- Page 1 RadiWarm MADE IN THE UK Hydronic Electric Radiator INSTALLATION & OPERATING INSTRUCTIONS Installer please note: Leave installation and operating instructions with customer...
-
Page 2: Table Of Contents
Contents Page 2.0 Technical Details 3.0 Important Safety Information 4.0 Installation Instructions 4.1 Pre-Install 4.2 Info 4.3 Positioning 4.4 Fitting 5.0 Operating Instructions 5.1 Before Switching On 5.2 Switching On 6.0 Radio Frequency Control (RFC) 6.1 Batteries 6.2 Connecting your Radiator to your Controller 6.3 Choosing a position in the room 6.4 Range Test 6.5 Fixing the RFC to the Wall... -
Page 3: Technical Details
Technical Details This appliance conforms to and is certified to AS/NZS 60335.2.30:2023 and AS/NZS 60335.1:2020 + A1 Energy Related Product Directive This product meets the Ecodesign requirement for an electric fixed local space heater Commission Regulation (EU) 2015/1188 when used with one of our controllers. Model 1.100 1.625... - Page 4 CE, UKCA, NEMKO, AS/NZS Eco Design Lot 20 Compliant when used with a controller Warranty Up to 30-year warranty See section 10.0 for full warranty terms and conditions. Country of Origin United Kingdom Manufacturer HEIGHTS (U.K.) LIMITED trading as Radiwarm...
-
Page 5: Important Safety Information
Important Safety Information The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervised or instruction concerning use of the appliance by a responsible person for their safety. Young children should be supervised to ensure that they do not play with the appliance. - Page 6 Supply This radiator must be plugged into a switched socket using the factory fitted plug, or hardwired. If hardwiring, remove the plug and dispose of safely and ensure all wiring complies with AS/NZS3000. The radiator must be installed under the protection of an RCD or RCBO not exceeding 30mA.
-
Page 7: Installation Instructions
4.0 Radiator Installation Instructions Note: If installing a radiator with an LST/SafeTouch cover please refer to that specific manual. Please read all instructions carefully before installation. A suitable socket will be needed to plug your radiator into. The radiator is supplied with a fitted plug but may also be hardwired by a licensed electrician. -
Page 8: Positioning
4.3 Positioning A suitable position for the radiator should be chosen and the positions of the mounting brackets marked on the wall, using the dimensions given below. Model 4100 4140 4160 A (bracket width) 860mm 1260mm 1460mm Model 6040 6060 6080 6100 6120... -
Page 9: Fitting
4.4 Fitting Ensure that the brackets are fitted towards the outside of the hangers on the radiator. This will prevent any lateral movement when the radiator is mounted. For most efficient operation of the radiator, there should be a gap between the skirting board and the rear panel of the radiator to allow air flow behind the radiator. -
Page 11: Operating Instructions
5.0 Operating Instructions NOTE This instruction manual should be read carefully and retained by the user. Particular attention must be made to the safety information at the beginning of this manual. 5.1 Before Switching On Ensure that the radiator has been installed correctly and that all warnings and instructions have been read carefully and followed. -
Page 12: Radio Frequency Control (Rfc)
6.0 Radio Frequency Control Your Radio Frequency Controller (RFC) is a wireless thermostat giving high precision room temperature control. It is also a seven day programmer with up to six temperature settings per day. Each RFC can control any number of radiators. The temperature control is primarily set by the RFC. -
Page 13: Connecting Your Radiator To Your Controller
6.2 Connecting your Radiator to your Controller For radio control to work, you first need to establish a radio connection between your radiator and your RFC. You may wish to follow this procedure if you add more radiators. Turn the radiator thermostat knob fully clockwise. -
Page 14: Choosing A Position In The Room
6.3 Choosing a position in the room The RFC should be positioned in a place where its temperature will not be changed by local events. Avoid: ● Draughty places near windows, doors and vents. ● Places near the radiator or any other heat sources in the room. ●... -
Page 15: Your Rfc Unit
7.0 Your RFC Unit... -
Page 16: Setting The Time And Day
7.1 Setting the Time and Day To set the clock press HOLIDAY and BOOST together. The hours will start to flash and you can adjust them with ▲ and ▼. Using SELECT you can adjust minutes, day of week or change from 24 hour clock to 12 hour clock. -
Page 17: Adaptive Start (Auto Advance)
7.5 Adaptive Start (Auto Advance) -
Page 18: Setting The 7-Day Program
7.6 Setting the 7 day program To set the program press SET-BACK and ADVANCE together. This will take you to stage 1 below. You can program the RFC1 with up to 6 temperature levels per day. Program times cannot overlap, for example if PROG.3 Mon is 16:30 then PROG.3 Mon can only be set to times before 16:30. -
Page 19: Reverting Your Radiator To Manual Control
7.7 Reverting your Radiator to Manual Control If for any reason you want to use your radiator without the RFC, you can revert to Manual Control. ● If the radiator is on, switch the mains supply off and turn the control knob to maximum. ●... -
Page 20: Smart Controller
8.0 Smart Controller... -
Page 22: Trouble Shooting Guide
9.0 Trouble Shooting Guide Symptoms Possible Cause Remedy Radiator makes “gurgling” This is normal, and the If the sound is still present or “swishing” sound on noise will go away after a on constant running after a first switching on. short period. -
Page 23: After Sales Service
If our recommended Trouble Shooting Guide does not solve the problem, warranty terms will then be followed as per below; All Radiwarm Signature Radiators are supplied complete with a manufacturer’s 12 month warranty, however this can be extended to 30 years (30 years on the radiator shell, 10 years on electrical components) by registering your appliance within 1 month of purchase at info@warmnz.co.nz... -
Page 25: Personal Information
DATE OF REGISTRATION Registration Form For extended warranty, complete this form and return to: Hunt Heating Registration Department, Reply Paid 87857, Keysborough VIC 3175 PERSONAL INFORMATION First Name : Prefix : Surname : Telephone : Mobile : Email Address : Address : Suburb : State :... - Page 26 189 Great South Rd, Takanini, Auckland 2112 09 296 9022 warmnz.co.nz...
