- Page 1 Voyager UTP Extender Serial Addendum...
- Page 2 Voyager UTP Extender Serial Addendum The default settings for serial extension (9600bps, 8 data bits, no parity, 1 stop bit, RTS/CTS and DTR/DSR loopback) should be suitable for the majority of applications. This addendum describes how you can adjust the baud rate and hardware flow control for specialist applications. Serial Interface Setup and Operation You can configure the baud rate and flow control protocol using jumpers on the serial daughter board (see Figure 1) in the Remote and/or Local units.
- Page 3 Changing the Baud Rate on the Voyager UTP Local Unit All Local units are supplied with the baud rate preset at 9600/19200. Use this procedure if you want to change the baud rate. 9600 / 19200 1200 1. Locate the Baud Rate jumper block in the Local unit. 2.
- Page 4 Ireland United Kingdom Bay 21 811 W. Evergreen Ave 5 Manhattan Business Park Free Zone West Suite 302A Westgate Shannon, Co. Clare Chicago, IL 60622 London W5 1UP info.ie@daxten.com info.us@daxten.com info.uk@daxten.com www.daxten.ie www.daxten.us www.daxten.co.uk Tel: +353 (0) 61 23 4000...
