- Page 1 MANUAL MagRack T1 Roof Bike Rack...
- Page 2 Caution All roof-mounted equipment must be removed before entering an Beware of height restrictions after loading. automatic car wash. When placing bicycles side by side on the roof, secure them in opposite directions. Max 45 lbs Not suitable for bicycles with fenders. Maximum load capacity: 45 lbs...
- Page 3 Parts for rack M8 Low square neck bolt X4 Wheel mount bracket(Left) X1 M8 Lock nut X4 M6 Low square neck bolt x2 Wheel mount bracket(Right) X1 M6 Lock nut with handle x10 Tire locking slider(Upper part) x2 U-Bolts clamp x4 Tire locking slider(Lower part) x2 Securing rod x4 T Slot Bolts clamp x4...
- Page 4 Step 1 Press and hold the button to lift the tire pressure lever. Use M6 bolts to install the Tire Locking Slider.
- Page 5 Step 2 Use M8 bolts to pass through the Securing Rod. Push and reset the tire pressure lever. Use the wrench to secure with M8 lock nut.
- Page 6 Step 3 Notice If your rack is compatible with U-Bolts Clamp installation, please skip to page 8. Lift the tire pressure lever and use T Slot Bolts Clamp through the holes on the cargo carrier, secure with M6 Lock nut with handle, and maintain a screw spacing of no less than 0.12 inches (3mm).
- Page 7 Align the T Slot Bolts Clamp with the rack slots and push it in. Notice Ensure the Tire Locking Slider is on the outside of the rack, not the inside. Tighten the roof rack and install the end caps.
- Page 8 Press and hold the button to lift the tire pressure lever. Tighten the T Slot Bolts Clamp.
- Page 9 Step 3 Use U-bolts to secure the rack to the roof.
- Page 10 How to load the bike Lift the bicycle onto the rack. Loosen the handle. Notice Ensure that the bicycle wheels are positioned below the rack.
- Page 11 Adjust the position to lock the wheel in place. Tighten the handle.
- Page 12 Push the tire pressure lever inward until it presses the tire firmly and clicks into place. Notice Ensure the bicycle is securely fastened and does not wobble.
- Page 13 How to remove the bike Press the button to release the pressure lever. Remove the bicycle from the rack.
- Page 14 Reset the tire pressure lever.
- Page 15 Dimensions 5.6” 59.6” 6.3” Specs Application: round, square, aero, elliptical, and most factory crossbars Maximum crossbar dimensions: 3.15" wide x 1.6" tall Crossbar spread: 22" - 29" Carrying capacity: 1 bicycle Weight capacity: 50 lbs Wheel diameter: 18" to 29" Rack weight: 20 lbs Material: steel...
- Page 16 WARNINGS ●Do not overload beyond the bike rack’s weight capacity of 45lbs. ●Do not carry more than 1 bike on the carrier. ●The bike rack is not intended for transporting humans or animals. ●The bike must be secured properly before operating the vehicle. ●Do not carry flammable items on the bike rack.
- Page 17 CRAVOT Warranty Policy Thank you for choosing CRAVOT. We are committed to providing you with quality products and exceptional service. This Limited Warranty Policy outlines the terms and conditions of our warranty support, including con- siderations for varying state laws in the United States and important dis- claimers.
- Page 18 ● Disclaimer of Liability It is crucial to follow the instructions provided in the product manual for proper use. CRAVOT is not responsible for any damages or losses result- ing from improper operation or handling of the product. This disclaimer of liability includes but is not limited to personal injury, damage to property, or any other losses incurred due to non-compliance with the provided instructions.
- Page 19 THANK YOU FOR CHOOSING A CRAVOT BIKE RACK! ● The CRAVOT Bike racks are meticulously designed to ensure stability and safety when hitching your bikes. Prior to assembly, carefully read through this Owner’s Manual, as it provides essential information for both assembly and adjustment.
- Page 20 VERSION:WRA0201240708...
