Summary of Contents for Philips EVNIA 27M2N3501PA
- Page 1 27M2N3501PA User manual Register your product and get support at www.philips.com/welcome...
-
Page 2: Table Of Contents
6. Technical Specifications 17 6.1 Resolution & Preset Modes ..21 7 Power Management 22 8 Customer care and warranty 23 8.1 Philips’ Flat Panel Monitors Pixel Defect Policy ........ 23 8.2 Customer Care & Warranty ..26 9 Troubleshooting & FAQs 27 9.1 Troubleshooting ...... -
Page 3: Important
Keep the display away from oil. Oil may damage the plastic cover of the display and void the warranty. This electronic user’s guide is intended for anyone who uses the Philips • Remove any object that could fall monitor. Take time to read this user into ventilation holes or prevent manual before you use your monitor. - Page 4 damage will not be covered under • Oil-based cleaning solutions may warranty. damage the plastic parts and void the warranty. • Do not knock or drop the monitor during operation and/or • Unplug the monitor if you are not transportation. going to use it for an extensive period.
-
Page 5: Notational Descriptions
1.2 Notational Descriptions Uninterrupted display of still or static images over an extended The following subsections describe the period may cause “burn-in”, also notational conventions used in this known as “after-imaging” or “ghost document. imaging”, on your screen. • “Burn-in”, “after-imaging”, or Notes, Cautions, and Warnings “ghost imaging”... -
Page 6: Disposal Of Product And Packing Material
From the planning, design, and production stages, Philips emphasizes the importance of making products that can easily be recycled. At Philips, end-of-life management primarily This marking on the product or its entails participation in national take-... -
Page 7: Setting Up The Monitor
2.1 Installation Package contents 27M2N3501PA Quick Start Register your product and get support at www.philips.com/welcome 2. Hold the stand with both hands. (1) Gently attach the base to the stand. (2) Use your fingers to tighten the screw located at the bottom of the base. - Page 8 Connecting to your PC Note The headphone holder is securely integrated with the monitor stand and is specifically designed for headset storage. Please note that excessive pulling/dragging on the hook, which effectively goes beyond its intended use, may result in damage. Earphone-Hang AC power input DisplayPort input...
-
Page 9: Operating The Monitor
What is On-Screen Display (OSD)? Description of the control buttons On-Screen Display (OSD) is a feature in all Philips LED monitors. It allows an end user to adjust screen performance or select functions of the monitors directly through an on-screen instruction window. - Page 10 Main menu Sub menu Standard, FPS, Racing, RTS, Movie, SmartImage Brightness 0~100 LowBlue Mode, EasyRead, Economy, Contrast 0~100 SmartUniformity, Game1, Game2 SmartContrast On, O Gamma 1.8, 2.0, 2.2, 2.4, 2.6 Sharpness 0~100 On, O sRGB Color Temperature Native, Preset, 5000K, 6500K, 7500K, 8200K, 9300K, 11500K R.G.B.
- Page 11 saturation with higher contrast Note so you can see better in both • Game mode: This model is equipped light and dark environments. In with new features in OSD which addition, this feature helps you gives you high-quality visual fine-tune your sight so that en- experience.
-
Page 12: Height Adjustment
To enable the OverClock feature, you Swivel will need to go to OSD menu > Game Settings > OverClock. +30° SmartImage Game Mode Input Audio Language System Setup Close Smart MBR Sync -30° Crosshair Off Stark ShadowBoost Select Smart Sniper Low Input Lag SmartResponse Close... -
Page 13: Remove The Base Assembly For Vesa Mounting
2.3 Remove the Base Assembly Note This monitor accepts a 100mm x 100mm for VESA Mounting VESA-Compliant mounting interface. Before you start disassembling the VESA Mounting Screw M4. Always monitor base, please follow the contact manufacturer for wall-mount instructions below to avoid any possible installation. -
Page 14: Image Optimization 12
EasyRead, Economy, Smartuniformity, brightness, contrast, color, and sharpness Game1 and Game2. in real-time. Whether you're working with text applications, displaying images, or watching a video, Philips SmartImage delivers great monitor performance. SmartImage GAME Why do I need it? Standard... - Page 15 LED displays can cause eye damage and affect vision over HDR Movie time. Developed for well-being, the HDR Vivid Philips LowBlue Mode setting uses Personal smart software technology to reduce Off harmful shortwave blue light. • EasyRead: Helps improve reading of text-based applications like PDF ebooks.
-
Page 16: Smartcontrast
3.2 SmartContrast Note To switch off the HDR function, please What is it? disable the Input device and its content. It is a unique technology that Inconsistent HDR settings between the dynamically analyzes displayed content input device and monitor may cause and automatically optimizes a monitor's unsatisfying images. -
Page 17: Adaptive Sync 15
4 Adaptive Sync AMD Radeon R7 260X • AMD Radeon R7 260 • ■ Processor A-Series Desktop and Mobility APUs Adaptive Sync AMD A10-7890K • AMD A10-7870K • PC gaming has long had an imperfect experience because GPUs and monitors AMD A10-7850K •... -
Page 18: Hdr 16
5. HDR HDR Settings in Windows10 system. Steps 1. Right-click on the desktop, and enter Display settings. 2. Select the display/monitor. 3. Select an HDR-capable display under Rearrange your displays. 4. Select Windows HD Color settings. 5. Adjust Brightness for SDR content. Note Windows 10 edition is required. -
Page 19: Technical Specifications 17
6. Technical Specifications Picture/Display Monitor Panel Type IPS Technology Backlight W-LED Panel Size 27" W (68.5 cm) Aspect Ratio 16:9 Pixel Pitch 0.2331 (H) mm x 0.2331 (V) mm Contrast Ratio(typ.) 1000:1 Recommended 2560 x 1440 @ 60 Hz Resolution 2560 x 1440 @ 144 Hz (HDMI) Maximum Resolution 2560 x 1440 @ 260 Hz (DP) - Page 20 Plug & Play DDC/CI, sRGB, Windows 11/10, Mac OS X Compatibility Stand Tilt -5 / +20 degree Swivel -30 / +30 degree Height adjustment 130 mm Pivot -90 / +90 degree Power AC Input Voltage AC Input Voltage AC Input Voltage Consumption at 100VAC , 60Hz at 115VAC , 60Hz...
- Page 21 50%. This monitor provides optimal visual comfort, minimizes eye strain, and supports sustained focus. Note The data mentioned in this section is subject to change without notice. Go to www. philips.com/support to download the latest version of the leaflet. 2. SmartUniformity and Delta E information sheets are included in the box.
- Page 22 Display Input Format 422/420 444/RGB 422/420 444/RGB HDMI 2.0 HDMI 2.0 DP 1.4 DP 1.4 2560 x 1440 260Hz, 10bits 2560 x 1440 260Hz, 8bits 2560 x 1440 240Hz, 10bits 2560 x 1440 240Hz, 8bits 2560 x 1440 200Hz, 10bits 2560 x 1440 200Hz, 8bits 2560 x 1440 144Hz, 10bits 2560 x 1440 144Hz, 8bits...
-
Page 23: Resolution & Preset Modes
For best output performance, please (kHz) always ensure that your graphic card 31.469 640 x 480 59.94 is capable of achieving the maximum resolution and refresh rate of this Philips 640 x 480 66.667 display. 37.861 640 x 480 72.809 37.5... -
Page 24: Power Management 22
7 Power Management If you have a VESA DPM compliance display card or software installed on your PC, the monitor can automatically reduce its power consumption when not in use. If an input from a keyboard, mouse, or other input device is detected, the monitor will 'wake up' automatically. -
Page 25: Customer Care And Warranty 23
Other Pixel Defect Policy combinations of lit and dark sub-pixels appear as single pixels of other colors. Philips strives to deliver the highest quality products. We use some of the Types of Pixel Defects industry's most advanced manufacturing... - Page 26 To qualify for repair or replacement due to pixel defects during the warranty Black Dot Defects period, a TFT Monitor panel in a Philips Black dot defects appear as pixels or flat panel monitor must have pixel sub-pixels that are always dark or 'off'.
- Page 27 BRIGHT DOT DEFECTS ACCEPTABLE LEVEL 1 lit subpixel 2 adjacent lit subpixels 3 adjacent lit subpixels (one white pixel) Distance between two bright dot defects* >15mm Total bright dot defects of all types BLACK DOT DEFECTS ACCEPTABLE LEVEL 1 dark subpixel 3 or fewer 2 adjacent dark subpixels 2 or fewer...
-
Page 28: Customer Care & Warranty
Please contact our Philips Customer Service Representative or local contact center (by Consumer care number) for more details. Philips Customer Care Center number listed below. -
Page 29: Troubleshooting & Faqs 27
• Disconnect the monitor from mains power source immediately for safety 9.1 Troubleshooting • Contact with Philips customer service This page deals with problems that can representative immediately. be corrected by a user. If the problem Imaging Problems persists after you have tried these... -
Page 30: General Faqs
Service contact information listed in set at 2560 x 1440. the Important information manual • Shut down your computer, and contact a Philips customer service disconnect your old monitor, and representative. reconnect your Philips LED monitor. * Functionality is different according to display. - Page 31 Can I connect my LED monitor to please use isopropyl alcohol. Do any PC, workstation, or Mac? not use other solvents such as Ans.: Yes. All Philips LED monitors are ethyl alcohol, ethanol, acetone, fully compatible with standard hexane, etc.
- Page 32 Q10: Are Philips LCD monitors Plug- Q13: How to unlock/lock my hotkey? and- Play? Ans.: Please press for 10 seconds Ans.: Yes, the monitors are Plug-and- to unlock/lock the hotkey, by Play compatible with Windows doing so, your display pops out 11/10, Mac OSX.
- Page 33 This product has been manufactured by and is sold under the responsibility of Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.
