instructions Scope of Delivery Specifications Structure of the sensor Technical Specifications User requirements D01-070en202211 Manual TTurb...

  • Page 36: Annex

    Bürgermeister-Brötje-Str. 25 D- 26180 Rastede Konformitätserklärung Declaration of Conformity Déclaration de Conformité Die TriOS GmbH bescheinigt die Konformität für das Produkt The TriOS GmbH herewith declares conformity of the product TriOS GmbH déclare la conformité du produit Bezeichnung TTurb Product name...

  • Page 37: Type Approval Certificate

    This is to certify: That the Miscellaneous Transmitter with type designation(s) TTurb Issued to TriOS Mess- und Datentechnik GmbH Rastede, Germany is found to comply with DNV rules for classification – Ships, offshore units, and high speed and light craft Application : Product(s) approved by this certificate is/are accepted for installation on all vessels classed by DNV.
  • Page 38 Reference is made to DNV rules for classification of ships Pt.4 Ch.9 Control and monitoring systems. The “TTurb” is found to be in compliance with the requirements of Resolution MEPC.259(68) – “2015 Guidelines for exhaust gas cleaning systems”, Chapter 10.2 “Washwater monitoring” as well as Resolution MEPC.340(77) – “2021 Guidelines for exhaust gas cleaning systems”, Chapter 10.2 “Discharge water monitoring”...
  • Page 39 Periodical assessment is to be performed after 2 years and after 3.5 years. A renewal assessment will be performed at renewal of the certificate. END OF CERTIFICATE Form code: TA 251 Revision: 2021-03 www.dnv.com Page 3 of 3 D01-070en202211 Manual TTurb...

  • Page 40: Modbus Rtu

    The factory default setting of the slave address is 40 (0x28). Access Permissions The R/W column describes the Registers access restrictions. An ‘R’ means it can be read from (0x03), a ‘W’ means it can be written to (0x10). Letter Description Read only Read and Write D01-070en202211 Manual TTurb...
  • Page 41 The time in [10 s] that the currently running Measurement timeout Uint16 measurement process will still require Device serial number Char[10] Serial number of the TTurb sensor. Firmware version Char[10] Version number of the installed firmware. Maximum measurement range (100; 400; Subtype Char[10]...
  • Page 42 Offset factor of the factory calibration Factory calibration – Scaling 6004 Float Scaling factor of the factory calibration. Factory calibration – Square 6006 Float Square factor of the factory calibration. Factory calibration – Timestamp 6008 Uint32 Timestamp of the factory calibration. D01-070en202211 Manual TTurb...
  • Page 43 Uint32 Timestamp of the factory calibration. Write single register (0x06) By writing a value that is not 0x0000 to the following coils / registers, the associated action will be performed by the TTurb. Designation Address Description Trigger measurement A single measurement is taken.
  • Page 44 Signal Overflow Warning during Signal Light measurement. Temporary SIG_OVERFLOW I.e, this bit is set if during a regular measure- Warning ment, if RawSigLight is greater than 32500, and cleared if its smaller or equal. D01-070en202211 Manual TTurb...
  • Page 45 TTurb Annex D01-070en202211 Manual TTurb...
