Page 1: Table Of Contents
GAS FLOOR FURNACES CONTENTS GENERAL INFORMATION Page 2 Page 3 DESCRIPTION Page 3 TECHNICAL INFORMATION Page 3 TRANSPORTATION Page 4 PACKAGE INSTALLATION Page 4 GENERAL WARNINGS Page 5 USING THE DEVICE Page 6 CLEANING and MAINTENANCE Page 7 TROUBLESHOOTING Page 8 INJECTOR CHANGE AND GAS ADJUSTMENT Page 9 GAS CONNECTION PICTURES... -
Page 2: Ageneral Information
GAS FLOOR FURNACESYER OCAKLARI GENERAL INFORMATION PLEASE READ THE OPERATING AND MAINTENANCE INSTRUCTIONS CAREFULLY BEFORE INSTALLING THIS DEVICE. IMPROPER INSTALLATION AND REPLACEMENT OF PARTS MAY DAMAGE THE PRODUCT OR CAUSE INJURY TO PERSONS. OUR COMPANY IS NOT RESPONSIBLE FOR INTENTIONAL DAMAGE TO THE DEVICE, DAMAGES CAUSED BY NEGLIGENCE, FAILURE TO COMPLY WITH THE INSTRUCTIONS AND REGULATIONS, OR INCORRECT CONNECTIONS. -
Page 3: A1 Description
GAS FLOOR FURNACES DESCRIPTION *This high-efficiency device is a professional floor stove produced for use in industrial kitchens. Packaging Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.YRG.60 600x800x500 EMP.YRG.80 700x915x560 TECHNICAL INFORMATION Power Code Model Consumption Consumption ( Kw ) -
Page 4: Transportation
GAS FLOOR FURNACESYER OCAKLARI TRANSPORT *This device cannot be handheld. Therefore, use a lifting vehicle (forklift or pallet truck) to transport the device. (The lifting arms of the forklift or pallet truck must reach more than half of the bottom of the device). OPENING THE A4 PACKAGE *The device must be opened and its packaging must be destroyed in accordance with the regulations in the country of use. -
Page 5: Cgeneral Warnings
GAS FLOOR FURNACES GENERAL WARNINGS *Do not use the device in facilities without adequate lighting. *Do not touch any moving parts while using the device. *Do not install the device near flammable or explosive materials. *Do not operate the device idle. *Do not load too much below or above the capacity of the device. - Page 6 GAS FLOOR FURNACESYER OCAKLARI USE OF THE DEVICE *Control Panel : A: Opening and closing B: Lighter A: full flame position D : Half flame position *Use of: • Turn the stove gas button to the on position by pressing it inward and ignite the stove in the pressed position.
-
Page 7: Ecleaning And Maintenance
GAS FLOOR FURNACES CLEANING and MAINTENANCE ➢ What to Do After Each Use: • Before cleaning the device, disconnect the gas connection. • Clean the outer surface of the device with a damp cloth or chrome polisher. • Do not use acid or similar materials when cleaning the device. •... -
Page 8: Ftroubleshooting
GAS FLOOR FURNACESYER OCAKLARI TROUBLESHOOTING Check whether the gas connection of the device is made . If there is no gas flow to the pilots, the THE DEVICE DOES NOT WORK device will not work . the gas inlet hoses leak gas due to tears, holes , etc. -
Page 9: Ginjector Change And Gas Adjustment
GAS FLOOR FURNACES INJECTOR CHANGE AND GAS ADJUSTMENT FLOOR FURNACES BURNER - INJECTOR CHANGE TABLE SMALL Pilot Gas Family injector mm injector mm injector mm 2.40 3.00 0.41 0.41 30 mbar 1.20 1.70 0.22 50mbar 0.20 37 mbar 0.22 50mbar 0.20 Replacement of Burner Injectors;... - Page 10 GAS FLOOR FURNACESYER OCAKLARI GAS CONNECTION PICTURES Figure 1) (Figure 2)
-
Page 11: Hgas Connection Pictures
GAS FLOOR FURNACES GAS CONNECTION PICTURES Figure 3... - Page 12 GAS FLOOR FURNACESYER OCAKLARI SPARE PARTS LIST - DISASSEMBLED VIEW EMP.YRG.60...
-
Page 13: Ispare Parts List - Disassembled View
GAS FLOOR FURNACES SPARE PARTS LIST - DISASSEMBLED VIEW PRODUCT CODE: EMP.YRG60 NAME OF THE PRODUCT U.CODE NO:5 BURNER M.GAZ-BRL-BEK-005 3/8 16*1.5 M.8 0.75 L ELBOW M.GAZ-TES-SRI-023 YRG.60 CASTING FURNACE M.AKS-DKM-KZN-009 CHASSIS M8*1200 MM NO:19 THERMOCOUPLE M.GAZ-TRL-005 INJECTOR M8*0.75 Ø 2.50 MM. M.GAZ-ENJ-NG-008 BUTTON BUMPER M.AKS-DGM-EMP-016... - Page 14 GAS FLOOR FURNACESYER OCAKLARI SPARE PARTS LIST - DISASSEMBLED VIEW EMP.YRG.80...
- Page 15 GAS FLOOR FURNACES SPARE PARTS LIST - DISASSEMBLED VIEW PRODUCT CODE: EMP.YRG80 NAME OF THE PRODUCT U.CODE BURNER M.GAZ-BRL-DKM-005 INJECTOR M8*0, 75 Ø 1.20 MM. M.GAZ-ENJ-LPG-011 3/8 16*1.5 M.8 0.75 L ELBOW M.GAZ-TES-SRI-023 M8*1200 MM NO:19 THERMOCOUPLE M.GAZ-TRL-005 T PIPE 3/8-3/8-3/8 (M16*1.5) 301021326 M.GAZ-TES-SRI-004 INJECTOR M8*0.75 Ø...
