Scan to view or download these
instructions online
READ BEFORE START
The following instructions are designed to help
you ensure a safe and professional installation.
Observe all the following steps.
CONTENTS
This document contains 3 parts:
3. Installation Guide
EQUIPMENT CHECKLIST
Some of the items you will need include:
- Snap Fix / Removal Tool (provided)
- Cable Snake
GENERAL NOTES
All LED Pucks are factory tested for a
minimum of 24hrs.
LED Puck RGBW is a Plug & Play
system designed for ease of
&PLAY
installation and maintenance.
planetlighting.com/led-puck
CAUTIONS!
Observe the following cautions.
LED PUCK INSTALLATION SHOULD BE CARRIED OUT BY A
LICENSED ELECTRICIAN ONLY.
DO NOT UNDERTAKE INSTALLATION WITH DRIVER
POWERED.
ENSURE THAT WIRE INSULATION IS NOT DAMAGED ON
SHARP INTERNAL BURRS
READ AND OBSERVE THE PRECAUTIONS ON YOUR
CHOSEN LED DRIVER. ALWAYS CONSULT THE DRIVER
MANUFACTURER OR YOUR DISTRIBUTOR IF YOU HAVE ANY
QUESTIONS.
LED PUCKS WILL OVERHEAT AND MAY CAUSE DAMAGE IF
KEPT RUNNING OUTSIDE THE RAIL CONTINUOUSLY.
NEVER CONNECT (HOT PLUG) LED PUCKS TO A POWERED
DRIVER AS THIS CAN DAMAGE LEDS.
IT IS ESSENTIAL THAT YOU CONTACT US AT PLANET
LIGHTING PRIOR TO INSTALLATION IF YOU CHOOSE TO
SUPPLY YOUR OWN DRIVER.
ISSUES ARISING FROM A DRIVER NOT SUPPLIED BY US
WILL NOT BE COVERED UNDER WARRANTY.
LED PUCK RGBW WIRING GUIDE
INSTALLATION
ver.11112020-00
Page 1
Advertisement
Table of Contents
Related Manuals for Planet Lighting LED PUCK RGBW
Summary of Contents for Planet Lighting LED PUCK RGBW
- Page 1 All LED Pucks are factory tested for a minimum of 24hrs. NEVER CONNECT (HOT PLUG) LED PUCKS TO A POWERED LED Puck RGBW is a Plug & Play DRIVER AS THIS CAN DAMAGE LEDS. system designed for ease of &PLAY installation and maintenance.
- Page 2 LED PUCK RGBW WIRING GUIDE INSTALLATION DRIVER DETAILS RECOMMENDED DRIVER SUPPLYING YOUR OWN DRIVER? Drivers that are supplied by Planet will (NOT RECOMMENDED) come pre-programmed with all parameters It is essential that you contact us at Planet optimised for LED Puck RGBW.
- Page 3 LED PUCK RGBW WIRING GUIDE INSTALLATION WIRING DIAGRAM LED Puck RGBW is a Plug & Play system DRIVES 1 TO 15 RGBW LED PUCKS designed for ease of installation and maintenance. PLUG CONNECTION RETURN CABLE DRIVER FEED CABLE EXTENSION LEAD...
- Page 4 LED PUCK RGBW WIRING GUIDE INSTALLATION 1. RUN CABLES INSTALLATION GUIDE 1.1 Run the return cable through the rail for the designated circuit as per wiring specifications. Return cable Cable entry point 1.2 Pull return cable through last hole (furthest from the cable entry point – this is the end of the circuit).
- Page 5 LED PUCK RGBW WIRING GUIDE INSTALLATION 2. PLUG IN INSTALLATION GUIDE NOTE! NEVER CONNECT (HOT PLUG) LED PUCKS to a powered driver as this can damage LEDs. 2.1 Ensure driver is powered OFF 2.2 For each hole, plug in an RGBW Puck, connecting male to female, and female to male plugs.
- Page 6 LED PUCK RGBW WIRING GUIDE INSTALLATION 3. CHECK & TEST INSTALLATION GUIDE NOTE! DO NOT keep LED Pucks running continuously outside the rail as they will overheat and may damage. Ensure test duration is short. NOTE! ONLY ONE colour channel at a time should be tested.
- Page 7 LED PUCK RGBW WIRING GUIDE INSTALLATION 4. INSERT LED PUCKS INSTALLATION GUIDE NOTE! Perform this step with the driver OFF and power disconnected. 4.1 Push the LED Pucks into the tube. The Pucks should snap firmly and securely into place.
- Page 8 LED PUCK RGBW WIRING GUIDE INSTALLATION 5. FINAL TEST INSTALLATION GUIDE 5.1 Apply power to the driver. 5.2 Check that ALL LED Pucks are illuminated as per the DMX / RDM input signal. 5.2 Final check: Confirm LED Pucks respond to DMX / RDM after insertion.
