Giant BRASS 1 - DATASHEET 2 Datasheet

Brass 1

Specifications

siZes
XS,S,M
CoLour Grey / Blue
FrAme ALUXX-grade butted aluminum
RST Dirt-RA, rebound adjust,
Fork
100mm travel
shoCk N/A
hAnDLeBAr Alloy riser 31.8mm
stem Giant FR
seAtpost Alloy 30.9x300mm
sADDLe Giant DJ
peDALs Alloy platform
shiFters
SRAM X.5
Front DerAiLLeur N/A
reAr DerAiLLeur SRAM X.5 med cage
BrAkes Hayes MX 4 160mm mechanical disc
BrAke Levers Tektro Alloy
CAssette SRAM PG-830 11-28T 8SPD
ChAin KMC Z72
CrAnkset SR Duro-S Octalink 32/RG
Bottom BrACket Shimano Octalink
rims WTB Dual Duty FR double wall 36H
huBs Formula Alloy
spokes Steel 14g
tires Kenda K-Rad 26x2.3"

extrAs

Chain tensioner
Specifications and availability subject to change without notice.
$

Spec Features

— RST Dirt-RA, 100mm suspension fork
— SRAM X.5 8-speed drivetrain, Hayes MX 4 mechanical disc brakes
— Wheelset: WTB Dual Duty FR rims/ Formula hubs

frame geometry

A B C
Actual part head seat
Frame size number Angle Angle*
inches degrees degrees
XS 12.5 2116800 68.0 74.0
S 14.5 2116801 69.0 74.0
M 16.5 2116802 69.0 74.0
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
D E F G
toptube** headtube Chainstay wheelbase standover
height***
inches inches inches inches inches
21.1 4.6 16.0 41.0 30.1
22.0 4.6 16.0 41.5 30.8
23.0 4.6 16.0 42.5 30.9
163
H
