Summary of Contents for Agromatic Scanbox ADT-D
- Page 1 Operating manual Scanbox ADT-D / Scanbox ADT-D 230V Agromatic AG Goldingerstrasse 30 8637 Laupen Switzerland Phone +41 (0)55 256 21 00 info@agromatic.com www.agromatic.com Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Phone +41 (0)55 256 21 00, www.agromatic.com Page 1 von 17...
-
Page 2: Table Of Contents
Type plates ....................14 Copyrights / license terms ................ 15 Revision history ..................15 EU declaration of conformity ..............16 Technical Data ......................17 Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Phone +41 (0)55 256 21 00, www.agromatic.com Page 2 von 17... -
Page 3: Safety And Security
Protect the unit from moisture, vibrations, extreme temper- atures, dirt and impact. When using accessories and accessories, use only the types suggested by Agromatic. The device must not be used or stored in rooms in which pesticides / gases are used. The device may only be installed and maintained by trained specialists. -
Page 4: Overview
Input / Output Connetion cable AAK Agro Therm blue 1 x 2 x Ø0.6mm + Shield / PE max. 300 m cable / port Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Phone +41 (0)55 256 21 00, www.agromatic.com Page 4 von 17... -
Page 5: Schematic Diagram Of Hardware Structure With Adt-D 230V Ac
230VAC Connetion cable AAK Agro Therm blue 1 x 2 x Ø0.6mm + Shield / PE max. 300 m cable / port Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Phone +41 (0)55 256 21 00, www.agromatic.com Page 5 von 17... -
Page 6: Installation And Commissioning
The installation of the device must be sufficiently tight. depth: 80mm PA / earth < 1½ min. 10mm to building potential equalization (Connect)! weight max. 3kg, depending on inserts Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Phone +41 (0)55 256 21 00, www.agromatic.com Page 6 von 17... -
Page 7: Electrical Installation
To protect the device, the switch box must be connected to the equipotential bonding via the marked mounting port. Min. cross-section of the equipotential bonding conductor 10mm Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Phone +41 (0)55 256 21 00, www.agromatic.com Page 7 von 17... -
Page 8: Connect Agromatic Data Bus With An Adt-D
A, which is twisted together with the yellow cable. Incorrect connection of the cable leads to damage or destruction of the Scanbox ADT-D. Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Phone +41 (0)55 256 21 00, www.agromatic.com Page 8 von 17... -
Page 9: Connect Agromatic Data Bus With An Adt-D 230V
Communication, ADT data line yellow Communication, ADT data line Incorrect connection of the cable leads to damage or destruction of the Scanbox ADT-D. Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Phone +41 (0)55 256 21 00, www.agromatic.com Page 9 von 17... -
Page 10: Connecting The Temperature Measuring Cable
Installation and commissioning 3.2.3. Connecting the temperature measuring cable Each Scanbox ADT-D is designed for a maximum of 512 sensors. The measuring cables should be distributed evenly over the 8 ports. Only use the connection cable AAK Agro-Therm blue 1x2xØ0.6mm + shield/PE. -
Page 11: Check Before Commissioning
Agromatic data line, Shielded, 2 x 2 x Ø 0.8mm If the switches are all in the right position according to AP and the Agromatic Data-Bus is connected correctly, there is nothing to stop the commissioning. Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Phone +41 (0)55 256 21 00, www.agromatic.com... -
Page 12: Commissioning
If the Warm start jumper is set, the Scanbox loads the internal saved configuration. Sensor failures are monitored during normal operation. Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Phone +41 (0)55 256 21 00, www.agromatic.com Page 12 von 17... -
Page 13: Operation
Operation 4. Operation With the Scanbox ADT-D, the temperature values of the measuring cables are read out and temporarily stored until they are queried by the «Silo Manager» SM2010Sx. 5. Maintenance The device does not require any maintenance in the true sense of the word. However, it is recommended to check the housing regularly for damage and to ensure that it is tight. -
Page 14: Type Plates
Art. 1030041 Version with 48VAC Scanbox ADT-D 230V / ATEX Art. 1030044 Version with 230VAC Scanbox ADT-D 230V Art. 1030045 Version with 230VAC Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Phone +41 (0)55 256 21 00, www.agromatic.com Page 14 von 17... -
Page 15: Copyrights / License Terms
Agromatic products and services - including images, text and software downloads ("Content") - belong either to Agromatic AG or to third parties who have granted Agromatic permission to use the Content. Agromatic cannot give you permission to use content that belongs to third parties. -
Page 16: Eu Declaration Of Conformity
Digital Scanbox ADT-D, ADT-D 230V Art. 1030040, Art. 1030041 Art. 1030044, Art. 1030045 Agromatic AG declares under its sole responsibility that the product to which the declaration relates complies with the following standard (s) or normative document (s). EU Directive... -
Page 17: Technical Data
Safety relevant data Protection class Protection class I IP protection class IP65 ATEX certification 1030040: Ex II 1D Ex taD IIIC 1030044: Ex II1D Ex taD IIIC Agromatic AG, Goldingerstr. 30, 8637 Laupen, Switzerland, Phone +41 (0)55 256 21 00, www.agromatic.com...
