TRF7964A Multiprotocol Fully Integrated 13.56-MHz RFID Reader and Writer IC

1 Device Overview

1.1

Features

• Completely Integrated Protocol Handling for

ISO15693, ISO18000-3, ISO14443A/B, and

FeliCa™

• Integrated State Machine for ISO14443A

Anticollision (Broken Bytes) Operation

• Input Voltage Range: 2.7 VDC to 5.5 VDC

• Programmable Output Power: +20 dBm (100 mW),

+23 dBm (200 mW)

• Programmable I/O Voltage Levels From 1.8 VDC

to 5.5 VDC

• Programmable System Clock Frequency Output

(RF, RF/2, RF/4) from 13.56-MHz or 27.12-MHz

Crystal or Oscillator

1.2

Applications

•

Public Transport or Event Ticketing

•

Passport or Payment (POS) Reader Systems

•

Product Identification or Authentication

1.3

Description

The TRF7964A device is an integrated analog front end and data-framing device for a 13.56-MHz RFID

system. Built-in programming options make the device suitable for a wide range of applications for

proximity and vicinity identification systems.

Built-in user-configurable programming options make the device suitable for a wide range of applications.

The TRF7964A device is configured by selecting the desired protocol in the control registers. Direct

access to all control registers allows fine tuning of various reader parameters as needed.

Documentation, reference designs, EVM, and source code TI MSP430™ MCUs or ARM

available.

PART NUMBER

TRF7964ARHB

An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,

intellectual property matters and other important disclaimers. PRODUCTION DATA.

Sample &

Product

Buy

Folder

Device Information

Tools &

Technical

Software

Documents

• Integrated Voltage Regulator Output for Other

System Components (MCU, Peripherals,

Indicators), 20 mA (Max)

• Programmable Modulation Depth

• Dual Receiver Architecture With RSSI for

Elimination of "Read Holes" and Adjacent Reader

System or Ambient In-Band Noise Detection

• Programmable Power Modes for Ultra Low-Power

System Design (Power Down <1 µA)

• Parallel or SPI Interface (With 127-Byte FIFO)

• Temperature Range: –40°C to 110°C

• 32-Pin QFN Package (5 mm x 5 mm)

•

Medical Equipment or Consumables

•

Access Control, Digital Door Locks

PACKAGE

VQFN (32)

Support &

Community

TRF7964A

SLOS787H – MAY 2012 – REVISED APRIL 2014

MCUs are

BODY SIZE

5 mm x 5 mm

Table of Contents

Need help?

Do you have a question about the TRF7964 and is the answer not in the manual?

Questions and answers

Summary of Contents for Texas Instruments TRF7964

Page 1: Device Overview
Sample & Support & Product Tools & Technical Community Folder Software Documents TRF7964A SLOS787H – MAY 2012 – REVISED APRIL 2014 TRF7964A Multiprotocol Fully Integrated 13.56-MHz RFID Reader and Writer IC 1 Device Overview Features • Completely Integrated Protocol Handling for •...
Page 2: Functional Block Diagram
STATE MACHINE ASK/OOK VSS_RF VOLTAGE SUPPLY REGULATOR SYSTEMS (SUPPLY REGULATORS AND REFERENCE VOLTAGES) VDD_X OSC_IN CRYSTAL OR OSCILLATOR TIMING SYSTEM VSS_D OSC_OUT Figure 1-1. Block Diagram Device Overview Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 3: Table Of Contents
..........Glossary ......Receiver – Analog Section Mechanical Packaging and Orderable ......Receiver – Digital Section ..........Information ........Oscillator Section ......Packaging Information Table of Contents Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 4: Revision History
Deleted previous Section 10, System Design, and moved contents to Section 7.3 through Section 7.5 ................• Removed references to figure numbers in Figure 7-3 Revision History Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 5: Device Characteristics
FeliCa ISO-15693, Device ISO-18000-3 212 kbps, 106 kbps 212 kbps 424 kbps 848 kbps (Mode 1) 424 kbps TRF7964A √ √ √ √ √ √ Device Characteristics Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 6: Terminal Configuration And Functions
32-pin RHB package. VDD_A I/0_7 I/0_6 VDD_RF I/0_5 VDD_PA I/0_4 TX_OUT I/0_3 VSS_PA I/0_2 VSS_RX I/0_1 RX_IN1 I/0_0 Figure 4-1. 32-Pin RHB Package (Top View) Terminal Configuration and Functions Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 7: Terminal Functions
Chip enable input (If EN = 0, then chip is in sleep or power-down mode). Negative supply for internal digital circuits SS_D (1) SUP = Supply, INP = Input, BID = Bidirectional, OUT = Output Terminal Configuration and Functions Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 8 Internally regulated supply (2.7 V to 3.4 V) for digital circuit and external devices (for example, DD_X MCU) Thermal Pad Chip substrate ground Terminal Configuration and Functions Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 9: Specifications
Input voltage - logic low EN, EN2, ASK/OOK, MOD DD_I/O I/O lines, IRQ, SYS_CLK, DATA_CLK, 0.8 x Input voltage threshold, logic high EN, EN2, ASK/OOK, MOD DD_I/O Specifications Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 10: Electrical Characteristics
10 MHz. This clock speed is acceptable only when external capacitive load is less than 30 pF. MISO driver has a typical output resistance of 400 Ω (12-ns time constant when 30-pF load used). Specifications Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links:...
Page 11: Handling Ratings
10 MHz. This clock speed is acceptable only when external capacitive load is less than 30 pF. MISO driver has a typical output resistance of 400 Ω (12-ns time constant when 30-pF load used). Specifications Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links:...
Page 12: Detailed Description
1.8 V to 5.5 V for the MCU I/O interface. The transmitter has selectable output-power levels of 100 mW (+20 dBm) or 200 mW (+23 dBm) equivalent into a 50-Ω load when using a 5-V supply. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 13: System Block Diagram
RF output (to ensure maximum RF power output). The manual mode allows the user to manually configure the regulator settings. 6.3.1 Supply Arrangements Regulator Supply Input: V Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 14 . The "Delta Voltage" in automatic DD_RF DD_A DD_A regulator mode can be increased up to 400 mV (for details, see bits B0 to B2 in register 0x0B). Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 15 (pin 29), the RF output stage negative supply is V (pin 6), and the negative supply for SS_D SS_PA the RF receiver V (pin 7). SS_RX Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 16 . This ensures the highest possible supply DD_RF DD_A DD_X voltage for the RF output stage while maintaining an adequate PSRR (power supply rejection ratio). Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 17: Power Modes
(thus unable to control the EN input). A rising edge applied to the EN2 input (which has an approximately 1-V threshold level) starts the reader supply system and 13.56- MHz oscillator (identical to condition EN = 1). Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 18 Modes 3 and 4 (active modes with the entire RF section active, bit 5 = 1 of register 0x00) are the normal modes used for normal transmit and receive operations. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links:...
Page 19: Receiver - Analog Section
AGC from interfering with the reception of the remaining data packet. In certain situations, this AGC freeze is not optimal, so it can be removed by setting B0 = 1 in the RX special setting register (address 0x0A). Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 20: Receiver - Digital Section
With each new write in this register, the default presets are reloaded in all related registers, so no further adjustments in other registers are needed for proper operation. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 21 The nature of the interrupt request pulse is available in the IRQ and Status register (address 0x0C). The bit coding description of this register is shown in Section 6.13.3.3.1. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 22 RX rate (see register 0x03) ISO14443 B high bit rate 424 kbps ISO14443 B high bit rate 848 kbps Reserved Reserved FeliCa 212 kbps FeliCa 424 kbps Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 23: Received Signal Strength Indicator (Rssi)
RSSI Levels and Oscillator Status register 0x0F. The relationship between the voltage at the RX_IN1 input and the 3-bit code is shown in Figure 6-6. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 24: Oscillator Section
, stray and parasitic PCB capacitance) can be estimated at 4 to 5 pF (typical). As an example, using a crystal with a required load capacitance (C ) of 18 pF, the calculation is shown in Equation Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 25: Transmitter - Analog Section
0x00, the pulse length is equal to the value of the register multiplied by 73.7 ns; therefore, the pulse length can be adjusted between 73.7 ns and 18.8 µs in 73.7-ns increments. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links:...
Page 26: Transmitter - Digital Section
TRF7964A receiver inputs for an external demodulated subcarrier input. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 27 = 0 enables a digital output, B3 = 1 enables an analog output). The design of an external power amplifier requires detailed RF knowledge. There are also readily designed and certified high-power HF reader modules on the market. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 28: Trf7964A Ic Communication Interface
(8 clocks) and then to generate another 8 clocks for reading out the data. The I/O_5 pin goes high during the second 8 clocks. But for normal SPI operations, I/O_5 pin is not used. (5) Slave_Select pin is active low Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 29 Examples of expected communications between an MCU and the TRF7964A are shown in the following sections. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 30 Figure 6-8. Continuous Address Register Write Example Starting with Register 0x00 Using SPI With SS Figure 6-9. Continuous Address Register Read Example Starting with Register 0x00 Using SPI With SS Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links:...
Page 31 Figure 6-10. Single Address Register Write Example of Register 0x00 Using SPI With SS Figure 6-11. Single Address Register Read Example of Register 0x00 Using SPI With SS Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links:...
Page 32 The maximum number of bytes that can be loaded into the FIFO in a single sequence is 127 bytes. NOTE The number of bytes in a frame, transmitted or received, can be greater than 127 bytes. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 33: Parallel Interface Mode
• The StopSmpl condition is also used to terminate the direct mode. Figure 6-14. Parallel Interface Communication With Simple Stop Condition (StopSmpl) Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 34 If the reader detects a receive error, the corresponding error flag is set (framing error, CRC error) in the IRQ Status register, indicating to the MCU that reception was not completed correctly. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links:...
Page 35 Stop condition. When first establishing communications with the TRF7964A, the SOFT_INIT (0x03) and IDLE (0x00) commands should be sent first from the MCU (see Table 6-14). Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 36 No Data Transitions (All High or Low) Ignore Don’t Care MISO SLAVE SELECT Figure 6-17. Procedure for Dummy Read Figure 6-18. Example of Dummy Read Using SPI With SS Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 37 No Data Transitions (All High or Low) No Data Transitions (All High or Low) MISO DON’T CARE SLAVE SELECT Figure 6-20. Continuous Read Operation Using SPI With Slave Select Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 38 In the example in Figure 6-23, this IRQ occurs approximately 1.6 ms after the SS line goes high after the Inventory command is sent out. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 39 The next byte is the DSFID (usually shipped by manufacturer as 0x00), then the UID, shown here up to the next most significant byte, the MFG code (shown as 0x07 (TI silicon)). Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links:...
Page 40 At this point, it is good form to reset the FIFO and then read out the RSSI value of the tag. In this case the transponder is very close to the antenna, so value of 0x7F is recovered. Figure 6-26. Reset FIFO and Read RSSI Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 41: Direct Mode
ISO standard communications, then deviated from the standard after being identified and selected, the ability to go into Direct Mode 0 becomes very useful. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links:...
Page 42 RX Wait Time register (0x08) to 0x07 • Modulator control register (0x09) to 0x21 (or any custom modulation) • RX Special Settings register (0x0A) to 0x20 Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 43 6 of the Chip Status Control register (0x00), making it a 0. Figure 6-28. Entering Direct Mode 0 Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 44 As an example of the receive data bits and framing level according to the ISO14443A standard is shown Figure 6-31 (taken from ISO14443 specification and TRF7964A air interface). Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 46: Special Direct Mode For Improved Mifare™ Compatibility
Test internal RF (RSSI at RX input with TX off) 0x19 Test external RF (RSSI at RX input with TX on) 0x1A Receiver Gain Adjust Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 47 0x00 0x0D Collision position and interrupt mask 0x3E 0x0E Collision position 0x00 0x0F RSSI levels and oscillator status 0x40 (1) Differs from default at POR Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 48 TX if the RX wait time register (0x08) is set. In this case, the receiver is enabled at the end of the wait time following the transmit operation. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links:...
Page 49 Tag communication for the Check RF command to work properly. Table 6-18. Test External RF Peak Level to RSSI Codes RF_IN1 [mV Decimal Code Binary Code Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 50: Register Description
Special Function Register, Preset 0x00 0x14 Adjustable FIFO IRQ Levels Register Status Registers 0x0C IRQ status 0x0D Collision position and interrupt mask register 0x0E Collision position Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 51 Test Register. Preset 0x00 0x1B Test Register. Preset 0x00 FIFO Registers 0x1C FIFO status 0x1D TX length byte 1 0x1E TX length byte 2 0x1F FIFO I/O register Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 52: Detailed Register Description
RFID application RFID: See Table 6-22 for B0:B4 settings based on ISO protocol desired by iso_2 RFID application (1) Only applicable to ISO-14443A and ISO-15693 Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 53 FeliCa 212 kbps FeliCa 424 kbps (1) For ISO14443A/B, when bit rate of TX is different from RX, settings can be done in register 0x02 or 0x03. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 54 TX For 14443A high bit rate, coding and decoding 1 = parity odd except last parity-2rx byte which is even for RX Unused Unused Unused Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 55 Timer Length All bits low = timer disabled (0x00) tm_length2 Timer Length tm_length1 Timer Length Preset 0x00 for all other protocols tm_length0 Timer Length LSB Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 56 604 µs → Reserved 755 µs → ISO15693 high data rate (TI Tag-It HF-I) NoResp0 No response LSB 1812 µs → ISO15693 low data rate (TI Tag-It HF-I) Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 57 Rxw3 9.44 µs → FeliCa Rxw2 66 µs → ISO14443A and B Rxw1 180 µs → Reserved Rxw0 293 µs → ISO15693 (TI Tag-It HF-I) Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 58 Mod Type and % Modulation depth MSB ASK 10% OOK (100%) ASK 7% Modulation depth ASK 8.5% ASK 13% ASK 16% Modulation depth LSB ASK 22% ASK 30% Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 59 The setting of bits B4, B5, B6 and B7 to zero selects bandpass characteristic of 240 kHz to 1.4 MHz. This is appropriate for ISO14443B, FeliCa protocol, and ISO14443A higher bit rates 212 kbps and 424 kbps. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 60 DD_X = 2.8 V, V and V = 2.8 V DD_RF DD_A DD_X = 2.7 V, V and V = 2.7 V DD_RF DD_A DD_X Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 61: Status Registers
B5 and B7 can be changed. During Receive only bit B6 can be changed, but does not trigger the IRQ line immediately. The IRQ signal is set at the end of Transmit and Receive phase. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 62 ISO14443A mainly supported, in the other protocols this register shows the bit position of error. Either frame, SOF/EOF, parity or CRC error. Col3 Col2 Col1 Col0 Bit position of collision LSB Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 63 0 = 7 subcarrier pulses Selects the number of subcarrier pulses that trigger collision error in the col_7_6 1 = 6 subcarrier pulses 14443A - 106 kbps Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 64 Reserved Reserved Reserved Wlh_1 Wlh_1 Wlh_0 IRQ Level FIFO high IRQ level (during Wlh_0 Wll_1 Wll_1 Wll_0 IRQ Level FIFO low IRQ level (during Wll_0 Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 65 Description test_rf_level RF level test test_io1 I/O test Not implemented test_io0 test_dec Decoder test mode clock_su Coder clock 13.56 MHz For faster test of coders Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 66 Bits B0:B6 indicate how many bytes that are in the FIFO to be read out (= N number of bytes, in hex) FIFO bytes fb[1] FIFO bytes fb[0] Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 67 It is taken into account only when broken byte flag is set. Broken byte number of bits bb[0] Broken byte flag B0 = 1, indicates that last byte is not complete 8 bits wide. Detailed Description Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 68: Application Schematic And Layout Considerations
12KB and uses a minimum of 1KB RAM. An MCU capable of running its GPIOs at 13.56 MHz is required for Direct Mode 0 operations. Application Schematic and Layout Considerations Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links:...
Page 69: Trf7964A Reader System Using Spi With Ss Mode
12KB and uses a minimum of 1KB RAM. An MCU capable of running its GPIOs at 13.56 MHz is required for Direct Mode 0 operations. Application Schematic and Layout Considerations Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links:...
Page 70: Layout Considerations
Starting with the 4-Ω source, the process of going from 4 Ω to 50 Ω can be represented on a Smith Chart simulator (available from http://www.fritz.dellsperger.net/). The elements are combined where appropriate (see Figure 7-3). Application Schematic and Layout Considerations Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 71 SLOS787H – MAY 2012 – REVISED APRIL 2014 Figure 7-3. Impedance Matching Circuit This yields the Smith Chart Simulation shown in Figure 7-4. Figure 7-4. Smith Chart Simulation Application Schematic and Layout Considerations Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 72: Reader Antenna Design Guidelines
For HF antenna design considerations using the TRF7964A, see these documents: • Antenna Matching for the TRF7960 RFID Reader (SLOA135) • TRF7960TB HF RFID Reader Module User's Guide (SLOU297) Application Schematic and Layout Considerations Copyright © 2012–2014, Texas Instruments Incorporated Submit Documentation Feedback Product Folder Links: TRF7964A...
Page 73: Device And Documentation Support
All other trademarks are the property of their respective owners. Electrostatic Discharge Caution This integrated circuit can be damaged by ESD. Texas Instruments recommends that all integrated circuits be handled with appropriate precautions. Failure to observe proper handling and installation procedures can cause damage.
Page 74 PACKAGE OPTION ADDENDUM www.ti.com 24-Oct-2015 PACKAGING INFORMATION Orderable Device Status Package Type Package Pins Package Eco Plan Lead/Ball Finish MSL Peak Temp Op Temp (°C) Device Marking Samples Drawing (4/5) TRF7964ARHBR ACTIVE VQFN 3000 Green (RoHS CU NIPDAU Level-2-260C-1 YEAR -40 to 110 &...
Page 75 PACKAGE OPTION ADDENDUM www.ti.com 24-Oct-2015 In no event shall TI's liability arising out of such information exceed the total purchase price of the TI part(s) at issue in this document sold by TI to Customer on an annual basis. Addendum-Page 2...
Page 76: Tape And Reel Information
PACKAGE MATERIALS INFORMATION www.ti.com 6-Apr-2016 TAPE AND REEL INFORMATION *All dimensions are nominal Device Package Package Pins Reel Reel Pin1 Type Drawing Diameter Width (mm) (mm) (mm) (mm) (mm) Quadrant (mm) W1 (mm) TRF7964ARHBR VQFN 3000 330.0 12.4 12.0 TRF7964ARHBT VQFN 180.0 12.4...
Page 77 PACKAGE MATERIALS INFORMATION www.ti.com 6-Apr-2016 *All dimensions are nominal Device Package Type Package Drawing Pins Length (mm) Width (mm) Height (mm) TRF7964ARHBR VQFN 3000 367.0 367.0 35.0 TRF7964ARHBT VQFN 210.0 185.0 35.0 Pack Materials-Page 2...
Page 81: Important Notice
IMPORTANT NOTICE Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, enhancements, improvements and other changes to its semiconductor products and services per JESD46, latest issue, and to discontinue any product or service per JESD48, latest issue.
