Summary of Contents for Nemo SO-HD-18-6Li-100
- Page 2 Functional Description and Specifications Intended Use The Nemo Submersible Special Ops Hammer Drill is intended to drill tough materials such as cement, brick, blocks, or stone, and can be used underwater, in wet conditions, and on dry land. Packing List...
-
Page 3: Technical Specifications
Technical Specifications Nemo Submersible Special Ops Hammer Drill Model SO-HD-18-6Li-100 Battery pack voltage 18V Li-ion Battery cell specification No load speed (two speeds) 0 – 400 / 0 – 1500 RPM No load IPM 0 – 17600 IPM Maximum torque... - Page 4 Safety Warnings Warning: Read all safety warnings and instructions, and save them for future reference. Failure to adhere to these warnings can result in serious injury and damage to equipment. Work Area Safety ♦ All work should be done in accordance with the local, state, and government occupational safety and health guidelines.
- Page 5 Caution: Under no circumstances should the power tool be opened for repairs or any other purpose by anyone other than an after-sales service technician authorized by Nemo Power Tools. Opening the power tool invalidates the manufacturer warranty. ♦ Use power tools, accessories, and tool bits in accordance with...
- Page 6 Rechargeable Battery Safety ♦ Use only the battery pack supplied with your power tool. ♦ When the battery pack is not in use, keep it away from other metal objects like paper clips, coins, keys, nails, screws, which can make a connection from one terminal to another. ♦...
- Page 7 If using the drill above water or in hot conditions, cool the tool down by dipping it in cool water regularly to prevent overheating. Getting Started with the Special Ops Hammer Drill Your Nemo Submersible Special Ops Hammer Drill (SO-HD-18-6Li-100) includes the following main components:...
- Page 8 Charging the Battery The Li-ion batteries are supplied partially charged, and must be charged to full capacity using the battery charger provided with the hammer drill before using the hammer drill for the first time. Caution: Only use the battery charger provided with the hammer drill.
- Page 9 The battery begins charging as soon as it is connected to the charger. ⬥ A steady red light on the battery charger indicates that the battery is charging. ⬥ A steady green light on the battery charger indicates that the battery is fully charged. Note: The battery is equipped with an NTC temperature controller that only allows it to be charged when its temperature is between 32˚...
- Page 10 Removing a Battery from the Special Ops Hammer Drill 1. Unfasten the two plastic clips on the side.. 2. Pull the battery pack out and down, without exerting any force. Inserting a Tool in to the Special Ops Hammer Drill The hammer drill spindle is locked whenever the On/Off trigger is not pressed.
- Page 11 2. The keyless chuck is secured with a securing screw to prevent it from unintentionally coming loose from the hammer drill spindle. Remove this screw by completely opening the chuck and unscrewing the screw, which has a left-handed thread, in a clockwise direction.
- Page 12 Connect the pressure balancing kit to the drill 1. Stand drill upright on a horizontal flat surface resting on its base. 2. Take the pressure balancing kit and place it on top of the Special Ops Hammer Drill. Align the two holes on the pressure balancing kit centre plate with the corresponding threaded holes on top of the drill.
- Page 13 3. Unscrew the red valve cap (valve A) on the back of the drill and place to one side. Take Tube 1 and attach one end to the back of the drill where you have removed the red screw cap. Attach the other end to the right hand side outer screw (valve E).
- Page 14 4. Take Tube 2 and attach one end to the right hand side inner screw (valve D). Connect the other end to the outer left hand screw (valve C). Connect the red pressure pump with valve B . Pump until desired pressure is reached. Pressurizing the Special Ops Hammer Drill for Underwater Your Special Ops Hammer Drill can be used in any wet conditions, and can be submerged and used underwater at depths of up to...
- Page 15 Pressurize the Special Ops Hammer Drill according to the depth to which you are going to submerge it, as follows: Depth in meters Depth in feet Pressure Up to 5m 16 feet Minimum 15 psi (1 Bar) Up to 10m 33 feet Minimum 29 psi...
- Page 16 Best Practices for Underwater Operation Your Nemo Submersible Special Ops Hammer Drill is designed to be waterproof, so that it can be used both on land and underwater. To obtain the maximum serviceable life of your hammer drill, adhere to the following best practices when using the hammer drill underwater: ♦...
-
Page 17: Setting The Working Mode
Operating the Special Ops Hammer Drill Setting the Working Mode The Special Ops Hammer Drill can function in regular drill mode, as a regular drill and driver, or in hammer mode. For more information, see Performing Special Ops Hammer Drill Operations with the Special Ops Hammer Drill, page 20 , and Performing Regular Drill Operations with the Special Ops Hammer Drill, page 20 . - Page 18 ⬥ To work in hammer mode, turn the mode selection ring until the hammer symbol on the mode selection ring is aligned with the single dot on the middle ring. Important: Only use the Special Ops Hammer Drill in hammer mode when the torque is set to the maximum, and the hammer symbol on the mode selection ring is aligned with the single dot on the middle ring.
- Page 19 the maximum torque (three dots), the silver notch pops out and locks. Important: Only use the Special Ops Hammer Drill in hammer mode when the torque is set to the maximum, and the hammer symbol on the mode selection ring is aligned with the single dot on the middle ring, as described in Setting the Working Mode, page 16 .
- Page 20 Selecting the Gear Speed 1. Set the rotational direction switch to the middle position. Caution: To minimize the risk of accidental activation, always ensure the rotational direction switch is in the neutral (middle) position before performing any e Special Ops Hammer Drill, a s maintenance work on th well as during transportation and storage.
-
Page 21: Hammer Drill
Performing Special Ops Hammer Drill Operations with the Hammer Drill in hammer mode when drilling Use the Special Ops Hammer Drill hard materials, such as concrete or stone. 1. Insert a tungsten-carbide tipped bit into the Special Ops Hammer Drill. Position the tool tip against the workpiece, switch on the agai nst Special Ops Hammer Drill, and lightly press the tool tip... -
Page 22: Maintenance
Caution: Under no circumstances should the Special Ops Hammer Drill be opened for repairs or any other purpose by anyone other than an after-sales service technician authorized by Nemo Power Tools. Opening the Special Ops Hammer Drill invalidates the manufacturer warranty. - Page 23 At the end of its lifecycle, the Special Ops Hammer Drill, its accessories, and packaging should be sorted for environmentally friendly recycling. Do not dispose of the battery pack in household waste, fire, or water. Battery packs should be collected, recycled, or disposed of in an environmentally friendly manner.
- Page 24 Caution: Under no circumstances should the Special Ops Hammer Drill or accessories be opened for repairs or any other purpose by anyone other than an after-sales service technician authorized by Nemo Power Tools. Opening the Special Ops Hammer Drill invalidates the manufacturer warranty.
- Page 25 Battery Safety Feature A battery that " fails " or seems to have a short life before it shuts down , may simply be a battery that has gone into its SAFE mode . A battery that has experienced an excessive current draw from a short circuit , or a high current draw when the tool was under an excessive load, may shut down prematurely .
- Page 27 Disclaimer : Nemo Power Tools Ltd reserves the right to change the contents of this manual at any time without prior notice . Nemo Power Tools Ltd www.nemopowertools.com...
