REFRIGERATOR
AW4-4D Defeature (RF30KM)
-160129.indd 1
REFRIGERATOR
FRENCH DOOR REFRIGERATOR
MODEL NAME :
RF30KM*
MODEL CODE :
RF30KMEDB**/AA
CONTENTS
1. PRECAUTIONS (SAFETY WARNINGS) ·······4
2. PRODUCT SPECIFICATIONS ······················8
3. DISASSEMBLY AND REASSEMBLY ·········23
4. TROUBLESHOOTING ································52
5. PBA DIAGRAM ···········································97
6. WIRING DIAGRAM ···································101
7. BLOCK DIAGRAM ····································102
8. MODEL CODE TABLE ······························104
2016. 1. 29.
7:42

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RF30KM Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung RF30KM Series

Summary of Contents for Samsung RF30KM Series

  • Page 1 REFRIGERATOR FRENCH DOOR REFRIGERATOR MODEL NAME : RF30KM* MODEL CODE : RF30KMEDB**/AA REFRIGERATOR CONTENTS 1. PRECAUTIONS (SAFETY WARNINGS) ·······4 2. PRODUCT SPECIFICATIONS ······················8 3. DISASSEMBLY AND REASSEMBLY ·········23 4. TROUBLESHOOTING ································52 5. PBA DIAGRAM ···········································97 6. WIRING DIAGRAM ···································101 7. BLOCK DIAGRAM ····································102 8.

  • Page 2: Important Safety Notice

    SAMSUNG ELECTRONICS AMERICA, INC. Technical Service Guide Copyright ©2016 All rights reserved. This service guide may not be reproduced in whole or in part in any form without written permission from the SAMSUNG ELECTRONICS Company. AW4-4D Defeature (RF30KM) -160129.indd 2 2016. 1. 29.

  • Page 3: Table Of Contents

    Contents 1. Precautions (safety warnings) ..............4 2. Product specifications ................8 2-1) Introduction of Main Function ........................8 2-2) Specifications ..............................10 2-3) Interior Views ..............................11 2-4) Model Specification & Specification Chart ....................12 2-5) Dimensions of Refrigerator (Inch, mm) ....................... 15 2-6) Optional Material Specification........................
  • Page 4 Contents 4. Troubleshooting ..................52 4-1) Function for failure diagnosis ........................52 4-1-1. Test mode (manual operation / manual defrost function) ............52 4-1-2. Display function of Communication error ..................53 4-1-3. Self-diagnostic function ......................... 54 4-1-4. Display function of Load condition ....................57 4-1-5.

  • Page 5: Precautions (Safety Warnings)

    1. Precautions (safety warnings) Precautions (safety warnings) ● Unplug the appliance before replacing or repairing electrical parts. ⇒ Be careful to avoid electric shock. ● Always use only the correct replacement parts. ⇒ Check the model name, rating voltage, rating current, running temperature symbols.

  • Page 6: Warning And Caution

    Precautions (safety warnings) Read all instructions before repairing the product and follow the instructions in order to prevent danger or property damage. Plug out and remove all the items in regrigerator prior to repair. CAUTION/WARNING SYMBOLS DISPLAYED SYMBOLS means "Prohibited". Indicates that a danger of death Warning...
  • Page 7 Precautions (safety warnings) ❈ Please let users know following warnings & cautions in detail. Warning & Caution Customers should not store narrow Drugs requiring precise Customers should not store glass or long bottles or food in a small temperatures should not be stored bottles of liquid in the freezer section.
  • Page 8 Precautions (safety warnings) FLOORING For proper installation, this refrigerator must be placed on a level surface of hard material that is the same height as the rest of the flooring. This surface should be strong enough to support a fully loaded refrigerator, or approximately 660lb (299kg).

  • Page 9: Product Specifications

    2. Product sPecifications Product sPecifications 2-1) Introduction of Main Function Surround Multi Flow • Provides uniform cooling for each shelf and every corner in the fresh food section. This is accomplished by using a center positioned fan and duct with multiple cooling flow openings. Twin Cooling System •...

  • Page 10: New Model

    Product sPecifications ▶ Changing Items Item Details New Model Ez-Open The freezer door and Mid drawer Handle (Flex zone) open and close easily. System The lighting helps you find groceries Emotional Easier by lighting down when you open Lighting Mid drawer(Flex zone) and freezer door. - Easy rail partition can divide off 4 independent spaces easily.

  • Page 11: 2-2) Specifications

    Product sPecifications 2-2) Specifications ELECTRICAL SPECIFICATIONS REFRIGERATOR Defrost Control From 12 to 22 hrs(comp.run ti m e) Thermo Bimetal Protector 140°F(60°C)(off) 104°F(40°C)(on) Defrost Thermistor(502AT) F: 50°F(10°C)(off) R: 59°F(15°C)(off) Electrical Rating 11.6 Amps Maximum Current Leakage 0.25 mA Maximum Ground Path Resistance 0.1 Ohm E n e r g y C o n s u m p t i o n 5 6 2 k W h / y e a r...

  • Page 12: 2-3) Interior Views

    Product sPecifications 2-3) Interior Views Refrigerator Light FF Ice-Maker Sparkling Module Cover (Optional) Sparkling Water Tank (Optional, Inside) Slide-Shelf Foldable-Shelf Foldable-Shelf Slide-Shelf Vertical Hinged Section Door Bins Cylinder Cover (Option) Vegetable & Fruit Drawers Auto Closer Flex Zone Light Auto Closer Convertible Room Water Filter Auto Pull Out Drawer...

  • Page 13: 2-4) Model Specification & Specification Chart

    Product sPecifications 2-4) Model Specification & Specification Chart RF30KM* ITEM Model ① ICE&WATER DISPENSER& SPARKLING WITH FLEX ZONE ② ICE&WATER DISPENSER WITH FLEX ZONE 35 6/8 Inch (908mm) On Cabinet 31 Inch (788mm) W/O Handle 35 1/2 Inch (901mm) External size With Handle 37 7/8 Inch (963mm) W/O Hinge Cap...
  • Page 14 Product sPecifications Items Specification Model MKV190CL2B/E01 Compressor Starting type BLDC Oil Charge FREOL α - 15c Freezer SPLIT FIN TYPE Evaporator Refrigierator SPLIT FIN TYPE Condenser Forced and Natural Convection Type Dryer Molecular shieve XH-9 Capillary tube (Dia x Length) R:0.032"...
  • Page 15 Product sPecifications Items Specification Defrost Heater (FRE) Heated at F Defrost AC 120V, 230W Defrost Heater (REF) Heated at R Defrost AC 120V, 120W F/S : AC 120V, 141W Heater-Ice Maker C/D : AC 120V, 120W Interlock with French DISPENSER Heater AC 120V, 2.5W Heater FRENCH Heater...

  • Page 16: 2-5) Dimensions Of Refrigerator (Inch, Mm)

    Product sPecifications 2-5) Dimensions of Refrigerator (Inch, mm) 35 6/8” 59.7” (1516mm) 4" (102mm) 4" (102mm) 0º~120º 0º~120º 37 7/8" (963mm) 1 3/16" (30.6mm) 35 1/2" (901mm) 5/8" (17.5mm) 5/8" (17.5mm) 1/2" (11.5mm) 1/2" (11.5mm) 2" (50.8mm) 2" (50.8mm) AW4-4D Defeature (RF30KM) -160129.indd 15 2016.

  • Page 17: 2-6) Optional Material Specification

    Product sPecifications 2-6) Optional Material Specification Part Name Part Code AMOUNT FILTER WATER-ASSY DA29-00020B ASSY INSTALL-ACCESSORY DA99-03490Q LED LAMP REF DA97-12606A LED LAMP CASE-VEG R, L DA41-00519S LED LAMP FRE DA41-00676G LED LAMP MID DA41-00676G LED LAMP REF(SIDE) DA41-00519Q AW4-4D Defeature (RF30KM) -160129.indd 16 2016.

  • Page 18: 2-7) Refrigerant Route In Refrigeration Cycle

    Product sPecifications 2-7) Refrigerant Route in Refrigeration cycle Compressor → Condenser → Hot Pipe → Back Cluster Pipe → Dryer → Capillary Tube → Refrigerator Evaporator → Pipe Direct Ice → Freezer Evaporator → Suction Pipe → Compressor AW4-4D Defeature (RF30KM) -160129.indd 17 2016.

  • Page 19: Principle Of Freezeer

    Product sPecifications 2-7-1. Principle of freezeer PIPE DIRECT ICE AW4-4D Defeature (RF30KM) -160129.indd 18 2016. 1. 29. 7:43...

  • Page 20: Operation Theory Of Refrigeration Cycle Components

    Product sPecifications 2-7-2. Operation theory of refrigeration cycle components ■Condenser 1) Role: A device which radiates heat to the outside (water/air) to make liquid state for the high temperature / high pressure gas refrigerant discharged from compressor 2) Types A. Air-cooling Type : Condense air by circulating naturally or manually. 1) Natural Convection Type : Used for the household refrigerator which has small condensing capacity.
  • Page 21 Product sPecifications ■Evaporator 1. Role: As the low pressure liquid refrigerant flowed from capillary absorbs heat inside of the refrigerator, it becomes low pressure gas and refrigerate the foods. 2. Theory: The low pressure refrigerant flowed to evaporator operates cooling which takes ambient evaporated potential heat with maintaining the evaporation up to evaporate completely.

  • Page 22: Refrigeration Cycle Type

    Product sPecifications ※ . Influence of moisture ① Moisture precipitation - Blocked by ice ② Refrigerant and reaction ③ Life reduction of oil ④ Acceleration of oxidization ⑤ Copper plating phenomenon ⑥ Gas dissolution by the interaction of synthetic insulating material (insulator) ※.

  • Page 23: 2-8) Cooling Air Circulation

    Product sPecifications 2-8) Cooling Air Circulation Refrigerator Ice Maker Air-flow Discharge Return Flex Zone Freezer AW4-4D Defeature (RF30KM) -160129.indd 22 2016. 1. 29. 7:43...

  • Page 24: Disassembly And Reassembly

    3. disassembly and reassembly disassembly and reassembly 3-1) PRECAUTION ● Unplug the refrigerator before cleaning and making repairs. ● Remove any foreign matter or dust from the power plug pins. - Otherwise there is a risk of fire. ● Do not use a cord that shows cracks or abrasion damage along its length or at either end. ●...

  • Page 25: 3-2) Refrigerator Door

    disassembly and reassembly 3-2) Refrigerator Door Part name How to do descriptive Picture 1. Remove the 3 screws holding down the Top Table and remove the Top  Table ()  2. Disconnect the electrical () above the upper left door hinge To disconnect the connector () more easily, press the end of the hook () and pull connector.
  • Page 26 disassembly and reassembly Part name How to do descriptive Picture 5. Lift the door straightly up to remove while opening it more than 90°. Be careful not to drop the door. CAUTION 6. With a Philips head screwdriver, remove the screw () attatched to ...

  • Page 27: 3-3) Door Handle Refrigerator

    disassembly and reassembly 3-3) Door Handle Refrigerator Part name How to do descriptive Picture 1. Loosen the Set Screw situated at the end of the inner part of handle about 0.1in by using Hex wrench. Door Handle Fridge 2. Pull the Set handle out by moving it straight up.

  • Page 28: 3-5) Refrigerator Light

    disassembly and reassembly 3-5) Refrigerator Light Part name How to do descriptive Picture 1. Press the tabs on the back of the Lamp Cover and take it off. Refrigerator Light 2. Remove the 2 screws And separate the LED panel. 3-6) Cover-Display &...

  • Page 29: 3-7) Water-Dispenser

    disassembly and reassembly 3-7) Water-Dispenser Part name How to do descriptive Picture 1. Disengage the Housing Connector by pushing a flat-blade screwdriver. 2. Remove 2 screws of the Case Ice Route Assy. Water-Dispenser 3. Pull the Case Ice Route Assy. (Ice/Water model ) 4.

  • Page 30: 3-8) Glass Shelf

    disassembly and reassembly 3-8) Glass Shelf Part name How to do descriptive Picture Remove the shelf by lifting the front Glass Shelf part of the shelf up and pulling it out. 3-9) Foldable Glass Shelf Part name How to do descriptive Picture 1.

  • Page 31: 3-11) Case Water Filter

    disassembly and reassembly 3-11) Case Water Filter Part name How to do descriptive Picture To disassemble the Case Water Filter, remove the water filter and all drawers and shelves. 1. Remove the 3 screws holding down the Top Table and remove the Top Table ().

  • Page 32: 3-12) How To Remove The Carbonator Kit

    disassembly and reassembly Part name How to do descriptive Picture 5. Disconnect the 2 Housing  connectors (). Case Water Filter 6. Lift and pull the Case Water Filter out. 3-12) How to Remove the Carbonator Kit Part name How to do descriptive Picture 1.
  • Page 33 disassembly and reassembly Part name How to do descriptive Picture 4. Remove the CO2 Cylinder(60L) by turning it counter clockwise. 5. Take off () by removing the two screws.  6. Remove the three screws. How to Remove the Carbonator Kit 7.

  • Page 34: 3-13) Motor Damper

    disassembly and reassembly 3-13) Motor Damper Part name How to do descriptive Picture 1. Remove the 2 screws under the. water filter case and take off the cover damper (). Motor Damper 2. Disengage 2 housing connector. 3. Take off the Motor Damper by pulling a flat-blade screwdriver.

  • Page 35: 3-14) Water Filter (Assembly & Disassembly)

    disassembly and reassembly 3-14) Water Filter (Assembly & Disassembly) Part name How to do descriptive Picture 1. Turn the water filter count- clockwise. (Refer to the picture) 2. Remove the water filter by pulling it. (Refer to the picture) Water Filter 3.

  • Page 36: 3-15) Gallon Door Bin

    disassembly and reassembly 3-15) Gallon Door Bin Part name How to do descriptive Picture Gallon Door Bin 1. Remove the door bin by moving (Right) straight up. 2. a. Remove dis door bin by moving Gallon Door Bin straight up. (Left) b.

  • Page 37: 3-16) Vertical Hinged Section

    disassembly and reassembly 3-16) Vertical Hinged Section Part name How to do descriptive Picture 1. Remove 2 screw cap parts with a flat-blade(-) screwdriver. (Refer to the picture) Before doing the above, make sure that the unit is unplugged. CAUTION 2.

  • Page 38: 3-17) Evaporator Cover In Refrigerator

    disassembly and reassembly 3-17) Evaporator Cover In Refrigerator Part name How to do descriptive Picture 1. Remove the angle cap with a flat- blade screwdriver. (Refer to the picture) Be careful not to scratch or break the parts CAUTION 2. Loosen the 4 screws, which fix the Evaporator cover ...

  • Page 39: 3-18) Evaporator In Refrigerator

    disassembly and reassembly 3-18) Evaporator In Refrigerator Part name How to do descriptive Picture 1. Disconnect the housing connector <Left> part on left side. Before doing the above, make sure that the unit is unplugged. CAUTION <Right> 2. Disconnect the housing connector on right side.

  • Page 40: 3-19) Freezer Door

    disassembly and reassembly 3-19) Freezer Door Part name How to do descriptive Picture 1. Pull out the Pull Out Drawer by maximum. 2. After lifting the Pull Out Drawer up holding both sides, remove it at the rail system. 3. Remove the Tilting Pocket() by ...

  • Page 41: 3-20) Convertible Door

    disassembly and reassembly 3-20) Convertible Door Part name How to do descriptive Picture 1. Pull the and remove the convertible room () by pulling it to your body with both hands. open to full extension. 2. Remove the cover housing () by a flat-blade screwdriver.

  • Page 42: 3-21) Ice-Maker

    disassembly and reassembly 3-21) Ice-Maker Part name How to do descriptive Picture 1. When pressing the Energy-Saver and the Fridge buttons on the Display together for 8 seconds at the same time, it will convert to the Test Mode and the entire Display function will be off.

  • Page 43: 3-22) Ice-Maker

    disassembly and reassembly 3-22) Ice-Maker Part name How to do descriptive Picture 7. Remove the screw from the Duct Tray-ice. 8. With a flat blade screwdriver, push the duct to the right and remove it from the locking tab. (Refer to the image.) 9.

  • Page 44: 3-23) Auger Motor Fan

    disassembly and reassembly 3-23) Auger Motor Fan Part name How to do descriptive Picture 1. Disconnect the FAN-AUGER-ASSY Connector. 2. Hold the Hook on the bottom of the Auger Motor Fan FAN-AUGER-ASSY and lift it up to make it free from the Locking Tab. 3.

  • Page 45: 3-24) Flex Zone Light

    disassembly and reassembly 3-24) Flex Zone Light Part name How to do descriptive Picture 1. Remove the cover Flex zone lamp () by a flat-blade screwdriver. Flex Zone Light 2. Disengage the housing. 3-25) Freezer Light Part name How to do descriptive Picture 1.

  • Page 46: 3-26) Side Light

    disassembly and reassembly 3-26) Side Light Part name How to do descriptive Picture 1. Remove the cover Side lamp () by a flat-blade screwdriver. 2. Separate the Side lamp from the Refrigerator Light case. 3. Disengage the housing. 3-27) Door Switch In Freezer Part name How to do descriptive Picture...

  • Page 47: 3-28) Evaporator Cover In Freezer

    disassembly and reassembly 3-28) Evaporator Cover In Freezer Part name How to do descriptive Picture 1. Remove the freezer door and freezer drawer by pulling out the drawer and then unscrewing 2 screws. Evaporator Cover In 2. Lift up the evaporator cover. Freezer 3.

  • Page 48: 3-30) Comp Cooling Fan

    disassembly and reassembly 3-30) Comp Cooling Fan Part name How to do descriptive Picture 1. Unscrew 5 screws of COVER COMP. 2. Remove the DRAIN HOSE. 3. Remove 1 screw. 4. Disengage the HOUSING Comp Cooling Fan CONNECTOR. (Refer to the picture) 5.

  • Page 49: 3-31) Comp Cooling Fan Motor

    disassembly and reassembly 3-31) Comp Cooling Fan Motor Part name How to do descriptive Picture 1. Remove the screw with a flat blade screwdriver. 2. Remove the motor fan by pulling the fan out while graping the motor part. Comp Cooling Fan 3.

  • Page 50: 3-32) Relay O/L

    disassembly and reassembly 3-32) Relay O/L Part name How to do descriptive Picture 1. Remove Cover Relay. relay o/l 2. Remove the relay O/L with a flat- blade screwdriver. (Refer to the picture) AW4-4D Defeature (RF30KM) -160129.indd 49 2016. 1. 29. 7:43...

  • Page 51: 3-33) Compressor

    disassembly and reassembly 3-33) COMPRESSOR Part name How to do descriptive Picture 1. Cut off the LOKRING connecting the COMP and the CONDENSER with a Pipe Cutter. (Red-line marking points) 2. Cut off the LOKRING connecting the CONDENSER and the HOT PIPE with a Pipe Cutter.

  • Page 52: 3-34) Electric Box

    disassembly and reassembly 3-34) Electric Box Part name How to do descriptive Picture 1. Remove the 2 screw attached to the upper left and right Case PCB Panel with a phillips screwdriver(+). 2. Disengage all housing connectors from the main PCB. PBA Main Before doing the above, make sure that the unit is unplugged.

  • Page 53: Troubleshooting

    4. troublesHooting troublesHooting 4-1) Function for failure diagnosis 4-1-1. Test mode (manual operation / manual defrost function) • If Freezer Key + Lighting Key on the front of panel are pressed simultaneously for 8 seconds , it will be changed to the test mode and all displays on the front of panel will be off. •...

  • Page 54: Display Function Of Communication Error

    troublesHooting 2) Forced Defrost 2-1) When you press any key one more time at Fridge off Forced Operation [OF r], rd lights up on the Display Panel. At this time, the Forcd Operation stops immediately and R-Defrost will be performed at the same time.

  • Page 55: Self-Diagnostic Function

    troublesHooting 4-1-3. Self-diagnostic function 1) Self-diagnostic function in the Initial power ON 1-1) Micom operates self-diagnostic function to check the temperature sensor condition within 1 second when the refrigerator turned On initially. 1-2) If bad sensor is detected by the self-diagnostic function, the applicable display LED will blink for 0.5 sec. At this moment, there is no beep sound.(Refer to self-diagnostic CHECK LIST) 1-3) Self-diagnostic button is recognized only when the error is displayed by the bad sensor.
  • Page 56 troublesHooting ※ R Self-diagnostics check list Item Trouble contents Diagnostic method The voltage of MAIN PCB CN30- “3” N76-”1”: FZ-Sensor Error shall be between 4.5V~1.0V The voltage of MAIN PCB CN30- “6” N76-”1”: FF-Sensor Error shall be between 4.5V~1.0V Display error : separation of sensor FZ-DEF-Sensor The voltage of MAIN PCB CN30- “5”...
  • Page 57 troublesHooting Item Trouble contents Diagnostic method Display error when the Ice Maker(FZ) kit The voltage of MAIN PCB CN76-”2”(Black) ↔ Ice Room-FAN Error operate moving ice over 3 times or it is CN76-”1” (Gray): shall be between 7V~12V not leveled. Main mycom ↔...

  • Page 58: Display Function Of Load Condition

    troublesHooting 4-1-4. Display function of Load condition ① ① ② ① If Freezer Key + Fridge Key are pressed simultaneously for 6 seconds, ALL ON/OFF will blink with 0.5interval for 2 seconds. ② If take the finger off from above keys and press Lighting, load condition mode will be started. 1) If Freezer Key + Fridge Key are pressed simultaneously for 6 seconds during normal operation, the temperature setting display of fresh food and freezer compartments will blink ALL ON/OFF with 0.5 for 2 seconds.

  • Page 59: Display Contents

    troublesHooting ※ Load mode Check list Display LED Display contents Operation contents When FF compartment FAN operates with high R-1-ⓐ R-FAN High speed, applicable LED Blink When FF compartment FAN operates with low R-1-ⓑ R-FAN Low speed, applicable LED Blink When FF compartment defrost heater operates, LED R-1-ⓒ...

  • Page 60: Cooling Off Mode Setting Function

    troublesHooting 4-1-5. Cooling OFF mode setting function ① ① ① ① If Freezer Key + Fridge Key + Alarm Key are pressed for 5 seconds, Cooling Off mode will be started. 1) If Freezer Key + Fridge Key + Alarm Key are pressed simultaneously for 5 seconds during normal operation, Cooling Off mode will be started with buzzer sound(ding-dong).

  • Page 61: Option Setting Function

    troublesHooting 4-1-6. Option setting function • If Alarm Key + Fridge Key are pressed simultaneously for 12 seconds during normal operation, fresh food and freezer compartments temperature display will be changed to option setting mode. KEY operation method for changing to option mode ①...
  • Page 62 troublesHooting Code Reference Value 1) For example, if you want to change freezer compartment standard temperature to -4℉(-2°C) by operating option, do as below. This function is for changing the standard temperature. In -2℉(-19°C) of current temperature of freezer compartment, if you make the temperature lower to -4℉ (-2°C) by the option, the standard temperature would be controlled -6℉(-21°C) Therefore, if you change the setting of temperature option to -2℉(-19°C) on the panel, the appliance will be operated with -6℉(-21°C).

  • Page 63: Option Table

    troublesHooting 4-1-7. Option TABLE 1) Temperature changing table of freezer compartment Freezer Temp Shift Set item Reference Fridge Room 7-SEG Value Setting value Temp. compartment compensation Code 0℉(0.0℃) -1℉(-0.5℃) -2℉(-1.0℃) -3℉(-1.5℃) -4℉(-2.0℃) -5℉(-2.5℃) -6℉(-3.0℃) -7℉(-3.5℃) +1℉(+0.5℃) +2℉(+1.0℃) Code Reference Value +3℉(+1.5℃) +4℉(+2.0℃) +5℉(+2.5℃)
  • Page 64 troublesHooting 3) Operation rate changing table of dispenser heater Set item Dispenser Heater Rate Fridge Room 7-SEG Reference Value Setting value Rate change compartment Code +0.0% + 20% operation ( up to 100% ) Code Reference Value ex) If you want to change the dispenser heater operation rate to +20% 4) Temperature changing table of Pantry/Mid Drawer Room Set item...
  • Page 65 troublesHooting 5) Amount of water supply to ice tray Set item Amount of Water Supply Reference Fridge Room 7-SEG Value Setting value Amount of water compartment supply Code setting value Setting value + 10cc Code Reference Value ex) If you want to change the amount of water supply to ice tray to Setting value + 10cc 6) Time changing table of ice maker dropping standby time Set item...
  • Page 66 troublesHooting 7) Temperature changing table of ice room Set item Ice Room Temp Shift Reference Fridge Room 7-SEG Value Setting value Temp. compartment compensation Code 0℉(0.0℃) -1℉(-0.5℃) -2℉(-1.0℃) -3℉(-1.5℃) -4℉(-2.0℃) -5℉(-2.5℃) -6℉(-3.0℃) -7℉(-3.5℃) +1℉(+0.5℃) +2℉(+1.0℃) +3℉(+1.5℃) +4℉(+2.0℃) +5℉(+2.5℃) Code Reference Value +6℉(+3.0℃) +7℉(+3.5℃) ex) If you want to change the ice room standard temperature...

  • Page 67: 4-2) Diagnostic Method According To The Trouble Symptom(Flow Chart)

    troublesHooting 4-2) Diagnostic method according to the trouble symptom(Flow Chart) DATA1.Temperature table Resistance value and MICOM port voltage of sensor according to the temperature SENSOR CHIP : based on PX41C, PX41C, 502AT/ 103**(ICE MAKER SENSOR(MOLD)/FULL UP, 20Kohm ( Actual measurement = value of the table below X 2 ) ℃...
  • Page 68 troublesHooting DATA2. Humidity Sensor table - Voltage output table @23°…, 5Vdc --- HTG3515CH/HTG3535CH RH(Temperature compensate ) = RH (Relative Humidity ) + ( Temp(°C) °© 23°C) x 0.05 ℃ ℉ ℃ ℉ ℃ ℉ Voltage Resi s tance Voltage Resi s tance Voltage Resi s tance 2246...

  • Page 69: If The Trouble Is Detected By Self-Diagnosis

    troublesHooting 4-2-1. If the trouble is detected by self-diagnosis - The error of sensor will be displayed on the front of display. when the error of sensor is detected at initial power ON, the appliance will not operated and display of abnormal sensor part will blink.
  • Page 70 troublesHooting 2) If R Sensor has trouble ERROR Code Start Is MAIN PCB DATA1. Connector CN30 and CN76 inserted Temperature table correctly? Bad contact of connector/ insert correctly ** Measuring point of resistance value according to Sensor ** Is R Sensor R : CN30 - “6”...
  • Page 71 troublesHooting 3) If R DEF Sensor has trouble ERROR Code Start Start Is MAIN PCB DATA1. Connector CN30 and CN76 inserted Temperature table correctly? Bad contact of connector/ insert correctly ** Measuring point of resistance value according to Sensor ** R-DEF : CN30-"8"...
  • Page 72 troublesHooting 4) If Ambient Sensor has trouble ERROR Code Start Start DATA1. MAIN PCB Connector CN78 inserted Temperature table correctly? Bad contact of connector/ insert correctly ** Measuring point of resistance value according to Sensor ** Ambient : CN78-”8”↔ “12” measuring resistance value ** Placed in the right top table of upper hinge.
  • Page 73 troublesHooting 5) If F Sensor has trouble ERROR Code Start Start Are MAIN PCB DATA1. Connector CN30 Temperature table inserted correctly? Bad contact of connector/ insert correctly ** Measuring point of resistance value according to Sensor ** F : CN30-“1” ↔ “4” measuring resistance value F Sensor unit normal? ** 0Ω: Short trouble / Ω∞: Open trouble Refer to circuit diagram in the manual...
  • Page 74 troublesHooting 6) If F DEF Sensor has trouble ERROR Code Start Start DATA1. MAIN PCB Connector CN30 and CN76 Temperature table insert correctly? Bad contact of connector/ insert correctly ** Measuring point of resistance value according to Sensor ** F-DEF : CCN30-”5” ↔ CN76-”1” measuring resistance FZ DEF Sensor unit value normal?
  • Page 75 troublesHooting 7) If Ice Room Sensor has trouble ERROR Code Start Start Is MAIN PCB DATA1. Connector CN78 and CN76 inserted Temperature table correctly? Bad contact of connector/ insert correctly ** Measuring point of resistance value according to Sensor ** Ambient : CN78 ”10”↔...
  • Page 76 troublesHooting 8) Mid Drawer Sensor has trouble ERROR Code Start Start Is MAIN PCB DATA1. Connector CN30 and CN76 insert Temperature table correctly? Bad contact of connector/ insert correctly ** Measuring point of resistance value according to Sensor Is Mid drawer Sensor Flex : CN30 ”9”...
  • Page 77 troublesHooting 9) If Humidity Sensor has trouble ERROR Code Start Start Is MAIN PCB Connector CN30 inserted correctly? ** Measuring point of resistance value according to Bad contact of connector /insert correctly Sensor" Humidity : CN30 ”1” ↔ ”3” Is Humidity Sensor Resistance value with opened : about 50Ω...
  • Page 78 troublesHooting 10) Mid Drawer Room Damper Heater has trouble (OPTION) ERROR Code Start Start Is Damper Heater normal?(about135ohm) Bad contact of connector/ insert correctly Measure the voltage of Resistance Is MAIN PCB connector between ① - ② after (CN77) inserted correctly? CN77 connector open / 1350 ohm ±...

  • Page 79: If Fan Does Not Operate

    troublesHooting 4-2-2. If FAN does not operate - The refrigerator of this model has BLDC FAN motor. BLDC motor is driven by DC 7~12V. - On the normal condition of COMP ON, it operates together with F-FAN motor. If door is opened and closed once at a high ambient temperature, it will be operated after 1 minute delay.

  • Page 80: If Ice Room Fan Does Not Operate

    troublesHooting 4-2-3. If ICE Room Fan does not operate - This refrigerator has BLDC FAN motor. BLDC motor is driven by DC7~12V. - When COMP ON, normally operates with F-FAN motor. - If there is any trouble, you should select the self-diagnostic function to check the trouble before power off. - When pressing the ICE TEST S/W for a certain period of time (over Start 1.5sec), the function is accomplished.

  • Page 81: When Ice Maker(Ff) Does Not Operate

    troublesHooting 4-2-4. When ICE MAKER(FF) does not operate 1. Water will be automatically supplied to the Ice Maker depending on temperature & time conditions, and ice will be produced to dispense. 2. Power is applied to one end of the wires. So, make sure to refer to its Exploded View whenever doing the disassembly.

  • Page 82: If Defrost Does Not Operate (F,R Def Heater)

    troublesHooting 4-2-5. If defrost does not operate (F,R DEF Heater) R DEF ERROR F DEF ERROR Start **Measuring point of resistance value according to heater** F-DEF : CN70 “3”(Brown) ↔ CN72 ”3” (Gray) measuring resistance value(63 ohm ± 7%) Are the all deforst R-DEF : CN70 ”1”(White) ↔...

  • Page 83: When Power Is Not Applied

    troublesHooting 4-2-6. When Power is not applied - To check the Inverter PBA, Caution refer to the Operation and Start 'Refer' sections in this There is Over AC 115V and DC 310V manual at the Inverter PBA Power Circuit. So, be cautious when repairing the unit or measuring values..

  • Page 84: When Compressor Does Not Run (Inverter Comp.)

    troublesHooting 4-2-7. When Compressor does not run (Inverter COMP.) Start 10 minutes have passed since COMP was off Check in 10 minutes When Forced Operation Refer to the TEST mode is activated, COMP Function in this manual operates Forced Operation signal sound should be checked F-Sensor is Good 0~800Hz 50%...

  • Page 85: When Alarm Sounds Continuously Without Stop(Related With Buzzer Sound)

    troublesHooting 4-2-8. When alarm sounds continuously without stop(related with buzzer sound) ① If 'ding-dong'sound continuously Start Door is ajar Is door closed completely? Remove causes after comprehending the conditions of interferance by door gasket, food etc, Is water penetrated into the door switch? Replace Door S/W Seperate the door switch andcheck if the Is the door...
  • Page 86 troublesHooting ③ If buzzer does not sound Buzzer is installed on the panel PCB in this model. If buzzer does not sound even though the button is pressed, manual operation is started and door is opened, it should separate panel PCB and check the breakage of buzzer and bad soldering. It is very hard to repair the panel PCB because it consists of SMD assemblies.

  • Page 87: When The Panel Pba Does Not Operate Normally

    troublesHooting 4-2-9. When the Panel PBA does not operate normally ① When the entire or a certain section of the Panel PCB does not light up - There is a MICOM embedded in the Panel PCB. So, take care when doing repairs. And, except the Solder Touch, replace the PCB.

  • Page 88: If Mid Drawer Panel Pcb Is Not Working Normally

    troublesHooting 4-2-10. If Mid drawer Panel PCB is not working normally You should check the display after door opening because the display of this model operates only when the fresh food compartment door is opened. Start room Does R Door switch operate normally? Check and repair the switch * Refer to <how to repair door switch>...

  • Page 89: When Refrigerator Room Lamp Does Not Light Up

    troublesHooting 4-2-11. When refrigerator ROOM Lamp does not light up When controlling the regrigerator light with Regulator(12V) : LED LAMP → Applying to the F/R Room compartment (Option) * If the Vegetable Lamp does not work properly, check the R compartment LED Lamp because it is connected with the R compartment LED Lamp in parallel.

  • Page 90: If Ice Water Is Not Supplied

    troublesHooting 4-2-12. If ICE Water is not supplied 1. Please shut the water supplying prior to repair. 2. Power is applied to the one end of wires. Be careful when disassembling not to get an electric shock. 2) Ice Water(R) Valve Start PCB Typical Ground J23 JUMMPER Is the confirming...

  • Page 91: If Sparkling Is Not Supplied

    troublesHooting 4-2-13. If Sparkling is not supplied 1. Please shut the water supplying prior to repair. 2. Power is applied to the one end of wires. Be careful when disassembling not to get an electric shock. 3. Check the Door while it is being closed. (By using a magnet stick, simulate a door-closed condition.) Start Replace the Dispenser Is the Switch of the Dispenser Lever...

  • Page 92: If Cubed Or Crushed Ice Is Not Supplied

    troublesHooting 4-2-14. If Cubed or Crushed Ice is not supplied Fridge door shall be Start closed during operation. Are Ices ejected? Are Ices in the Ice bucket? Is “Ice Off” mode ① Check the Ice making switch selected on the display ②...

  • Page 93: If Cover Ice Route Motor(Geard Motor) Is Not Working Normally

    troublesHooting 4-2-15. If Cover Ice Route Motor(Geard Motor) is not working normally Caution 1. When replacing the Cover Ice Motor, pull out the plug to avoid an electric shock. 2. Be careful! When disassemble the Cover Ice Motor, spring can jumped out and may cause personal injury. 3.

  • Page 94: Ir Sensor Trouble-Shooting

    troublesHooting 4-2-16. IR Sensor Trouble-Shooting 1. When the IR sensor is defective, ice is not produced even if there is no Ice Maker Error, Ice Maker Sensor Error or the Ice Maker Function Error. (When turning on the Self Diagnosis Function, it does not produce ice even if there is no 14E, 15E or 39E being displayed.) 2.

  • Page 95: Led Blinking Frequency Depending On Protecting Functions

    troublesHooting 4-2-17. LED blinking frequency depending on protecting functions If Failure Condition is detected during compressor is operating, immediately stop Compressor operating and stand by 5 minutes. During this 5 minutes, RPM command signal is not available. It means, even if available RPM command signal is applied to the compressor, it does not work and keep standing by.

  • Page 96: 4-3) General Diagnosis

    troublesHooting 4-3) General diagnosis PROBLEM SOLUTION • Check that the power plug is properly connected. refrigerator • Check if the set temperature on the digital display is warmer than does not work the freezer or fridge inner temperature. If it is, set the refrigerator at all or it colder.
  • Page 97 troublesHooting PROBLEM SOLUTION Ice Maker is • Did you wait for 12 hours after installation of the water supply line not producing before making ice? ice. • Is the water line connected and the shut-off valve opened? • Did you manually stop the ice making function? •...

  • Page 98: Pba Diagram

    This document can not be used without Samsung's authorization 5. Pba diagram Pba diagram 5-1) PBA Layout with part position 1. DC12V, 5V, GND supplied from SMPS PCB (Not Used) 2. Circuit for controlling Step-Valve (3-Way Valve) * Option 3. FAN MOTOR control part : To supply the power from 8.3V ~ 12V according to the motor types.

  • Page 99: 5-2) Pba Layout With Part Position (Inverter Board)

    This document can not be used without Samsung's authorization Pba diagram 5-2) PBA Layout with part position (Inverter Board) 1. PCB Power Supply : From the SMPS circuit, it supplies 13.2V and 5V for the Main PBA control and supplies 15V and 5V to the Inverter circuit for the Compressor control.

  • Page 100: 5-3) Connector Layout With Part Position (Main Board)

    This document can not be used without Samsung's authorization Pba diagram 5-3) Connector Layout with part position (Main Board) Main Valve Mid DRAWER-DOOR Switch OPEN MID DRAWER ROOM DISPLAY ICE Pipe Heater(FF) F/B ICE Water Pipe Heater (FF) Mid Drawer Room LED Driver...

  • Page 101: 5-4) Connector Layout With Part Position (Inverter Board)

    This document can not be used without Samsung's authorization Pba diagram 5-4) Connector Layout with part position (Inverter Board) AW4-4D Defeature (RF30KM) -160129.indd 100 2016. 1. 29. 7:43...

  • Page 102: Wiring Diagram

    This document can not be used without Samsung's authorization 6. wiring diagram wiring diagram AW4-4D Defeature (RF30KM) -160129.indd 101 2016. 1. 29. 7:43...

  • Page 103: Block Diagram

    This document can not be used without Samsung's authorization 7. block diagram block diagram 7-1) Whole block diagram AW4-4D Defeature (RF30KM) -160129.indd 102 2016. 1. 29. 7:43...
  • Page 104 This document can not be used without Samsung's authorization block diagram 7-1) Whole block diagram AW4-4D Defeature (RF30KM) -160129.indd 103 2016. 1. 29. 7:43...

  • Page 105: Model Code Table

    8. model code table 8. model code table AW4-4D Defeature (RF30KM) -160129.indd 104 2016. 1. 29. 7:43...
  • Page 106 Asia: gspn2.samsungcsportal.com North & Latin America: gspn3.samsungcsportal.com China: china.samsungportal.com - This Service Manual is a property of Samsung Electronics Co., Ltd. Any unauthorized use of Manual can be punished under applicable International or domestic law. © Samsung Electronics Co., Ltd.

This manual is also suitable for:

Rf30kmedb aa series

Table of Contents
