TMT TXI-500F Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TXI-500F
VER 110
RF MULTI INDICATOR
OWNER'S MANUAL
www.tmteng.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TXI-500F and is the answer not in the manual?

Questions and answers

Related Manuals for TMT TXI-500F

Summary of Contents for TMT TXI-500F

  • Page 1 TXI-500F VER 110 RF MULTI INDICATOR OWNER’S MANUAL www.tmteng.com...

  • Page 2: Warning Definitions

    (4) To improve the product performance, functions can be changed with no notice. (5) Please understand that TMT does not have responsibility for a demand related to loss, lost profit etc. caused by operating the product, regardless of the third clause.

  • Page 3: Table Of Contents

    RF MULTI INDICATOR TXI-500F INDEX 1. Precautions ................4 2. Introduction ................5 3. Installation ................6 4. Description of Panels and Symbols ........7 5. Use of Battery Charger ............9 6. Measurement of Axle Loads ..........10 7. Alphabet Input ..............14 8.

  • Page 4: Precautions

    ◆ products. Use only batteries, chargers, adaptor, and enhancements approved by TMT for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous. For availability of approved enhancements, please check with your dealer.

  • Page 5: Introduction

    RF MULTI INDICATOR TXI-500F 2. Introduction ◆ Portable & watertight case ◆ Indicators for measuring axle ◆ Wireless communication: ZigBee ◆ Weigh-In-Motion and static weighing mode ◆ Built in thermal printer ◆ Memory capacity: 8K vehicles ◆ Standard RS232C ◆ Alert for over loaded vehicle ◆...

  • Page 6: Installation

    RF MULTI INDICATOR TXI-500F 3. Installation Weighing method Description Sequential 2 Axle, 2 Plate Accuracy: ±1~3% (WIM: ±3%) In case of Weigh-In-Motion (WIM), you must [Scale ID] install the dummy pad (longer to the length of Axle 1☞ Left: 1 / Right: 2 the vehicle) back and forth on scale.

  • Page 7: Description Of Panels And Symbols

    RF MULTI INDICATOR TXI-500F 4. Description of Panels and Symbols Name Description Display Display the weight data & message Antenna 3dBi dipole antenna for wireless communication Keypad Ten key and function key Printer Thermal printer USB port USB host port for memory stick...

  • Page 8: Display Specification

    RF MULTI INDICATOR TXI-500F 4.1. Display specification Description Indicates number of scales to be linked or sequence number Example of display (1 scale) (2 scales) (3 scales) (4 scales) (5 scales) (6 scales) (7 scales) (8 scales) (9 scales) (10 scales)

  • Page 9: Keypad Specification

    RF MULTI INDICATOR TXI-500F 4.2. Keypad specification Description Turn on and off the indicator Use to change input value and input data Use to back light on and off Use to change weight unit The scale’s unit is also changes...

  • Page 10: Measurement Of Axle Loads

    RF MULTI INDICATOR TXI-500F 6. Measurement of Axle Loads 6.1. Sequential weighing in static mode Connect scales by wireless Setting F03-0 and F01-2. Initial display → Input the vehicle ID → (For 2 seconds) → Input the item code →...
  • Page 11 RF MULTI INDICATOR TXI-500F 6.2. Sequential weighing in WIM (Weigh-In-Motion) Connect scales by wireless Setting F03-1 and F01-2. Initial display → Input the vehicle ID → (For 2 seconds) → Input the item code → axle weighing (WIM) axle weighing (WIM)
  • Page 12 RF MULTI INDICATOR TXI-500F 6.3. Synchronous weighing method in static mode Connect the scales by wireless (Example: 6 scales) Setting F03-0 and F01-6. Initial display → Input the vehicle ID → (For 2 seconds) → Input the item code →...
  • Page 13 RF MULTI INDICATOR TXI-500F 6.4. Real Time Warning MODE Connect the scales by wireless (Example: 4 scales) Setting F01-4, F06-2 Initial display → Input the vehicle ID → 2000 kg Raise the vehicle is not loaded cargo on the pad.

  • Page 14: Alphabet Input

    RF MULTI INDICATOR TXI-500F 7. Alphabet Input 7.1. Input method English input is similar to the way cellular phone. Erase previous value Enter key Number/English conversion Space key 7.2. Input the vehicle ID You can enter up to 10 characters.
  • Page 15 RF MULTI INDICATOR TXI-500F 7.3. Input the item code You can enter up to 10 characters. Item code is not stored in the memory. For example (“IRON”) Step1: Press and hold key for more 2 seconds, is displayed. ☞ ☞...
  • Page 16 RF MULTI INDICATOR TXI-500F English input wait state English keypad state Delete the previous contents Step1: When the indicator is power off press key while pressing key, “ EDIT” is displayed. key, “ DELETE” is displayed and delete the previous contents.

  • Page 17: Calling The Saved Data

    RF MULTI INDICATOR TXI-500F 8. Calling the Saved Data key in the weight mode and “ 1 - 5” is displayed. Press Refer to the call method of the downside and press key. Call the date Input the year and date→...
  • Page 18 RF MULTI INDICATOR TXI-500F 8.1. Print form (Please refer to print form of page 30.) 8.2. PC data format ◊ 1~20 byte [Data & time] [Serial number] ◊ 21~41 [Vehicle ID] [Item code] ◊ 42~62 [Axle 1 weight: left / right / sum] ◊...

  • Page 19: Initialization Of Memory

    RF MULTI INDICATOR TXI-500F 9. Initialization of Memory It is used to initialize the data stored in the weight mode. Stored data: Date, Time, Serial number, Item code, Vehicle ID and Weight. When the indicator is power off press key while pressing key, Then this mode is started.

  • Page 20: Setting Mode

    RF MULTI INDICATOR TXI-500F 11. Setting Mode 11.1. How to enter When the display is off, press key while pressing the key. Step 1. At this time, “F01” is shown on the display after “SET” message. At this point, If you press key exit the mode.
  • Page 21 RF MULTI INDICATOR TXI-500F ◊ F04: Backlight conditions (0~2) ▶ Initial value: 0 Value Description Manual ON/OFF Automatic ON/OFF (Weighing: ON / Zero: OFF) Always ON ◊ F05: Backlight brightness level control (0~9) ▶ Initial value: 9 Value Description The brightness of the backlight is adjusted depending on this parameter.
  • Page 22 RF MULTI INDICATOR TXI-500F ◊ F07: Print format (0~3) ▶ Initial value: 0 Value Description Standard Standard + Left-Right balance Standard + Inspector and Driver Standard + Left-Right balance + Inspector and Driver Customer details (Max. 5 lines – 120 characters)
  • Page 23 RF MULTI INDICATOR TXI-500F ◊ F10: Enable printer (0,1) ▶ Initial value: 1 Value Description Not used printer Used printer ◊ F11: Baud rate for RS232C port (0~5) ▶ Initial value: 2 Value Description 2400 bps 4800 bps Only send to RS232C port.
  • Page 24 RF MULTI INDICATOR TXI-500F ◊ F14: RS232C output (0~3) ▶ Initial value: 0 Value Description Not used Stream mode (Send the weight of each scales) Press key (6.1-step13, 6.2-step11, 6.3-step8) to send the data Stream mode (Depend on the setting of F13) F14-1: Send a scale data 1 ☞...
  • Page 25 RF MULTI INDICATOR TXI-500F ◊ F18: Auto weighing stable time (0~9) ▶ Initial value: 0 Value Description Not used 5 second stable state, the automatic accumulate the weighing 9 second stable state, the automatic accumulate the weighing Setting F01-2. ◊ F19: Auto print time (1~9) ▶ Initial value: 2...

  • Page 26: Test Mode

    RF MULTI INDICATOR TXI-500F 12. Test Mode 12.1. How to enter When the display is off, press key while pressing the key. Step 1. At this time, “TEST1” is shown on the display after “TEST” message. At this point, If you press key exit the mode.
  • Page 27 RF MULTI INDICATOR TXI-500F ◊ TEST 5: Memory test Display Description MEMORY key, and then “GOOD” is displayed. Press GOOD If flash memory has failed, “ERROR” is displayed. ◊ TEST 6: Real time clock Display Description 123056 Make sure the real time clock is goes. (12:30:56 PM) ◊...

  • Page 28: Rs-232C Interface

    RF MULTI INDICATOR TXI-500F 13. RS-232C Interface 13.1. Specifications ◊ Method: Full-duplex, asynchronous transmission format ◊ Baud rate: 2400, 4800, 9600, 19200, 38400 bps ◊ Data bit: 7, 8 bits ◊ Parity bit: Even or Odd (For 7 data bits) or Non parity (For 8 data bits) ◊...
  • Page 29 RF MULTI INDICATOR TXI-500F ② Setting mode F14-3 ◊ Format 1 (F13-0, 22bytes) Header 1 Header 2 Fixed Data Unit Terminator , G S , 1 8 2 2 0 Stable weight data (0x53) (0x54) Unstable weight data (0x55) (0x53)

  • Page 30: Usb Interface

    RF MULTI INDICATOR TXI-500F 14. USB Interface The USB host option is for sending the weight data to USB memory. When you print weighing data, it is stored to USB memory stick. If an error occurs at the time of storage, “CH 04” is displayed.

  • Page 31: Data Capacity

    RF MULTI INDICATOR TXI-500F Example: TEST.csv (Comma separated value - Excel file format) 14.3. Data capacity ◊ In case of 1G memory stick: Approx. 5,900,000 data - 31 -...

  • Page 32: Replacing The Paper Roll

    RF MULTI INDICATOR TXI-500F 15. Replacing the Paper Roll Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer cannot detect the paper end correctly.
  • Page 33 RF MULTI INDICATOR TXI-500F Step 5. Pull out a small amount of paper, as shown. Then close the cover. When closing the cover, Press the center of printer cover firmly to prevent paper miss-loading Step 6. Tear off the paper as shown.

  • Page 34: Specifications

    RF MULTI INDICATOR TXI-500F 16. Specifications General specifications ◆ Display 6 digit FSTN LCD (Height: 20mm) Backlight Amber LED backlight Operating temperature -20℃ ~ 60℃ Operating humidity 85% R.H. (No condensation) Net weight Approx. 4.2kg 10A lead-acid battery Power AC/DC Adapter 12V Charging adapter Approx.
  • Page 35 RF MULTI INDICATOR TXI-500F Wireless specifications ◆ Wireless method ZigBee RF frequency range 2400 ~ 2483.5 MHz Output power Max. 4dBm Channel width 2 MHz Frequency offset < ±30ppm Transmit data rate 250Kbps,500Kbps Receiver sensitivity -99dBm (PER <1%) Maximum input level...

  • Page 36: Check Message

    RF MULTI INDICATOR TXI-500F 17. Check Message Code Description Something wrong in printer. CH 03 Please check printer and contact us to resolve this technical problem. Something wrong in USB port. CH 04 Please check your memory stick. FAT32-formatted memory stick must be used.
