- Page 1 MANUAL MagRack T2 Wheel Mount Rack...
- Page 2 Caution Pay attention to the overall vehicle length and driving safety after installation. Ensure it is securely tightened. Forward travel direction Not suitable for tandems or recumbents. Max 100 lbs Suitable for receivers with a distance greater than 1.5 inches (3.8 cm) for X...
- Page 3 Parts for rack Tire locking slider(Upper part) X4 Hitch base bracket X1 Tire locking slider(Lower part) X4 Wheel mount bracket(Left) X2 M6 Low square neck bolt X4 M6 Lock nut with handle X4 Wheel mount bracket(Right) X2 M8 Low square neck bolt X8 Securing rod X8 M8 Lock nut X8 Parts for tools...
- Page 4 Step 1 Open the switch and insert the base bracket until the spring buckle clicks into place. Pinch and press the handle, and use Lock the base. the hex to tighten the base.
- Page 5 Step 2 Press and hold the button to lift the tire pressure lever. Use M6 bolts to install the Tire Locking Slider.
- Page 6 Use M8 bolts to pass through the Securing Rod. Push and reset the tire pressure lever.
- Page 7 Step 3 Hold the folding handle and lower the base. Secure the rack with M8 lock nut.
- Page 8 Use the wrench to tighten the screws. Notice Ensure tightening to prevent the frame from shaking.
- Page 9 How to load the bike Press the button to release the tire pressure lever. Lift the bicycle onto the rack. Notice: If you have two bicycles, place the one closest to the vehicle on the rack first.
- Page 10 Loosen the handle.
- Page 11 Tighten the handle. Push the tire pressure lever inward until it presses the tire firmly and clicks into place.
- Page 12 Notice When placing two bicycles, ensure they are positioned in opposite directions.
- Page 13 How to remove the bike Press the button to release the pressure lever. Remove the bicycle from the rack.
- Page 14 Reset the tire pressure lever. Notice The trunk can be opened normally. Fold it away when not in use.
- Page 15 How to disassemble the rack Use the hex to Loosen the base. Unlock the base. Open and hold the switch, then pull the rack outward.
- Page 16 Dimensions 10.8” 12.2” 59.6” 32.8” Specs Application: 2" x 2" trailer hitch receivers Carrying capacity: 2 bikes Weight capacity: 50 lbs per bike Maximum tire width: 3.0" Maximum wheelbase: 48" Wheel diameter: 18" to 29" Rack weight: 55 lbs Material: steel Bicycle anti-theft: Yes Bike racks anti-theft: Yes Tilt function (with bikes): Yes...
- Page 17 WARNINGS ●Do not overload beyond the bike rack’s weight capacity of 100lbs. ●Do not carry more than 2 bike on the carrier. ●The bike rack is not intended for transporting humans or animals. ●If you are planning to load only one bike, it is recommended to place it in the position closest to the vehicle.
- Page 18 CRAVOT Warranty Policy Thank you for choosing CRAVOT. We are committed to providing you with quality products and exceptional service. This Limited Warranty Policy outlines the terms and conditions of our warranty support, including con- siderations for varying state laws in the United States and important dis- claimers.
- Page 19 ● Disclaimer of Liability It is crucial to follow the instructions provided in the product manual for proper use. CRAVOT is not responsible for any damages or losses result- ing from improper operation or handling of the product. This disclaimer of liability includes but is not limited to personal injury, damage to property, or any other losses incurred due to non-compliance with the provided instructions.
- Page 20 THANK YOU FOR CHOOSING A CRAVOT BIKE RACK! ● The CRAVOT Bike racks are meticulously designed to ensure stability and safety when hitching your bikes. Prior to assembly, carefully read through this Owner’s Manual, as it provides essential information for both assembly and adjustment.
- Page 22 VERSION:WRA0202240708...
