Summary of Contents for Simmons 119502C

  • Page 1 Trail Camera Instruction Manual Model #: 119502C/119504C 05-18...

  • Page 2: Important Note

    Do not mix old and new batteries. Do not mix battery types-use ALL lithium or ALL alkaline. Rechargeable batteries are NOT recommended. Simmons® recommends using SanDisk ® SD and SDHC Cards (up to 32GB capacity) in this Simmons trail camera.

  • Page 3: Parts And Controls

    (10MP resolution, depending on model), or video clips (720p, 10 seconds length). The Simmons Trail Camera consumes very little power (< 0.5mA) in a stand-by (surveillance) state. This means it can deliver up to six months stand-by operation time when the...
  • Page 4 Fig. 1 Lens Display Light AIM/Status Sensor “Up” Key Power/ Mode “OK” Key Switch “Down” (ON/AIM/OFF) Sensor Battery Tray Eject Button Fig. 3 Eject Button Fig. 2 Card Slot...

  • Page 5: Installing Batteries And Sd Card

    INSTALLING BATTERIES and SD CARD Before you begin to use your Simmons Trail Camera, you will first need to install a set of batteries and insert an SD card. Although that may only take you a minute, there are some...

  • Page 6: Setup Mode

    There are only a few settings to make, so the process is quick and easy. To start setting up your Simmons Trail Camera: To enter Setup Mode, move the Power Switch to the middle (AIM) position (Fig.
  • Page 7 SETUP MODE Fig. 4 Fig. 5 Fig. 6 Fig. 7 Fig. 8 Fig. 9 Fig. 10 Fig. 11...
  • Page 8 Setting Time and Date (Fig. 6) After the Initial Setup screen, the next few display screens will allow you to set the current time and date, so the time/date stamp imprinted on all your photos and videos will be accurate when captured by the camera.
  • Page 9 When setting up the Simmons Trail Camera for scouting game or other outdoor applications, you must be sure to mount it in place correctly and securely.
  • Page 10 Using the adjustable web belt: Push one end of the belt through the two brackets on the back of the Simmons Trail Camera (Fig. 12). Thread the end of the strap through the buckle. Fasten the belt securely around the tree trunk by pulling the end of the strap firmly so there is no slack left.
  • Page 11 AIM). SAVING/VIEWING THE FILES ON YOUR COMPUTER After you have setup, mounted and activated your Simmons Trail Camera, you will of course be eager to return later and review the images it has captured for you. The best way to do...
  • Page 12 The same card can then be returned to your Simmons Trail Camera for future use. Use the format feature in Setup Mode to erase the entire card if you want to have its full capacity available to store as many images as possible before it becomes full and you need to go through this remove >...

  • Page 13: Troubleshooting (Faq)

    If the camera continues to take images with no subject, then there is probably an electronic component issue. If this is the case, please contact Simmons customer service to send the camera back for repair. Battery life is shorter than expected Battery life will vary with operating temperature and the number of images taken over time.
  • Page 14 If you have used an SD card in another device before inserting it in your Simmons Trail Camera, you might want to try formatting the card using the “Format” option in Setup Mode (pg. 9). Make sure you have backed up any important files first, as formatting will erase all previous files.
  • Page 15 Under certain lighting conditions, the sensor can become confused resulting in poor color images. b). If this is seen on a consistent basis, then the sensor may need servicing. Please contact Simmons customer service. 7. Video clips are too short/end prematurely a) Check to make sure that the SD card is not full (display reads FULL).
  • Page 16 Mode (pg. 8). 2. Check that the batteries still have adequate power levels. Always replace all batteries at the same time. Photos Do Not Capture Subject of Interest 1. Try to set your camera up in an area where there is not a heat source in the camera’s line of sight.

  • Page 17: Technical Specifications

    Model Number 119502C / 119504C Image Sensor Type/ CMOS, 2 million pixels Resolution Image Resolution- 10MP (119502C, 119504C) * Photo Mode Lens Angular Field of View 47 degrees (+/- 2 degrees) PIR Sensor Yes, auto sensitivity Trigger Speed (photo) 1.0 second Trigger Speed (video) <3.0 seconds...

  • Page 18: One-Year Limited Warranty

    ONE YEAR LIMITED WARRANTY Your Simmons product is warranted to be free of defects in materials and workmanship for one year after the date of purchase. In the event of a defect under this warranty, we will, at our option, repair or replace the product, provided that you return the product postage prepaid.
  • Page 19 FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...
  • Page 20 For further questions or additional information please contact: Simmons 9200 Cody Overland Park, KS 66214 1-800-423-3537 www.simmonsoptics.com ©2018 B.O.P.
