- Page 1 MEDICAL LIGHTING PH A NTO M EX INSTALLATION MANUAL EXAMINATION LIGHT PHANTOM EX M A N U A L ver. 22112023-00 planetlighting.com/medical-lighting/ Document is subject to change without notice.
-
Page 2: Table Of Contents
6.1 Fixing the mount ‑ P.13 6.2 Attaching the power supply ‑ P.13 6.3 Electrical Connections ‑ P.13 6.4 Final inspection ‑ P.13 M A N U A L PHANTOM EX ver. 22112023-00 planetlighting.com/medical-lighting/ Document is subject to change without notice. -
Page 3: Introduction
• Electrical engineer, or other electro-technical expert qualified to work as an electrician (for the electrical works) • For the installation phase, as regards assembly operations only, a qualified person is deemed whosoever has attended a course organised by Planet Lighting or, alternatively, whosoever has carefully read the manual. FIG. 1.1 GLOSSARY OF TERMS... -
Page 4: Warnings And Safety Notices
FIG. 1.2 WARNINGS AND SAFETY NOTICES 2.0 GENERAL INFORMATION This installation manual describes how to install, maintain and operate the Planet Lighting Phantom EX medical examination light. Prior to installation carefully read through all the instructions enclosed in this manual. -
Page 5: Product Definition
When your PRODUCT reaches the end of its life, contact Planet lighting or our local agents to learn about recycling options. The PRODUCT must be disposed of properly according to local laws and regulations. -
Page 6: Graphic Signs And Symbols Used In The Installation Manual
No arbitrary structural changes or variations to the PRODUCT are admitted. Any modifications must have the prior written authorisation of Planet Lighting. In case of the PRODUCT having been tampered with, the warranty shall be invalidated and the manufacturer disclaims all liability for any injuries or damage caused to the OPERATOR, the RESPONSIBLE ORGANIZATION and the SERVICE PERSONNEL. - Page 7 Date of manufacture (Month/Year) MANUFACTURE MANUFACTURER Manufacturers address READ OPERATING Compulsory to read the operating manual MANUAL FIG. 2.6 GRAPHIC SYMBOLS USED ON THE PRODUCT PHANTOM EX M A N U A L ver. 22112023-00 planetlighting.com/medical-lighting/ Document is subject to change without notice.
-
Page 8: Planning
For more information regarding our cotton reel mounts, please see the Cotton Reel Mount datasheet. 3.2 Correctly wiring up the premises M A N U A L PHANTOM EX ver. 22112023-00 planetlighting.com/medical-lighting/ Document is subject to change without notice. - Page 9 • The electrical system must have a certificate of conformity issued by whosoever installed it. • The earth system must be certified as required by applicable regulations. cotton reel FIG. 3.1 STRUCTURAL MOUNTING EXTENSION (COTTONREEL) PHANTOM EX M A N U A L ver. 22112023-00 planetlighting.com/medical-lighting/...
- Page 10 FIG. 3.2 STRUCTURAL LOADINGS / APPROXIMATE WEIGHTS FOR WALL AND CEILING MOUNT Static weights of complete fixture (Mount, Arm and Light Head). M A N U A L PHANTOM EX ver. 22112023-00 planetlighting.com/medical-lighting/ Document is subject to change without notice.
-
Page 11: Installation General Requirements
4.1 Mounting general notes The Phantom EX arm is designed to be mounted above the immediate work area. Standard mounting fixtures for the Phantom EX are: Ceiling Mount & Wall Mount (specialised mountings are available on application). For mounting, please use the relevant Ceiling or Wall Mount Template document provided on our website. -
Page 12: Fixing The Wall Mount
FIG. 5.1 ENSURE VERTICAL Ensure wall mount installation is vertical. M A N U A L PHANTOM EX ver. 22112023-00 planetlighting.com/medical-lighting/ Document is subject to change without notice. - Page 13 Electrical Classification: Non invasive medical device, as per label/s below. Voltage: 240v Input Current: 0.229Arms Frequency: 50Hz Classification: Class 1 Phantom EX Model: Wall www.planetlighting.com PHANTOM EX M A N U A L ver. 22112023-00 planetlighting.com/medical-lighting/ Document is subject to change without notice.
-
Page 14: Ceiling Mount
Tighten the two locking screws on the collar to secure the ceiling cover. M A N U A L PHANTOM EX ver. 22112023-00 planetlighting.com/medical-lighting/ Document is subject to change without notice. -
Page 15: Final Inspection
Looking directly into this light may cause permanent eye damage. DIM - DOWN (lower brightness) CAUTION POWER - ON/OF Ensure you follow your workplace cleaning and maintenance requirements. PHANTOM EX M A N U A L ver. 22112023-00 planetlighting.com/medical-lighting/ Document is subject to change without notice. - Page 16 FIG. 6.0 CEILING MOUNT FIG. 6.1 RETRO FITTING TO OLD CEILING TUBE Discard old screw Discard old swivel boss M A N U A L PHANTOM EX ver. 22112023-00 planetlighting.com/medical-lighting/ Document is subject to change without notice.
-
Page 17: Cleaning
• Once handle is sterilised, re-attach the handle to the light fitting FIG 8.0 DO NOT spray cleaning solutions directly onto the PRODUCT. Spray onto a cloth and wipe the product. PHANTOM EX M A N U A L ver. 22112023-00 planetlighting.com/medical-lighting/... -
Page 18: Maintenance
9.1 Technical faults and repairs In the case of a technical fault with one of our products, Planet Lighting recommend that the product is returned to our factory to be assessed and repaired. If a qualified technician is available to repair the fixture, circuit diagrams, parts lists, and descriptions will be made available to assist in this process. -
Page 19: Troubleshooting
END OF DOCUMENT Made in Australia Exported to the World Tamarind Drive Bellingen NSW 2454 Australia Phone + 61 (0)2 6659 5600 sales@planetlighting.com www.planetlighting.com PHANTOM EX M A N U A L ver. 22112023-00 planetlighting.com/medical-lighting/ Document is subject to change without notice.
