ASSE MB LY GUI D E FOR
Sig n at ur e
Umb rell a Ba se
WARNINGS/IMPORTANT NOTES
• Only use to secure Ledge umbrellas - not approved for other models.
• Compatible with 1.375", 1.5", & 2" Umbrella pole diameters.
• Not for use in pool.
CLEANING AND CARE
• Hand wash with soap & water only.
PARTS INCLUDED
x1
Screw
x1
Fill Cap
x1
x1
Allen Wrench
x1
Pole Brace
x1
Base Reservoir
x1
Receiver Cap
x1
1.5" Reducer
1.375" Reducer
x1
Receiver Pole
Advertisement
Related Manuals for LEDGE Signature
Summary of Contents for LEDGE Signature
- Page 1 Sig n at ur e Umb rell a Ba se WARNINGS/IMPORTANT NOTES • Only use to secure Ledge umbrellas - not approved for other models. • Compatible with 1.375”, 1.5”, & 2” Umbrella pole diameters. • Not for use in pool.
- Page 2 Note - If your umbrella pole has a 2” diameter, you will not need the 1.5“ reducer piece in this step. All LEDGE umbrellas have 1.5” diameter poles. Receiver Cap 1.5”...
- Page 3 ASSEMBLY STEP 2: Insert the metal pole brace piece into the cavity at the bottom of the base reservoir. Press firmly to ensure the piece is seated correctly. Insert screw through the center hole and use the included allen wrench To attach the pole receiver assembly from below.
- Page 4 ASSEMBLY STEP 2: Loosen the top ring on the pole receiver assembly, insert the umbrella pole, and then re-tighten the top ring to secure the umbrella in the base. Assembly complete.
- Page 5 WARNING Assembly Instructions and Assembly Items Enclosed DO NOT THROW AWAY...
