- Page 1 20V MAX LITHIUM-ION BRUSHLESS DRILL DRIVER Model: PDDX2-M2-EU PDDX2-M2-EU-0 For customer service please find all information on www.senixtools.com CAUTION: BEFORE USING THIS PRODUCT, READ THIS MANUAL AND FOLLOW ALL ITS SAFETY RULES AND OPERATING INSTRUCTIONS. ORIGINAL INSTRUCTIONS...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY & INTERNATIONAL SYMBOLS ..........................2 SAFETY INSTRUCTIONS................................3 KNOW YOUR UNIT...................................11 SPECIFICATIONS*...................................12 ASSEMBLY....................................13 OPERATION....................................15 MAINTENANCE..................................18 TROUBLESHOOTING................................19 SAFETY & INTERNATIONAL SYMBOLS Explanation of Safety & international symbols describes safety and international symbols and pictographs that may appear on this product. Read the operator’s manual for complete safety, assembly, operating and maintenance and repair information. Caution / Warning. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS GENERAL POWER TOOL SAFETY 2) Electrical Safety WARNINGS a) Power tool plugs must match the outlet. Never modify the WARNING! plug in any way. Do not use Read all safety warnings, any adapter plugs with earthed instructions, illustrations and (grounded) power tools. -
Page 4: Personal Safety
outdoor use reduces the risk of with your finger on the switch or electric shock. energising power tools that have f) If operating a power tool in a the switch on invites accidents. damp location is unavoidable, d) Remove any adjusting key use a residual current device or wrench before turning the (RCD) protected supply. - Page 5 4) Power Tool Use And Care moving parts, breakage of a) Do not force the power tool. parts and any other condition Use the correct power tool for that may affect the power your application. The correct tool’s operation. If damaged, power tool will do the job better have the power tool repaired before use.
- Page 6 5) Battery Tool Use And Care or modified. Damaged or modified batteries may exhibit a) Recharge only with the unpredictable behaviour resulting charger specified by the in fire, explosion or risk of injury. manufacturer. A charger that is f) Do not expose a battery pack suitable for one type of battery or tool to fire or excessive pack may create a risk of fire...
-
Page 7: Safety Warnings For Drill
SAFETY WARNINGS FOR DRILL bend causing breakage or loss 1) Safety Instructions For All of control, resulting in personal Operations injury. a) Hold the power tool by 3) Dust/Chip Extraction insulated gripping surfaces, when performing an operation Dust from materials such as where the cutting accessory or lead-containing coatings, some fasteners may contact hidden... - Page 8 ADDITIONAL SAFETY temporarily high torque INFORMATION FOR DRILL reactions. f) In case of damage and improper a) Secure the workpiece. A use of the battery, vapours may workpiece clamped with be emitted. The battery can set clamping devices or in a vice is alight or explode.
- Page 9 SAFETY WARNING FOR BATTERY (This advice is considered PACK AND BATTERY CHARGER correct for conventional NiMh, NiCd, lead acid and lithium- • Recharge only with the charger ion cell types. If this advice specified by the manufacturer. A is incorrect for a cell design charger that is suitable for one that differs from these, then type of battery pack may create...
-
Page 10: Intended Use
VIBRATION + NOISE REDUCTION the letter. This will help to prevent To reduce the impact of noise and risks and hazards. vibration emission, limit the time of • Always be alert when using operation, use low-vibration and low- this product, so that you can noise operating modes as well as recognize and handle risks early. -
Page 11: Know Your Unit
As a cordless drill driver: Drilling in all types of wood, metal products with drill bits; Driving screws into wood,metal with screwdriver bits. NOTE: PDDX2-M2-EU-0 does not include charger and battery pack. 1. Speed Selector 7. Work Light 2. Torque Ring 8. -
Page 12: Specifications
SPECIFICATIONS* Model PDDX2-M2-EU Rated voltage 18 V d.c. Low: 0-600 rpm No load speed High: 0-2000rpm Chuck capacity Ø 2 mm-13 mm Wood: 38 mm Max. drill capacity Steel: 13 mm Max. torque 70 N.m Weight without battery 1.2 kg... -
Page 13: Assembly
NOTE: Observe the technical requirements of this product (see section “SPECIFICATIONS”) when purchasing and using bit. PDDX2-M2-EU-0 does not include the charger and the Always use special bits according to the work to battery pack. be performed. The chuck and the bit can be very hot after... -
Page 14: Battery Pack
To remove: Turn the chuck counterclockwise to open the jaw and pull the bit out of the jaw. NOTE: Make sure the bit is fixed firmly and will never come out before use. BATTERY PACK NOTE: Prior to installation, lock the switch trigger by the reversing lever to avoid unintentional start. To install: Align and slide the battery pack to the docking port until it is locked in place. -
Page 15: Operation
OPERATION TORQUE WARNING: 1. 17 torque values are designed for screw driving.Rotating Always wear eye, hearing, hand protection to the torque ring until the arrow points at the desired value. reduce the risk of injury when operating the The screw will be automatically stopped once the pre-set tool. -
Page 16: Switching On/Off
SPEED NOTE: Mode Setting Application Charge batteries at a ambient temperature of 0°C-40°C. Slow “1” 0-600/min Fast “2” 0-2000/min The tool reaches higher speed when push the speed selector to "2" . 1. Charge the Lithium-Ion battery pack only with the correct charger. -
Page 17: Practical Advices
PRACTICAL ADVICES Lights 1) General Lighted Blinking Remaining Capacity a) Ensure the tool is fitted with a suitable bit for current work and the reversing lever is at center lock position before start. b) Always keep the product perpendicular to the 75% - 100% workpiece. Otherwise, bit is more likely to slip or be jammed in turn causing tool damage. -
Page 18: Maintenance
MAINTENANCE TRANSPORTATION WARNING: 1. Only carry by its handle. Only perform cleaning and maintenance work 2. Protect from any heavy impact or strong vibrations according to these instructions! which may occur during transportation in vehicles. All further works must be performed by a qualified specialist! 3. -
Page 19: Troubleshooting
TROUBLESHOOTING Suspected malfunctions are often due to causes that the users can fix themselves. Therefore, check the product using this section. In most cases the problem can be solved quickly. PROBLEM POSSIBLE CAUSE SOLUTION Product does not start Reversing lever at center locking position Switch the reversing lever to proper side Battery pack not properly attached Attach properly Battery pack discharged Charge the battery pack Product does not reach...
