Page 2
Laurent End Table Model #10507 PARTS INCLUDED Please confirm all parts are available before starting assembly. HARDWARE INCLUDED Please confirm all hardware are available before starting assembly. Qty. Ref. Bolts 1/4 x 60 mm Hex Key...
Page 3
Laurent End Table Model #10507 Place the top assembly upside down and remove the dowels, Figure 1 and then pull out the drawer. Clean surface Figure 2 Fasten the legs with ( 8 ) bolts ( A ) and hex key ( B ).
Page 4
Laurent End Table Model #10507 Figure 3 Fasten the shelf to the legs with ( 4 ) bolts ( A ) and hex key ( B ). Ask for another set of hands to help hold the shelf while the bolts are inserted.
