USER GUIDE
UG532: Skyworks Saturn Evaluation Platform
Features
• Supported products:
- SKY69101
- SKY69002/01
- SKY63103/02/01
All products feature a 64-LGA package with 
•
similar pinouts
• Skyworks ClockBuilder Pro® software for
Windows® makes configuration easy
USB cable and 5 V DC adapter are provided in 
•
the kit
• Flexible power tree allows user to configure power
to the device
• On-board power monitors to evaluate total power
draw of the clock configuration
• On-board ambient temperature sensor
• NetSync™ devices only: On-board OCXO/TCXO
reference to meet holdover requirements
• Access to all clock device GPIO
• 3-wire SPI, 4-wire SPI, and I
header for direct serial communication with 
the device
• Host interface connector header for easy
evaluation of AccuTime™-enabled timing solution
Skyworks Solutions, Inc. • Phone [949] 231-3000 • sales@skyworksinc.com • www.skyworksinc.com
207071A • Skyworks Proprietary Information • Products and Product Information are Subject to Change without Notice
1
2
C all supported via
Description
The Saturn Evaluation Platform is used for evaluating 
a broad family of both NetSync and jitter attenuator
devices.
These supported clock devices are built on sixth-
generation MultiSynth™ technology. All devices
supported by this EVB feature both an on-chip crystal
oscillator (XO) and an on-chip BAW oscillator (BOSC)
that act in tandem as a high-frequency dual reference
to provide the lowest phase noise floor for both sub-
10 kHz (close-in phase noise) and across the rest of the
integration band. NetSync devices come with many
features to support IEEE 1588/PTP applications. They
can be used in conjunction with AccuTime software,
which runs on a separate host processor, to provide a
complete IEEE 1588/PTP timing solution.
The Saturn Evaluation Board (EVB) is designed to be
configured by ClockBuilder Pro software, which offers
a GUI for easy evaluation of the clock device. With
ClockBuilder Pro EVB GUI, all that is needed is a 
USB connection to any Windows PC and an external 
5 V supply.
March 6, 2025
