Kistler 6613C2Q04 Instruction Manual

Cylinder pressure transmitter

Advertisement

Quick Links

Instruction
Manual
Cylinder Pressure
Transmitter
Type 6613C2Q04
II 3G Ex nA IIC T4 Gc
IECEx nA IIC T4 Gc
CSA class I, Div 2
ä
002-236e-04.16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6613C2Q04 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kistler 6613C2Q04

  • Page 1 Instruction Manual Cylinder Pressure Transmitter Type 6613C2Q04 II 3G Ex nA IIC T4 Gc IECEx nA IIC T4 Gc CSA class I, Div 2 ä 002-236e-04.16...
  • Page 2 Instruction Manual Cylinder Pressure Transmitter Type 6613C2Q04 II 3G Ex nA IIC T4 Gc IECEx nA IIC T4 Gc CSA class I, Div 2 ä 002-236e-04.16...
  • Page 4 Information in this document is subject to change without notice. Kistler reserves the right to change or improve its products and make changes in the content without obligation to notify any person or organization of such changes or improvements.
  • Page 5: Table Of Contents

    Operation ............................15  8.  Maintenance ............................16  9.  Trouble Shooting..........................17  Repair ............................17  9.1  10.  Technical Data Type 6613C2Q04 ..................... 18  11.  Control drawings ..........................19  12.  CSA Certificates ..........................22  13.  ATEX Certificates ..........................25  14.  IECEx Certificates ..........................27 ...
  • Page 6: Introduction

    It will help you with the installation, maintenance, and use of this product. To the extent permitted by law Kistler does not accept any liability if this instruction manual is not followed or products other than those listed under Accessories are used.
  • Page 7: Disposal Instructions For Electrical And Electronic Equipment

    Kistler Instrument sales office for return instructions. 1.2 Software Upgrades and Updates Kistler may from time to time supply upgrades or updates for embedded software. Such upgrades or updates must always be installed. Kistler declines any liability whatsoever for any direct or...
  • Page 8: Csa-Listing

    CSA-Listing 2. CSA-Listing Cylindrical pressure transmitter Type 6613…, 6615…, 6351…, 6352… are C and US – listed. It covers Class I Div 2 Group A, B, C, D and Temp Code T4. The corresponding control/installation drawings different gas groups are in the attachment: - Group A, B - Group C, - Group D...
  • Page 9: Atex-Listing

    Cylinder Pressure Transmitter CSA class I, Div 2 3. ATEX-Listing The Cylindrical pressure transmitters type 6613…, 6615…, 6351…, 6352… are marked for application in “Group II Category 3 systems. Type of protection: Non sparking "n" ATEX and IECEx Marking: IECEx SEV 14.0005 IECEx Ex nA IIC T4 Gc SEV 14 ATEX 0125...
  • Page 10: Labelling

    Labelling 4. Labelling The cylindrical pressure transmitter is labeled with the ATEX, IECEx and CSA designation. The label is self- adhesive and non-removable. 002-236e-04.16 Page 7...
  • Page 11: Description

    Cylinder Pressure Transmitter CSA class I, Div 2 5. Description 5.1 Introduction The pressure transmitter Type 6613C2Q04 contains a piezoelectric sensor and an integrated charge amplifier. The pressure transmitter is made for continuous cylinder pressure monitoring of large gas engines.
  • Page 12: Dimensions Type 6613C2Q04

    Description 5.2 Dimensions Type 6613C2Q04 Fig 2: Dimensions Type 6613C2Q04 and mounting bore 002-236e-04.16 Page 9...
  • Page 13: Working Principle

    Cylinder Pressure Transmitter CSA class I, Div 2 5.3 Working Principle The cylinder pressure is acting on the diaphragm. The diaphragm converts the pressure in proportional force on the sensor element. The piezoelectric sensor element converts the force into a charge. The charge is converted by a charge amplifier into a voltage.
  • Page 14: Installation

     Sensor must be tightened according the mounting torque If there are any question regarding installation please contact Kistler. Fig. 5: Sensor installed in cylinder head Fig. 6: Sensor direct installed in the indicator valve 002-236e-04.16 Page 11...
  • Page 15: Recommended Mounting

    Cylinder Pressure Transmitter CSA class I, Div 2 6.2 Recommended Mounting Fig. 7: Mounting bore for Type 6613C2Q04 Mounting torque is 133 lbf in (15 Nm) without the adapter 6.2.1 Sealing A leak-proof mounting of the sensor is essential to prevent overheating of the sensor by leaking hot gases.
  • Page 16: Installing The Charge Amplifier

    Installation 6.2.3 Installing the Charge Amplifier Charge amplifier can be fixed with cable strips in the cable channel. Select a location where the temperature does certainly not exceed 85°C. Route and fix the integrated cable between sensor and preamplifier so it is protected against mechanical damage.
  • Page 17: Pin Connections

    Cylinder Pressure Transmitter CSA class I, Div 2 6.2.5 Pin Connections Fig 8: View on connector of amplifier Type 1700A69 1700A69A1 1700A69A2 1700A69A3 wires length 10 m 20 m 30 m 50 m Color* Color* Function Black Black Ground (GND) Blue Blue Signal output...
  • Page 18: Operation

    Operation 7. Operation After starting up the engine check for any gas leakage. If there is any gas leaking out around the mounting thread, stop the engine and check the mounting to achieve a complete sealing (see chapter 6). In case of sensor is mounted in indicator valve. When engine is operating, do not open the main indicator valve to blow through for more than 2 seconds at a time.
  • Page 19: Maintenance

    Cylinder Pressure Transmitter CSA class I, Div 2 8. Maintenance After installation, the transmitter needs no maintenance. Do not use a steam or high-pressure cleaner for cleaning purposes. Take care, that diaphragm at sensor front is very thin. Never use wire brush, screw drivers or any other sharp pointed instrument to cleaning the diaphragm.
  • Page 20: Trouble Shooting

    Trouble Shooting 9. Trouble Shooting 9.1 Repair The transmitter cannot be repaired by client. In case of incorrect functions or broken parts the sensor has to be sent to manufacturer. If a constant voltage of –3V or +5V could be measured at signal pin, then disconnect the sensor from power supply to reset charge amplifier.
  • Page 21: Technical Data Type 6613C2Q04

    Convertion of °Celsius to °Fahrenheit => [°C] x 1,8 + 32 °F 2,5 Sensitivity shift 200150 °C 1 20050 °C –0,5 Thermo shock (Kistler testengine 9,5 bar pmi; 1 500 1/min) 5 Time constant for cylinder measuring for calibration >2 500 Signal output (at 1 mA load) max.
  • Page 22: Control Drawings

    Control drawings 11. Control drawings 002-236e-04.16 Page 19...
  • Page 23 Cylinder Pressure Transmitter CSA class I, Div 2 Page 20 002-236e-04.16...
  • Page 24 Control drawings 002-236e-04.16 Page 21...
  • Page 25: Csa Certificates

    Cylinder Pressure Transmitter CSA class I, Div 2 12. CSA Certificates Page 22 002-236e-04.16...
  • Page 26 CSA Certificates 002-236e-04.16 Page 23...
  • Page 27 Cylinder Pressure Transmitter CSA class I, Div 2 Page 24 002-236e-04.16...
  • Page 28: Atex Certificates

    ATEX Certificates 13. ATEX Certificates 002-236e-04.16 Page 25...
  • Page 29 Cylinder Pressure Transmitter CSA class I, Div 2 Page 26 002-236e-04.16...
  • Page 30: Iecex Certificates

    IECEx Certificates 14. IECEx Certificates 002-236e-04.16 Page 27...
  • Page 31 Cylinder Pressure Transmitter CSA class I, Div 2 Page 28 002-236e-04.16...
  • Page 32 IECEx Certificates 002-236e-04.16 Page 29...
  • Page 33: Ec Declaration Of Conformity

    Cylinder Pressure Transmitter CSA class I, Div 2 15. EC Declaration of Conformity Page 30 002-236e-04.16...
