Delta Electronics SMT Power Inductor HAH1340 Product Specifications

SMT Power Inductor
SILM8040 Type
Features
RoHS compliant.
Low profile (4.0mm max. Height), SMD type.
Self-leads, suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Ideal for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.
Mechanical Dimension:
C
A

Electrical Characteristics:

L
PART NO.
(uH)
SILM8040 - 1R5 1.5
SILM8040 - 2R2 2.2
SILM8040 - 3R3 3.3
SILM8040 - 4R4 4.4
SILM8040 - 5R2 5.2
SILM8040 - 100 10.0
SILM8040 - 150 15.0
SILM8040 - 220 22.0
SILM8040 - 330 33.0
SILM8040 - 470 47.0
SILM8040 - 680 68.0
SILM8040 - 101 100.0
1. Tolerance of inductance : 1.5~100uH 3 0%.
2. Irated is the DC current which cause the inductance drop 35% of its nominal inductance without current
and the surface temperature of the part increase less than 45 C.
3. Operating temperature: -20 C to 105 C (including self-temperature rise).
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
B
O
25 C : 100KHz, 0.1V
2 2
1 DCR
Isat Irated
(m ) MAX
(Adc)
13.8 7.00
18.3 6.50
20.6 5.00
25.7 4.60
30.0 4.20
47.0 3.00
71.3 2.75
102.0 2.30
143.0 1.75
189.0 1.52
260.0 1.30
361.0 1.05
o o
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
RECOMMENDED PAD PA TTERNS
3
(Adc) 100
9.00
7.50
6.00
6.00
4.50
4.00
3.50
10
3.00
2.50
2.00
2.00
1.30
1
0
0
o
59
UNIT:mm/inch
A = 8.4 / 0.331 Max.
B = 4.2 / 0.165 Max.
C = 8.4 / 0.331 Max.
D = 6.3 0.5 / 0.248 0.020
E = 3.0 0.5/ 0.118 0.020
F = 9.5 0.5 / 0.374 0.020
1 10 100
DC BAIS (A)
