Giant AVAIL 1 - DATASHEET 2 Datasheet

aVAIL 1

Specifications

siZes XS,S,M
CoLour White / Red

FrAme

ALUXX SL-Grade aluminum
Advanced-Grade composite w/

Fork

alloy OverDrive steerer
shoCk N/A
hAnDLeBAr Giant for Women Connect 31.8mm
stem Giant Connect
seAtpost Giant Connect carbon 30.9x350mm
sADDLe Selle Royal Seta W
peDALs Not included
shiFters Shimano R700 w/ reach adjust
Front DerAiLLeur Shimano 105
reAr DerAiLLeur Shimano 105
BrAkes Tektro R540
BrAke Levers Shimano R700 w/ reach adjust
CAssette Shimano 105 11-28T 10SPD
ChAin Shimano 105
CrAnkset Shimano 105 34/50T compact
Bottom BrACket Shimano external
rims Giant P-R2 F:24H / R:28H
huBs Formula Alloy
spokes Sapim Race 14g
tires Giant P-R3 700x25c

extrAs

Specifications and availability subject to change without notice.
$
Spec Features
— Shimano 105, 5700-series 10-speed component group w/ compact crankset
— Giant Connect handlebar & stem, Connect carbon composite seatpost
— Wheelset: Giant P-R2 rims/ Formula Alloy hubs
frame geometry
A B C
Actual part head seat
Frame size number Angle Angle*
centimeters degrees degrees
XS 43.0 2114506 71.0 74.5
S 46.5 2114507 72.0 74.0
M 50.0 2114508 72.5 73.5
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
D E F
toptube** headtube Chainstay wheelbase
centimeters centimeters centimeters centimeters
51.0 13.0 42.0 98.3
52.5 15.0 42.0 98.5
54.0 17.5 42.0 99.0
117
G H
standover
height***
inches
28.9
29.6
30.6
