Summary of Contents for MechMaxx ATV120
- Page 1 WARRANTY Operator’s Manual www. mechmaxx.com...
-
Page 3: Table Of Contents
INSTRUCTION&WARNING DECALS OPERATING INSTRUCTIONS AND ADJUSTMENTS INITIAL CHECK DRAWBAR ADJUSTMENT TO ADJUST QUICK OFFSET DRAWBAR MOWER CUTTING HEIGHT CUTTING HEIGHT ADJUSTMENT: STARTING THE ENGINE FORWARD SPEED STOPPING THE MOWER STOPPING THE MOWER ANTI-SCALPING ROLLER/SIDE SKIDS www. mechmaxx.com TABLE OF CONTENTS... -
Page 4: Specifications
SPECIFICATIONS Model ATV120 Engine DUCAR DH420E 420cc/15hp Electric Start Gasoline Engine Working Width 48 in Overall Width 72 in Cutting Height 0.4-2.5 in Number of Blades Blade Type Hammers Size of Blades 4x2.6 in Blade Weight 0.8 lbs Blade Material... -
Page 5: Safety Signs
Do not open or remove safety shields while parts. engine is running. HIGH PRESSURE FLUID HAZARD Relieve pressure before disconnecting lines. Do Not use hands to check for leaks. Consult physician immediatly if skin ROTATING penetration occurs. BLADES KEEP HANDS AWAY www. mechmaxx.com SAFETY SIGNS... -
Page 6: Introduction
ATV for braked trailed equipment Note:Universal road going trailers will normally have the and 2 x unladen weight of the ATV for unbraked trailed equipment are the appropriate maximum retios. maximum gross weight stated on a separate notice. www. mechmaxx.com INTRODUCTION... -
Page 7: Mounted Equipment
• four-wheel driver will give better traction and mobility and may provide a margin of safety; • Choose a safe route; • Be aware that increased speed greatly increases the risk of instability and the risk of an overturn; www. mechmaxx.com INTRODUCTION... -
Page 8: Safety
2. DO–Ensure all spectators are a safe distance away support stands when operating. • DO NOT allow any persons to ride on the 3. DO–Carry out regular servicing and checks before use. equipment 4. DO–Clear cutting area from potential damaging compo- nents. www. mechmaxx.com SAFETY... -
Page 9: Operating Instructions And Adjustments
TO ADJUST 1. Unlock the locking nut (A) 2. Lengthen the link to lower the front of the deck or shorten to raise the deck. 3. Once the deck is level, re-tighten locking nut (A). www. mechmaxx.com OPERATING INSTRUCTIONS AND ADJUSTMENTS... -
Page 10: Starting The Engine
Never move from one site to another with the engine most cases.Ensure you follow the procedure below. running. Please note the AT – Flail Mower is not road legal, and should not be used on public roadways www. mechmaxx.com OPERATING INSTRUCTIONS AND ADJUSTMENTS... -
Page 11: Anti-Scalping Roller/Side Skids
Front of the skid and the rear of the skid (Shown as “C”) Select new setting, replace the bolts and tighten. Repeat for the oppo- site skid; always ensure both skids are set to ASSEMBLY www. mechmaxx.com OPERATING INSTRUCTIONS AND ADJUSTMENTS... -
Page 12: Maintenance
Oil 1.96 in coupling Swivel hitch Bush Wear Check All Fastener’s are tight and intact Safety Chain Guard inspection Safety Decals intact Safety Guards Intact Check Blade wear / condition Check Metal Fatigue Clutch Wear / Function www. mechmaxx.com MAINTENANCE... -
Page 13: Engine
To check the bearings, try to move the wheel from left to right and feel for any play in the bearings, ensure the wheel-locating bolt is tight before you start and follow any jacking procedures. If any www. mechmaxx.com MAINTENANCE... - Page 14 C. Replace shackle bolt securely, but still allowing the shackle to swing on the fixing bush. NOTE:Never use cracked or repaired shackles when replacing knives. If the shackle fixing has become damaged or worn, replace with new parts www. mechmaxx.com MAINTENANCE...
-
Page 15: Parts Diagram
PARTS DIAGRAM www. mechmaxx.com PARTS DIAGRAM... -
Page 16: Parts List
Lock Nut M8 15HP engine Bolt M8*80 Down pulley Battery Power lock 35*60 washer Bushing for oil seal bearing 16005 Spring washer 12 tension roller Bearing UC207 tension roller weldment Gearse nipple M8*1 Square Rubber cOVER www. mechmaxx.com PARTS LIST... - Page 17 Washer 16 Locking nut M16 Connection bar Bolt M16*60 Linkage weledment Spring Connection bar A Bush Bolt M12*70 trailer bar Mower Deck Lock Nut M10 Washer 10 Bolt M10*45 Bolt 3/8-24UNC×35 Big wash 12 Bolt M8*25 www. mechmaxx.com PARTS LIST...
