Giant BOWERY MASHUP Datasheet

50 Bowery mashup
Specifications
siZes S,M,L,
CoLour White / Black / Orange
FrAme CroMo
Fork CroMo
shoCk N/A
hAnDLeBAr Alloy flat 25.4mm
stem Alloy
seAtpost Alloy 25.4x350mm
sADDLe Giant Road
peDALs Alloy platform w/powerstrap
shiFters N/A
Front DerAiLLeur N/A
reAr DerAiLLeur N/A
BrAkes Tektro alloy dual pivot v-brake
BrAke Levers Tektro
CAssette 17T 1/2x1/8 freewheel & fixed
ChAin KMC Z410A 1/2x1/8
CrAnkset Alloy messenger style 48T
Bottom BrACket Cartridge
rims Giant CR32 32H
huBs R:Alloy high flange track style flip-flop
spokes Stainless Steel 14/15g
tires Kenda Kriterium 700x25c
extrAs 16T 1/2x1/8 cog
Specifications and availability subject to change without notice.
$
Spec Features
— Single-speed 17T gearing
— High-flange track-style flip-flop rear hub for fixed/ freewheel setup
— Includes extra 16T rear cog
frame geometry
A B C
Actual part head seat
Frame size number Angle Angle*
centimeters degrees degrees
S 42.0 2113200 72.0 74.0
M 48.5 2113201 72.0 73.0
L 55.0 2113202 72.0 72.5
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
D E F
toptube** headtube Chainstay wheelbase
centimeters centimeters centimeters centimeters
52.0 12.0 41.6 98.1
55.0 15.0 41.6 100.2
58.0 18.0 41.6 102.9
G H
standover
height***
inches
29.3
30.7
32.4
