Summary of Contents for Daxten VOYAGER IP
- Page 1 Voyager IP User guide...
-
Page 2: Specifications
© Copyright 2006. All rights reserved. Daxten, the Daxten logo, Voyager and The Brains Behind KVM Switching and Sharing are trademarks of Daxten Industries. All other trademarks acknowledged. - Page 3 Voyager IP Introduction The Voyager IP is a device that enables you to control your server over TCP/IP via LAN, WAN or Internet connection, from any location. Product Features Bios level KVM control. Control any server irrespective of the server status or network connectivity. ...
-
Page 4: Network Configuration
To proceed you will need to click Yes. The first warning will disappear when the first client installs the Daxten [Voyager IP] root certificate. The second warning can be avoided by adding a line to your window‟s „hosts‟ file (normally found at \Windows\system32\drivers\etc) The line format should be: any-IP any-name.daxten.kvmip... - Page 5 Server names left as UNUSED cannot be accessed. Install the Switch definition file If the KVM Switch is not listed in the Manufacturer & Model list, contact Daxten for an updated list. Load the Switch definition file on the client computer.
-
Page 6: Security - Ssl Certificate
Locate and install the Switch Definition file, this will update the Manufacturer & Model list. Administration - Serial Settings If Serial Devices are to be connected to the Voyager IP Units, the serial settings need to be configured. From the menu click Serial Settings, the Serial Settings window appears Enter a name for the Serial device, and select the correct parameters for the device. -
Page 7: Maintenance - Firmware Upgrade
Voyager IP or the currently selected server on the KVM Switch connected to the Voyager IP appears. The first time you connect you must install the Daxten Certificate and Active X control. You must be logged on as an administrator on the client computer to install the Active X Control. - Page 8 Full screen mode To work in full screen mode: 1. Ensure that the client computer has the same resolution as the Target Server. 2. Press F11, Internet Explorer window disappears leaving the Explorer toolbar at the top. 3. Right click the Explorer toolbar and check Auto-Hide, the Explorer toolbar disappears leaving you in full screen mode.
-
Page 9: Adjusting The Video Settings
Adjusting the Video settings To change the video settings, from the Toolbar click the Video icon. This will give you the following options: Refresh Manual Video Adjust Auto Video Adjust Refresh – Refreshes the Video image (Press Ctrl + R ). Manual Video Adjust –... -
Page 10: Aligning The Mice Pointers
To record a Key sequence: 1. From the Special Key Manager Box press Record Now, the Add Special Key box appears. 2. Give the key sequence a name in the label box. 3. Click Start Recording. 4. Press the desired keys, the keys appear in the area provided. 5. -
Page 11: Advanced - Mouse Emulation
– defines the maximum mouse report rate. For SUN Solaris the default value is 20, in Max Rate order to support older SUN versions. Daxten Menu features Right click the Daxten logo, a menu appears. From this menu you can access connected devices, and also the following features: – disconnect the session. Disconnect –... -
Page 12: Video Resolution And Refresh Rates
Troubleshooting - Restoring factory defaults (Hard Reset) You can restore the factory setting through the Web interface as described on page 7. However if you cannot access the system e.g. you have forgotten the User Name or Password, you can restore the factory defaults by performing a Factory Reset. -
Page 13: Service Information
Limited Warranty Daxten warrants to the end user that this product is and will be free from defects in materials and workmanship for a period of 24 months from the date of purchase. If during the warranty period the product should fail, the purchaser must promptly call Daxten for a RETURN MATERIALS AUTHORIZATION (RMA) number. - Page 14 Ireland Worldwide United Kingdom Bay 21 info.eu@daxten.com 5 Manhattan Business Park Free Zone West www.daxten.eu Westgate • Shannon, Co. Clare London W5 1UP info.ie@daxten.com info.uk@daxten.com www.daxten.ie www.daxten.co.uk info.us@daxten.com Tel: +353 (0) 61 23 4000 Tel: +44 (0) 20 8991 6200 www.daxten.us...
