Page 6: Spm-010 / Spm-010Bc Sump Pump Monitor And Control System
User Guide About This Guide This user guide provides detailed instructions for setting up and using the SPM-010 and SPM- 010BC sump pump monitoring and control devices. These devices are designed to help homeowners monitor critical sump pump parameters and prevent flooding due to equipment failure. -
Page 7: Spm-010Bc
• Displays device status and battery charge • Sends SMS alarms via a connected home device SPM-010BC The SPM-010BC provides independent monitoring and control via cellular (LTE) connectivity. • Monitoring and Control: Works continuously, without requiring a home smartphone or tablet. -
Page 8: Device Advantages
Device Advantages SPM-010 • Operates without relying on Wi-Fi or internet • Real-time data on water level, power, and temperature • Optional pump control using the SSR-CU module • Continues monitoring during power outages Note: Requires a stationary smartphone or tablet at home for full functionality... -
Page 9: Figure 2 Spm-010 Monitoring And Control Implementation
Bluetooth communication - True Water Level - Power Backup Option - Power and Operation Statuses - Air Temperature ALARM SPM-010 Sump Pump Monitoring and Control with home stand Smartphone/Tablet Figure 2 SPM-010 Monitoring and Control Implementation iPhone/iPAD House Bluetooth Zone SMS:... -
Page 10: Techn M Ical Specifications
BLE 4.2, 2.4 GHz integrated antenna FCC Compliance FCC CFR47, Part 15 and ARIB STD-T-66 Pump Control Interface Two-pin LED control (max 3 mA) via SSR-CU module SPM-010 App Compatibility iOS 14.5 and above SPM-010BC Cellular Network AT&T (or other providers) LTE-M SPM-010BC Antenna... -
Page 11: What's In The Box
What's in the Box Configuration 1: SPM-010 Kit SPM-010 unit (see Figure 6) • • WS-010 wire water level sensor or KUS SSS/SSL resistive sensor Note: KUS sensor is required for pump control • AA-size dummy battery (to be installed in empty battery slot) 120V AC to 5V DC power adapter (see Figure 6) •... -
Page 12: Figure 7 Ssr-Cu Pump Control Power Unit
Figure 7 SSR-CU Pump Figure 8 LTE Band Antenna Control Power Unit... -
Page 13: Installation And Adjustment
Before beginning installation, ensure the power is disconnected from all sump pump circuit breakers. If you're not familiar with electrical work, contact a licensed electrician or plumber. Connections and Connector Panel The provides guideline for SPM-010 and SPM-010BC connections. 120AC to 5VDC 0.5A Adapter... -
Page 14: Ws-010 Sensor Installation (Without Sip - Sensor Installation Pipe)
AC Adapter WSU050-1500-R SPM- Switch 010BC Cable Zip Ties Connector Silicone cover – mounted on wall Sump Pump Switch Sump Cover Ltop = 2" - 3" (51mm – 76mm)) Bottom Sump Pump Figure 10 WS-010 Sensor (without SP) and SPM-010/SPM-010BC Installation... -
Page 15: Ws-010 Sensor Installation (With Sip - Sensor Installation Pipe)
Switch Connector WS-010 Silicone cover – mounted on wall Sump Pump Switch Sump Cover Ltop = 2" - 3" (51mm – 76mm)) ¼ PEX Pipe (SIP) Pipe Edge Bottom Sump Pump Figure 11 WS-010 Sensor with SIP and SPM-010 Installation... -
Page 16: Kus Sss/Ssl Resistive Sensor Installation
3. Install and Seal Place the sensor in the hole and seal with waterproof silicone. Avoid screws; silicone sealant is sufficient. Figure 12 : KUS SSS sensor and SPM-010 installation diagram Figure 13 : SPM-010BC installation with KUS SSS sensor LTE Band MIMO... -
Page 17: Figure 13 Spm-010Bc Installation Example For Monitoring Function With Kus Sss Sensor
Figure 13 SPM-010BC installation example for Monitoring function with KUS SSS sensor... -
Page 18: Emergency Pump Setup (With Ssr-Cu Module)
If using an emergency sump pump setup: • Install the SSR-CU control module between the sensor and the pump. • The resistive sensor (e.g., KUS SSS) is required for this configuration. See Figure 14: SPM-010/SPM-010BC with Emergency Pump and SSR-CU Power 120VAC, 60Hz Outlets Backup Unit... -
Page 19: Operation
Tips, Warnings). Operation Powering On and Basic Use Dummy Cell Installation (SPM-010 Only) Before first use, you must install the included dummy battery in the SPM-010 device. Steps: 1. Remove the silicone protective cover. Figure 15 : Removing Silicon Cover 2. -
Page 20: Device Controls And Indicators
Figure 15 Silicon Cover Removing Figure 16 Dummy Cell Installation Device Controls and Indicators Both models have a simple, intuitive front panel: Power Button – Turns the unit on/off. • LED Indicator – Blinks approximately every 1.5 seconds during normal operation. •... -
Page 21: Using The Ios Application
Figure 17 SPM-010 and SPM-010BC Front Panels Using the iOS Application Installation Download and install the SPM-010 App from the AppStore on your iPhone or iPad. Setup for SPM-010 Users If using a smartphone/tablet for monitoring and alerts: 1. Create a new Contact on your iOS device:... -
Page 22: Figure 18 Spm-010 Activation Message And Spm-010Bc (In Case Of Lte Is Connected)
: Confirmation Message on Startup If SMS alerts are not required, this step is optional. Figure 18 SPM-010 Activation Message and SPM-010BC (in case of LTE is connected) Activation direct SMS message Figure 19 Message Phone number at start (SPM-010 example) -
Page 23: Messaging, Alerts, And Operating Conditions
Figure 20 iOS Application Screenshot for SPM-010BC device version. Messaging, Alerts, and Operating Conditions The SPM-010 and SPM-010BC devices notify you of key status changes through visual indicators, in-app messages, and SMS alerts (when configured). Here's how each scenario is... -
Page 24: Normal Operation
Normal Operation SPM-010 • Power is connected and stable • Battery is charging or fully charged • Water level is below the alarm threshold • No sound or visual alarms Status indicator shows “Normal” • SPM-010BC • Power is connected •... -
Page 25: Figure 21 Power Loss Screenshot, Power Loss Alarm Message And Power Return Message
Figure 21 Power Loss Screenshot, Power Loss Alarm message and Power Return Message SPM-010BC • Sends SMS directly using LTE When power is restored, a “PWR OK” message is automatically sent •... -
Page 26: Water Level Alarm
• The water level bar on the app turns red (above 70% - adjustable) • A sound alarm is triggered on the paired iOS device (SPM-010) • SMS alert is sent (SPM-010BC or RMS-enabled SPM-010) When water drops below 5%, a “Water OK” message is sent to confirm normal status. -
Page 27: Figure 23 Spm-010 Water Level Alarm Screenshots, Water Level Alarm Message And Water Level Return Message
Figure 23 SPM-010 Water Level Alarm Screenshots, Water Level Alarm message and Water Level Return message Figure 24 SPM-010BC Water Level Alarm Screenshots, Water Level Alarm message and Water Level Return message... -
Page 28: Battery Charging Status
The device shows “Battery Charging” on its status line • • Indicates the unit switched to charging mode after a power loss Figure 25 Figure 26 & : Charging Indicator Screens Figure 25 SPM-010 Normal operation with battery charging screenshot... -
Page 29: Low Temperature Alert
Figure 26 SPM-010BC Normal operation with battery charging and Activation SMS screenshot Low Temperature Alert If the ambient temperature drops below 45°F (7°C): An SMS message is sent with the “Low Temperature” alert and the actual reading • Once temperature rises back above 45°F, a “Temperature Norm” message is sent •... -
Page 30: Requesting System Status (Spm-010Bc Only)
: SMS Response with Current Parameters Figure 28 Request Current parameters and response SMS message with current parameters Battery Safety and Handling The SPM-010 and SPM-010BC both use a 3.7V Lithium-ion protected battery to ensure uninterrupted operation during power outages. Safety Features: •... -
Page 31: Important Guidelines
Important Guidelines: • Do not use the device with a damaged battery • Do not attempt to replace the battery with a non-approved model • Battery is rated for approximately 500 charge cycles • Store the device in a cool, dry place to extend battery life Always handle batteries with care. -
Page 32: Troubleshooting Guide
SumpPumpMonitorV010 Go to iOS Settings > Bluetooth, tap on , and select connect "Forget This Device." Then restart both the SPM-010 and your phone. No activation SMS Double-check the contact entry in your iOS device (see app setup sent instructions). -
Page 33: Appendix A: Bluetooth Scanner & Sensor Calibration
SPM-010, including how to perform WS-010 sensor calibration and set resistive sensor parameters using the TI SimpleLink Starter app. Using a Bluetooth Scanner Application A BLE scanner app allows you to connect directly to the SPM-010 and SPM-010BC for configuration and diagnostics. Recommendation is to use TI SimpleLink Starter App: •... -
Page 34: Figure 30 Screenshot Example
Steps: Note: If you have previously paired any SPM-010 device, go to Settings>Bluetooth and remove it from list (see Figure 30) by using Forget This Device option 1. Download and install the BLE Scanner app from the App Store. 2. Open the app and scan for nearby BLE devices. -
Page 35: Figure 31 List Of Devices And Services
Figure 31 List of devices and Services Figure 32 Services... -
Page 36: Figure 33 Command Write Example
Figure 33 Command Write Example... -
Page 37: Ws-010 Sensor Settings And Calibration
WS-010 Sensor Settings and Calibration If you are using the WS-010 wire sensor, you may need to calibrate it if the default settings do not match your sump depth. Default Calibration Settings: • 0% Water Level: 0 mm (sensor dry) •... -
Page 38: Appendix B: Spm-010Bc Special Operation Modes
Phone Number: +1XXXXXXXXXX (the number to receive SMS) 3. Open the SPM-010 App. Wait until the status bar displays: Normal / LTE Connected 4. The PNT Button (Phone Number Transfer) will appear for 15 seconds. 5. Tap the PNT button once and wait 20–30 seconds for the number to be saved. -
Page 39: Method 2: Using The Ti Simplelink Starter App
Figure 34 Phone Transferring Mode by using SPM-010 application Method 2: Using the TI SimpleLink Starter App This method allows you to manually send configuration commands to the SPM-010BC. Prerequisites: • TI SimpleLink Starter app installed • BLE connection to SPM-010BC established •... -
Page 40: Lte Antenna Location Adjustment
Achieve a signal strength better than -100 dBm during initial installation. Signal Optimization Mode ("LTE Mode") How to Enter LTE Mode: 1. Open the SPM-010 App on your iOS device. Normal / LTE Connected 2. Wait for the status to show: 3. -
Page 41: Figure 35 Lte Operation Mode
Figure 35 LTE Operation Mode... - Page 42 The series of commands need to be sent for phone transferring (see Table 1 Table 1 Phone Transferring Commands Command 95 Country Code = 1 Phone Number Digits: Area Code Example 105 Area Code D1 Command 115 Area Code D2 Command 125 Area Code D3 Command Phone Number 135 Phone Number D1 Command...
-
Page 43: Support & Contacts
Support & Contacts For the most up-to-date information about the Electronic Design Service product, go to the Electronic Design Service website at www.eldesignservice.com. Technical Support : Email: support@eldesignservice.com www.eldesignservice.com...
