- Page 2 What's in the box Your Sprint Booster comes with the following components: Selector Switch Sprint Booster device * Installation instructions/ Double sided tape Quick Start (this document) Tie wrap User guide For reference only. The actual device may vary in shape and dimensions depending on the vehicle.
- Page 3 Choose the type of transmission MANUAL AUTO On the right side of the selector , there is a slide switch. Using a pointed object (pen/pin/paper clip..etc) move the switch to one of the 2 positions depending on the type of your vehicle's transmission.
- Page 4 Connecting the Selector Switch As soon as you select the type of transmission, you will need to connect the Selector Switch to the Sprint Booster: Locate the white socket on the Sprint Booster, take the Selector switch's connector and connect it to the Sprint Booster You also have the option not to connect the Selector Switch.
- Page 5 Open the vehicle's door and remove the car keys from the car. With the door open ,wait for 10 minutes before you install the device. During this time, the vehicle checks the electronic systems of the car through the CAN bus system. This step is important to allow the CAN bus system to complete the diagnostic testing and avoid having the check...
- Page 6 Installing Sprint Booster Locate the harness connector on the accelerator pedal. Remove the harness connector from the pedal.
- Page 7 Connect the Sprint Booster on the pedal. Make sure that the Sprint Booster is properly aligned with the pedal's connector during installation. Connect the harness connector on the Sprint Booster. Make sure all connections are firmly in place (both harness connector and Sprint Booster are properly connected).
- Page 8 End of Installation After you install the device on the pedal, you can attach the selector switch anywhere on the dashboard using the double sided tape (included). Before attaching the selector switch , clean the selected area of your dashboard with a dry cloth. Always make sure that the wire does not interfere with your foot or the accelerator pedal.
- Page 9 Acceleration modes SPORT RACE No light) (Red Green light) light) 3 Acceleration modes/presets (2 + OFF): ● Off (no light) – Stock response ● SPORT ( Green light) – improved response up to 30% ● RACE (Red light) - improved response up to 60%...
- Page 10 Switching between the Acceleration modes Press the Main button to cycle through the modes Sport Race The navigation through different modes should be done when the accelerator pedal is not pressed. Never change modes while pressing the accelerator pedal.
- Page 11 Acceleration Programs Each mode (SPORT – RACE) comes with 9 steps-programs: Select program using the arrow buttons: 1-9 in SPORT mode (Green light) 1-9 in RACE mode (Red light) Left arrow button Right arrow button Select to decrease Select to increase (9->1) (1->9) The selected program...
- Page 12 Switch Off LED display Keep the main button pressed for 3'' to switch Off the led display (optional ). 2 '' 3 '' 1 '' Keep button pressed for 3 seconds to turn Off LED display Repeat the same procedure to turn the LED Display On.
- Page 13 This document contains basic information in order to install and start using the product in Acceleration mode. Make sure you have read the user guide before operating the device. The Valet Mode and Pedal lock mode are explained in detail in user guide. All titles, ownership rights and intellectual property rights in and relating to this brochure or any copies thereof, including but not limited to copyright, logos, names, trademarks, patents,...
-
Page 16: Selector Switch
Selector Switch Arrow buttons & Navigate through the Acceleration programs......Enter PEDAL LOCK mode / VALET Mode Menu ....... 10-11 Navigate through the PEDAL LOCK mode / PIN selection..12,14 Navigate through the VALET mode / Level - PIN selection..16-18,20 7 Segment LED display Display of the selected Acceleration program...... - Page 17 Choose the type of transmission MANUAL AUTO On the right side of the selector , there is a slide switch. Using a pointed object (pen/pin/paper clip..etc) move the switch to one of the 2 positions depending on the type of your vehicle's transmission. Move to 'M/T' position for vehicles equipped with manual transmission or to 'A/T' position for vehicles equipped with automatic transmission.
- Page 18 Acceleration modes Sprint Booster comes with 3 Acceleration modes/presets (SPORT / RACE / OFF): Off mode – Sprint Booster is deactivated. The response of the car has the factory settings.The LED of the Selector switch is OFF. SPORT mode- Sprint Booster provides improved response up to 30%.
- Page 19 Switching between the Acceleration modes In Order to switch between the different acceleration modes/presets you need to press the main button on the selector Switch (button with Sprint Booster logo). Main button The main button will cycle through the 3 acceleration modes (Off –...
- Page 20 Acceleration Programs Each mode (SPORT – RACE) comes with 9 steps-programs so the driver can choose the one that suits his driving style (18 programs in total). This allows the driver to fine-tune each mode (SPORT – RACE) according his needs by selecting one of the nine different programs on each mode.
- Page 21 Acceleration Programs The default programs on the Selector switch are SPORT- 5 & RACE- 5. With the main selection button move to SPORT or RACE mode and with the arrow buttons select 1-9 to choose acceleration program. Example : Selecting the program SPORT-9 and RACE-4. SPORT-9 RACE-4 (Green)
- Page 22 Switch Off LED display Anytime, you have the option to switch Off the 7 segment LED display ( in SPORT & RACE mode). To do so , just keep the main selection button pressed for 3 seconds. During the time you have the button pressed, 3 dashes will appear to indicate 3 seconds.
- Page 23 In case you disconnect the Selector switch from the Sprint Booster, the device will keep the last settings in memory. (e.g if you disconnect the device while you are in SPORT-5 the device will work as SPORT-5). As soon as you turn off your car's engine the switch (led indicator and led display) will remain active for a few minutes and will go Off as soon as the CAN bus system cuts off the electric...
- Page 24 T h e P e d a l L o c k mo d e a c t s a s a n e x t r a p r o t e c t i o n a g a i n s t u n a u t h o r i z e d v e h i c l e u s e .
- Page 25 Pedal Lock / Valet mode MENU In order to activate the Pedal Lock/Valet mode MENU, follow the procedure below: 1. Make sure the car is stationary and the pedal is not pressed. 2. Go to Off mode (LED Off). 3.Press the 2 Arrow buttons simultaneously for 3 seconds. 4.
- Page 26 Pedal Lock / Valet mode MENU Once you enter the MENU ( ) press the Left or Right arrow button to choose one of the 2 available modes (Pedal lock / Valet mode). By pressing arrow buttons the LED display will cycle between Pedal Lock mode Valet mode In the Pedal Lock/ Valet mode menu, the main selection button is...
- Page 27 Pedal Lock mode In order to activate the Pedal Lock mode you need to press the main selection button when is displayed on the LED display. Once you enter the Pedal lock mode the lower dash on the LED display will start blinking. This indicates the first digit of the 3 digit PIN code.
- Page 28 Pedal Lock mode As soon as you store the third digit of your pin the will blink on the LED display for 10 seconds. After this time the will stop blinking and will remain ON. During the time the is blinking you have the option To cancel the lock by pressing any of the 3 buttons on the Selector switch.
- Page 29 Pedal Lock mode Pedal Lock mode Deactivate Pedal Lock In order to deactivate the Pedal Lock : Press the 2 Arrow buttons simultaneously for 3 seconds. Press 2 arrow buttons The lower dash 3 '' simultaneously for 3 will start blinking seconds to enter PIN.
- Page 30 Pedal Lock mode Once you enable the Pedal Lock mode the car will not be able to accelerate when you press the accelerator pedal and will stay on idle. The PIN should be entered every time you need to activate-deactivate the Pedal Lock mode.
- Page 31 Valet mode Valet mode limits the acceleration of the vehicle by 55 % - 65% - 75% (comes in 3 selectable levels) .It is activated/deactivated through a 3 digit PIN. By limiting the acceleration there will be a significant reduce in vehicle's performance (Power and Torque).
- Page 32 Valet mode In order to select the Valet mode level press the main selection button when the desired level is displayed on the LED display . For example , in order to choose the 2 level of Valet mode (limit acceleration by 65%) , choose the number 2 with the arrow buttons and press the main selection button to select.
- Page 33 Valet mode The 1 digit of your PIN is now stored. Repeat the same procedure to store the 2 and 3 digit of your PIN. In second digit the blinking dash will be the middle one and on the third digit , the upper one. As soon as you store the third digit of your pin the will blink once and then will remain on the display.
- Page 34 Valet mode On vehicles with low hp use only the 1 level as in 2 and 3 level the acceleration will dramatically decrease. Use the 3 level only in vehicles with high hp (300+) : Vehicle's HP suitable levels Up to 150 hp 150-300 300 and up 1,2,3...
-
Page 35: Valet Mode
Valet mode Deactivate Valet mode In order to deactivate the Valet mode : Press the 2 Arrow buttons simultaneously for 3 seconds. Press 2 arrow buttons The lower dash 3 '' simultaneously for 3 will start blinking seconds to enter PIN. Press arrow to choose Press SET to store dash is blinking... -
Page 36: Troubleshooting
Troubleshooting SUGGESTED SYMPTOMS POSSIBLE CAUSE ACTION 1. Device installed 1a. Switch On – Off while Can bus system the engine several was active. times (If the check engine light is still On go to step 1b). 1b. Remove the device, reset the check engine light 22 'Reset check engine light') and... - Page 37 Troubleshooting In case the vehicle's check engine light goes On you can follow the steps below to reset the light: 1. Switch On and Off your car's engine several times. Most vehicles will reset any sporadic error during this process. 2.Consult a technician or your local dealer so the error can be erased through a diagnostic tool.
- Page 39 Terms of use All titles, ownership rights and intellectual property rights in and relating to this brochure or any copies thereof, including but not limited to copyright, logos, names, trademarks, patents, design,text, images, links, concepts and themes are owned by BOULEKOS SA or used under authorized license by BOULEKOS SA.
