Installation instructions
Interface adapter with cable for Ethernet
KERN KUP-04
Type TYKUP-04-A
Version 1.3
2025-01
GB
You can also find the current version of these instructions online at
https://www.kern-sohn.com/shop/de/DOWNLOADS/
Under the heading Operating instructions
KERN & Sohn GmbH
Zie
1
gelei
72336 Balingen-Frommern
Germany
+0049-[0]7433-9933-0
+0049-[0]7433-9933-149
info@kern-sohn.com
TYKUP-04-A-IA-e-2513
Advertisement
Table of Contents
Related Manuals for KERN KUP-04
Summary of Contents for KERN KUP-04
- Page 1 KERN & Sohn GmbH +0049-[0]7433-9933-0 gelei 72336 Balingen-Frommern +0049-[0]7433-9933-149 Germany info@kern-sohn.com Installation instructions Interface adapter with cable for Ethernet KERN KUP-04 Type TYKUP-04-A Version 1.3 2025-01 You can also find the current version of these instructions online at https://www.kern-sohn.com/shop/de/DOWNLOADS/ Under the heading Operating instructions...
-
Page 2: Table Of Contents
Interface adapter with cable for Ethernet Version 1.3 2025-01 Installation instructions Table of contents Scope of delivery ................... 3 General information ..................3 Technical data ....................3 Default settings ....................3 Installation ...................... 4 Installing the interface on the scales ..................4 Connecting the interface ...................... -
Page 3: Scope Of Delivery
• Interface adapter with cable for Ethernet • Installation instructions General information • Weighing data can be transmitted over a network via the Ethernet in- terface. • Only KERN KUP adapters may be connected to the 15-pin Sub-D connection of the balance! Technical data CORE TYKUP-04-A... -
Page 4: Installation
Please note that all three commands, JNEA, JNEK and JNEG, must be entered in strict sequence to finalise the Ethernet interface setting. A detailed description can be found in the "KERN Communications Protocol" manual, available in the download area on our KERN homepage (www.kern-sohn.com) -
Page 5: Via The Configuration Page
5.3.2 Via the configuration page The configuration page can be called up in the address bar under the IP address of the KUP. After entering the user name and password (see section4 ), the default settings can be changed. NOTE ... -
Page 6: Small Breakdown Service
6 Small breakdown service Error Remedy • Ensure that the scales are switched on Connection cannot be established • Ensuring the cable connection • Ensure use of a standard Ethernet cable • Disconnect the scales from the power supply (mains + No communication pos- sible after changing the battery) for a few minutes and restart...
