MECHLINE AQUATECHNIX TX-i-200 Installation & Operating Manual

Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION &
OPERATING MANUAL
MODELS: TX-i-200 / TX-i-300
CONTENTS:
Chapter
Description
1.
Introduction ........................................................ 1
2.
Ratings and Specifications ................................. 2
3.
Product Safety .................................................... 3
4.
Structure ............................................................. 5
5.
INSTALLATION INSTRUCTIONS ........................... 6
6.
OPERATING INSTRUCTIONS ............................... 8
7.
After Sales and Service Support ........................ 8
8.
Warranty ............................................................. 8

Chapter 1. INTRODUCTION

Thank you for purchasing Mechline's AquaTechnix TX-i intelligent sensor tap. When correctly installed, and operated
in accordance with this Operator Manual, this tap will provide many years of service.
Designed with the most advanced electronics on the market, Mechline's intelligent TX-i boasts a whole host of
benefits including a super-smart instant shut-off valve, extended battery life, and enhanced anti-bacterial
properties.
The TX-i offers supreme water-savings alongside huge hygiene benefits. Its durable, low-maintenance design
makes it an essential addition to busy commercial kitchens and other high-traffic or hygiene-critical environments,
providing long-lasting, hands-free performance in demanding settings.
INSTALLATION & OPERATING MANUAL
Page
REVISION: 06/2025 | page 1 of 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQUATECHNIX TX-i-200 and is the answer not in the manual?

Questions and answers

Related Manuals for MECHLINE AQUATECHNIX TX-i-200

Summary of Contents for MECHLINE AQUATECHNIX TX-i-200

  • Page 1: Table Of Contents

    Operator Manual, this tap will provide many years of service. Designed with the most advanced electronics on the market, Mechline’s intelligent TX-i boasts a whole host of benefits including a super-smart instant shut-off valve, extended battery life, and enhanced anti-bacterial properties.

  • Page 2: Chapter 2. Ratings And Specifications

    AquaTechnix TX-i Electronic Sensor Tap Chapter 2. RATINGS and SPECIFICATIONS Model numbers TX-i-200 TX-i-300 Region UK/International Spout height 200mm 300mm Water Pressure Range 0.5-8 bar (recommended 3 bar) Flow Rate Range Between 3.78 LPM (0.063 LPS) and 8 LPM (0.133 LPS) pressure dependent Operating Temperature 1 to 70°C Voltage Nominal...

  • Page 3: Chapter 3. Product Safety

    AquaTechnix TX-i Electronic Sensor Tap Chapter 3. PRODUCT SAFETY GENERAL ADVICE To ensure optimum performance of your battery-operated sensor tap, follow these guidelines: 3.1.1 Inspect the product for damage carefully before installation. No claims for damage can be accepted after installation.

  • Page 4: Safety Instructions

    2014/30/EU, IP 67. 3.4.2 Mechline’s TX-i sensor tap is supplied to the marketplace having been produced under the control of our comprehensive BSI ISO 9001:2015 Quality Management System (certificate FS 616985) and BSI ISO 14001:2015 Environmental Management (certificate EMS 801683).

  • Page 5: Chapter 4. Structure

    AquaTechnix TX-i Electronic Sensor Tap Chapter 4. STRUCTURE Spout Diffuser casing Flange with O-ring Diffuser Tap fixing kit Protection mask Microvalve Stainless steel hose M8 to 1/2" BSP / PEX lined / WRAS Red LED Sensor and wiring (1000±30 mm) Battery pack 4x AA batteries INSTALLATION &...

  • Page 6: Chapter 5. Installation Instructions

    AquaTechnix TX-i Electronic Sensor Tap Chapter 5. INSTALLATION INSTRUCTIONS Equipment needed: Spanner and 4 x AA batteries. Position the tap on the basin. Carefully push the wiring and hose through the basin hole. Ensure the O-ring is correctly positioned within the flange channel before proceeding. Install the tap fixing kit from beneath the basin.
  • Page 7 If in doubt, contact technical@mechline.com Place 4x standard AA batteries (not supplied) into the battery pack and secure accordingly. When installing batteries, make sure they are inserted correctly, observing the proper polarity ('+' positive and '-' negative).

  • Page 8: Operating Instructions

    Do not use abrasive, chlorine or any other acid-based cleaning products. Chapter 7. AFTER SALES and SERVICE SUPPORT For warranty or spare parts contact technical@mechline.com. Chapter 8. WARRANTY Unless otherwise stated, all products carry a warranty of twenty-four (24) months against manufacturing defect or workmanship on parts with no inclusion for labour or site attendance.
  • Page 9 ©2025 All rights reserved. All material on these pages, including and without limitation text, logos, icons, photographs and all other artwork, is copyright material of Mechline Developments Ltd, unless otherwise stated. Commercial use of this material may only be made with the express, prior, written permission of Mechline. This includes material provided by any third party, including material obtained through links to other sites from Mechline’s pages or its affiliates and commercial associates.

This manual is also suitable for:

Aquatechnix tx-i-300
