Sealey EVBT1200 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear safety
instructions footwear
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user's responsibility to check the following:
‰
Check all electrical equipment and appliances to ensure that they are safe before
9
using.
Inspect power supply leads, plugs and all electrical connections for wear and
9
damage.
Ensure that the insulation on all cables and on the appliance is safe before
9
connecting it to the power supply.
DO NOT use worn or damaged cables, plugs or connectors.
8
Ensure that any faulty item is repaired or replaced immediately by a Sealey qualified technician.
9
If the cable or plug is damaged during use, switch off the electricity supply and remove from use.
9
Sealey recommend that an RCD (Residual Current Device) is used with all electrical products.
9
IMPORTANT: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is fitted with the
correct fuse.
DO NOT pull or carry the appliance by the power cable.
8
DO NOT pull the plug from the socket by the cable.
8
WARNING! Any modifications to the machine must not be performed without prior written approval from the manufacturer.
‰
Unauthorized modifications may compromise safety, void warranties, and violate compliance with applicable standards.
1.2. GENERAL SAFETY
WARNING! Ensure all Health and Safety, local authority, and general workshop practice regulations and recommendations are strictly
‰
adhered to when lifting or moving heavy loads. The lifting or movement of heavy loads may be dangerous if not undertaken correctly.
Trained users only.
Familiarise yourself with the application and limitations, as well as the specific potential hazards peculiar to the lift.
9
Maintain the lift in good condition (use an authorised service agent).
9
Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9
Use a qualified person to lubricate/maintain the lift. DO NOT use brake fluid to top up hydraulic unit. Use Sealey hydraulic oil only.
9
To ensure optimal and safe performance, always keep the lift clean and well-maintained. Use the lift only on flat, level, solid ground,
9
preferably concrete, as using it on Tarmacadam when fully laden may cause the wheels to sink.
WARNING! Position the lift in a suitable working area, keeping the space clean, tidy, and free from unrelated materials. Before
‰
transporting a load, always lower it fully and conduct a risk assessment of the intended route. Make sure the floor is swept clean and free
from obstacles to allow safe movement.
Keep the work area clean, uncluttered and ensure there is necessary adequate lighting.
9
Keep children and non essential persons away from the loading/unloading and transporting area.
9
Keep hands and body clear of the edge and underside of the platform when operating the lift.
9
Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
9
DO NOT enter under the platform unless it is mechanically locked.
8
WARNING! Ensure load is placed level and centrally on lift platform and if necessary strap load in place before attempting to lift, lower, or
‰
transport. When raised, check that the platform/load will not foul on the handle and/or your hand when lowering the load.
WARNING! Use the lift with diligence. DO NOT allow lift to knock into anything. Even when unladen, the lift is heavy and if misused, could
‰
cause serious damage and/or personal injury. Continually monitor transportation, lifting and lowering operations.
Take care to ensure you can view the way ahead when moving the lift. Take special care when approaching blind corners.
9
Before lifting check that there are no overhead obstructions.
9
DO NOT use in strong winds.
8
Only use in an area with adequate lighting.
9
Engage the wheel locks before attempting to raise or lower the platform.
9
▲ DANGER! If a heavy load tips or leans, STOP WHAT YOUR ARE DOING. Move quickly to a safe distance. DO NOT try to hold or steady
a heavy load. Failure to follow this instruction may cause serious personal injury or death.
Ensure the lift is fully lowered before attempting to transport a load.
9
Before lowering the platform, ensure there are no obstructions underneath the platform and that all persons are standing clear of the lift.
9
Watch the lift during operation.
© Jack Sealey Limited
1200KG CAPACITY ELECTRIC VEHICLE (EV)
BATTERY HYDRAULIC HIGH LIFTING TABLE
MODEL NO:
DO NOT enter DO NOT put
under if not
hands or feet
mechanically
under platform
locked
Original Language Version
EVBT1200
DO NOT ride Wear
on platform protective
gloves
Indoor use only DO NOT use
No reaching in
Keep hands
clear
Pinch point
on uneven or
inclined floors
EVBT1200 Issue 3 29/05/25
