- Page 1 40” 5K2K ULTRA WIDE GAMING MONITOR INSTRUCTION MANUAL PLEASE READ THIS MANUAL THOROUGHLY BEFORE USE AND KEEP IT HANDY FOR FUTURE REFERENCE 5K2K 120 Hz 1 MS MPRT 5120x2160 COMPATIBLE...
-
Page 2: Table Of Contents
TABLE OF CONTENTS GENERAL INFORMATION PRODUCT DESCRIPTION AND TYPE OF USE GENERAL FEATURES OPENING THE BOX CONTENTS OF THE BOX WARNINGS POWER SAFETY PRECAUTIONS INSTALLATION PRECAUTIONS CLEANING THE DEVICE PRIVACY & COPYRIGHT INTERFACES, CONTROLS & SETTINGS MONITOR INPUTS ACCESSOIRIES CONTROL PANEL INITIAL SETUP MENU OPTIONS OSD MENU... -
Page 3: General Information
GENERAL INFORMATION Dear Customer, Thank you for having purchased this product. This document describes how to install and use the LCD color monitor. Read this manual which contains information for correct, safe use carefully. Keep this manual at hand so that you can refer to it when needed. PRODUCT DESCRIPTION AND TYPE OF USE The LCD color monitor presents a very rugged structure. -
Page 4: Warnings
WARNINGS POWER • Only use the power unit provided to power the device. Check mains rating before plugging the power unit in. • Do not pull the cable to unplug the device. SAFETY PRECAUTIONS • Keep the device away from rain and humidity to prevent risk of fire and electrocution. Do not introduce material (solid or liquid) inside. -
Page 5: Cleaning The Device
CLEANING THE DEVICE • Rub delicately with a dry cloth to remove dust and dirt. • Dip the cloth in neutral detergent if dirt cannot be eliminated with a dry cloth alone. • Do not use volatile liquids (such a petrol, alcohol, solvents, etc.) or chemically treated clothes to clean the device to prevent deformation, deterioration or scratches to the paint finish. -
Page 6: Accessoiries
ACCESSOIRIES The package includes: 40 INCH MONITOR STAND USB-C CABLE DP CABLE USB-A TO B CABLE POWER ADAPTER AND POWER CABLE USER MANUAL... -
Page 7: Control Panel
CONTROL PANEL The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. ● ● Click to boot, click to enter the navigation menu Click to boot, click to enter the navigation menu When the navigation menu is displayed, press the left button to When the navigation menu is displayed, press the left button to enter the enter the signal source, and press the right button to enter the menu... -
Page 8: Initial Setup
INITIAL SETUP Connect the monitor to a power outlet. 1. Press the POWER button on the monitor or to turn it on (The indicator will be blue). 2. Connect the relevant cable to the corresponding input on the monitor. The source will be automatically detected. 3. -
Page 9: Osd Menu
OSD MENU A. INPUT SOURCE 5120x2160@120Hz Type-C HDMI1 Setting Setting HDMI2 Multi-Window 5120x2160@120Hz Switch the signal input to Type-c, DP, HDMI1, HDMI2 or have the monitor Auto Select the source. B. BRIGHTNESS/CONTRAST 5120x2160@120Hz Brightness Contrast Setting Setting Multi-Window 5120x2160@120Hz Brightness: Change the display brightness value from 0 to 100. Contrast: Adjust the display contrast value from 0 to 100. -
Page 10: Color Settings
C. COLOR SETTINGS OLOR SETTINGS 5120x2160@120Hz Gamma Picture Mode Standard Color Temperature Normal Setting Setting Saturation Low Blue Light Multi-Window 5120x2160@120Hz Gamma: Change the display Gamma value to: 1.8,2.0,2.2,2.4,2.6. Pirture Mode: Change the pre-set mode to: Standard, Photo, Game, Movie, RTS or FPS. Color Temperature: Change the color temperature to:Normal,Warm,Cool,User. -
Page 11: Picture Quality Settings
D. ADVANCE 5120x2160@120Hz Sharpness Response Time Setting Setting Multi-Window 5120x2160@120Hz Sharpness: Change the display Sharpness value from 0 to 100. Response Time: Select the Response Time Value from Low,Middle,High or turn it Off. -
Page 12: Display
E. DISPLAY 5120x2160@120Hz Aspect Ratio Wide Screen Setting Setting Multi-Window 5120x2160@120Hz Aspect Ratio: Change the image aspect ratio to Full Screen,Auto,4:3 or 1:1. F. AUDIO 5120x2160@120Hz 5120x1440@144Hz Mute Mute Volume Volume Setting Audio Source Setting Audio Source Setting Setting Multi-Window Multi-Window 5120x210@120Hz Window2:... -
Page 13: Multi-Window
G. MULTI-WINDOW 5120x2160@120Hz Multi-Window Sub Win2 Input PIP Size Medium Setting Setting PIP Position TopRight Swap Multi-Window 5120x2160@120Hz Multi-Window: Turn the Multi-Window feature On or Off. Sub Win2 Input: Select the PIP input source. PIP Size: Select the PIP Size Value from Small, Medium, Large. PIP Position: Select the PIP Position Value from Top Right, Top Left, Bottom Left, Bottom Right, Mid. -
Page 14: Other
I. OTHER THER 5120x1440@144Hz FreeSync(Adaptive Sync) Setting MPRT Setting USB Update FW Flicker Free Reset Multi-Window 5120x1440@144Hz FreeSync: Turn FreeSync On or Off. HDR: Turn HDR On or Off. MPRT: Turn MPRT On or Off. KVM: Allows control of multiple computer hosts USB Update FW: Run the firmware update. -
Page 15: Product Specifications
PRODUCT SPECIFICATIONS Model: 40” 5K2K ULTRA WIDE GAMING MONITOR Resolution: 5120 x 2160 Refresh rate: 120Hz Brightness (MAX): 300cd/m2 Respons time: 1Ms MPRT PANEL Aspect ratio: 16:9 Viewing Angle: 178° (H) / 178° (V) Display Color: 1.07B 10 bit(8bit+FRC) Freesync:...
