Millcreek 204 Operator's Manual

Row mulcher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATOR'S MANUAL
204 Row Mulcher
MILLCREEK 204 ROW MULCHER
PUBLICATION DATE: 4/1/13
MILLCREEK PART # 43899
Millcreek Manufacturing Company
525 Reservoir Rd
Honey Brook PA 19344
Phone: 1-800-311-1323 / Fax: 877-640-9009
www.millcreekmfg.com
WARNING: DO NOT assemble, operate, or maintain this equipment without
first reading and understanding the information provided in this manual.
Failure to follow all safety precautions as stated in these manuals may result
in serious personal injury or death.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 204 and is the answer not in the manual?

Questions and answers

Related Manuals for Millcreek 204

Summary of Contents for Millcreek 204

  • Page 1 OPERATOR'S MANUAL 204 Row Mulcher MILLCREEK 204 ROW MULCHER PUBLICATION DATE: 4/1/13 MILLCREEK PART # 43899 Millcreek Manufacturing Company 525 Reservoir Rd Honey Brook PA 19344 Phone: 1-800-311-1323 / Fax: 877-640-9009 www.millcreekmfg.com WARNING: DO NOT assemble, operate, or maintain this equipment without first reading and understanding the information provided in this manual.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION 1: INTRODUCTION..................1-1 Guide to this Manual......................1-1 For Your Safety......................... 1-1 Safety Labels....................... 1-1 Inspection and Warranty Registration ................1-5 Standard/Optional Components................... 1-5 Warranty Registration....................1-5 SECTION 2: ATTACHING THE ROW MULCHER TO THE TRACTOR....2-1 Connecting the Row Mulcher Hitch to the Tractor Drawbar...........2-1 Attaching the Row Mulcher PTO to the Tractor PTO............2-2 Assembling the Safety Tow Chain..................2-2...

  • Page 6: Section 1: Introduction

    SECTION 1: INTRODUCTION Guide to this Manual This manual contains all the information necessary to safely operate and maintain your Millcreek Row Mulcher. Consult the Table of Contents for a detailed list of topics covered. You'll find this manual's step-by-step procedures easy to follow and understand. Should questions arise, please contact your Millcreek dealer before starting any of the procedures in this manual.

  • Page 7: Safety Labels

    Be sure to keep the safety labels clean and readable. If the labels ever become damaged or illegible, contact your Millcreek dealer for replacements.
  • Page 8 Operator's Manual: Millcreek Row Mulchers Safety Labels (continued) Row Mulcher Safety Labels Item# Part# Description 42710 Warning Entanglement 42717 Label Row Mulcher 42730 Millcreek Logo Lg Red 42756 Danger Shield Missing 42759 Cardinal Red Prem Cast Vinyl 42772 Warning Label...
  • Page 9 Operator's Manual: Millcreek Row Mulchers Safety Labels (continued) NO RIDERS 42792 Moving parts can crush or cut. STAY CLEAR of machine while engine is running and/or machine is operating. Keep hands, feet,clothing, and hair awayfrom operating parts. Never adjust, lubricate, or clean machine while engineis running and/or machine is operating.

  • Page 10: Inspection And Warranty Registration

    Following inspection of your new spreader, locate the Millcreek Warranty Card in the literature packet shipped with your spreader. For proper warranty registration, Millcreek requires that you fill out the warranty registration card and return it within 30 days to:...

  • Page 11: Section 2: Attaching The Row Mulcher To The Tractor

    Operator's Manual: Millcreek Row Mulchers SECTION 2: ATTACHING THE ROW MULCHER TO THE TRACTOR Connecting the Row Mulcher Hitch to the Tractor Drawbar WARNING: For safe operation, connect the row mulcher directly to the tractor drawbar; DO NOT connect the row mulcher to a three-point hitch towbar.

  • Page 12: Assembling The Safety Tow Chain

    Operator's Manual: Millcreek Row Mulchers Assembling the Safety Tow Chain NOTE: The safety tow chain may be ordered as an optional component for the row mulcher and must be used if the row mulcher is to be moved any time on a public roadway. Be sure to adhere to all local/state transportation codes for travel on public roadways with this type of equipment.

  • Page 13: Section 3: Operation & Adjustment

    SECTION 3: OPERATION & ADJUSTMENT Understanding Row Mulcher Operation Proper and safe operation of the Millcreek row mulcher requires: (1) being familiar with the row mulcher's operating components and (2) heeding all safety precations as stated in this manual. The Row Mulcher Operating Controls The row mulcher hydraulic models draw power from the tractor hydraulic remotes.
  • Page 14 Operator's Manual: Millcreek Row Mulchers Hydraulics Tractor Hydraulic models draw their power directly from the tractor hydraulic system. For optimal operat- ing performance, the hydraulic oil flow of 5 gallons per minute (GPM) must be maintained. At 3 GPM, the spreader will still operate but at a slower speed.

  • Page 15: Section 4: Maintenance & Adjustment

    PTO is disengaged and the tractor engine is not running. Failure to adhere to this caution could result in serious personal injury. General Maintenance Performing regular maintenance on you Millcreek Row Mulcher will help ensure optimal performance. Please follow these guidelines for maintaining your mulcher: •...

  • Page 16: Wheel/Tire Maintenance

    Operator's Manual: Millcreek Row Mulchers Guidelines for Regular Maintenance (continued) Wheel/Tire Maintenance • Once a month, check the wheel lug bolt torque. The recommended torque is 100 ft. lbs. • Check the tires and maintain proper tire pressure: • 40 PSI for Ag Rib Tires ATTENTION: When storing the row mulcher for a period of time, block up the unit to remove weight from the tires.
  • Page 17 Operator's Manual: Millcreek Row Mulchers Guidelines for Regular Maintenance (continued) Figure 4A - Adjusting the Apron Chain Tension Figure 4B - Cross Conveyor Belt Tension Adjustment...

  • Page 18: Hydraulic System Maintenance

    Operator's Manual: Millcreek Row Mulchers Hydraulic System Maintenance • Periodically check the condition of the hydraulic hoses for flexibility and any signs of rubbing/weakness on the outer surface. Replace the hose(s) as soon as any weakness or cracking is noted.

  • Page 19: Appendix A: Parts Reference

    Parts Ordering Information When ordering replacement parts, please provide the following information to your local Millcreek dealer: * Model and serial number of the unit (located on the front left corner of the mulcher)
  • Page 20 204 Row Mulcher Manual Apron/Floor Assembly...
  • Page 21 204 Row Mulcher Manual Item# Part# Description 34320 5/16 x 1 ¼ Carr Bolt 34367 5/16 Flange Nut Wide 261801 T-Rod Slat 210421 9mm T-Rod Link 271489 Floor Board 271490 Half Board 260112 Floor Hold Down 261743 Apron Idler Shaft...

  • Page 22: Wheel And Hub Assembly

    204 Row Mulcher Manual Wheel And Hub Assembly...
  • Page 23 204 Row Mulcher Manual Item# Part# Description 215109 Complete Hub 34209 Cotter Pin 215132 Wheel and Tire (Includes Items 4, 11) 215106 Wheel 215205 Spindle Nut 215222 Wheel Lug 215204 Hub (Includes Items 13,14) 215203 Inner Bearing Cone 215202 Hub Seal...
  • Page 24 204 Row Mulcher Manual Main Frame/Hitch And Axle...
  • Page 25 204 Row Mulcher Manual Item# Part# Description 271429 Conv House Right 271428 Conv House Left 271417 Conv House Front 271416 Front Brace 271418 Support Angle 271423 Load Baffle 271434 Frame 271407 Axle 271413 Hitch Receiver 271431 Hitch 271443 Conveyor Holder...

  • Page 26: Box Assembly

    204 Row Mulcher Manual Box Assembly...
  • Page 27 204 Row Mulcher Manual Item# Part# Description 271428 Side Sheet RH 271424 Side Sheet LH 271458 Lower Back 271467 Upper Back 271420 Rear Shield 271438 Rear Post RH 271439 Rear Post LH 271418 Support Angle 270175 Top Edging 34274 5/16 x ¾ Carriage Bolt 34118 5/16 x ¾...
  • Page 28 204 Row Mulcher Manual Drive Chain Assembly A-10...
  • Page 29 204 Row Mulcher Manual Item# Part# Description 271470 Spacer 210360 Apron Sprocket 271411 Apron Shaft 220189 5/16 x 2 Key 271410 Apron Bracket 271409 Front Apron Shaft Assembly 240134 012 Hyd Motor 271432 Beater 220161 1” Shaft Collar 271419 Side Shield...

  • Page 30: Conveyor Assembly

    204 Row Mulcher Manual Conveyor Assembly A-12...
  • Page 31 204 Row Mulcher Manual Item# Part# Description 215447 Idler Roller 215338 Drive Roller 215433 Conveyor Belt 271430 Conveyor Wa Conveyor Board 220419 Rubber Seal 271421 Seal Hold Down 271422 Seal Supports 210144 Flange Bearing 210145 12t Sprocket 210229 #50 Chain 54 Link...
  • Page 32 204 Row Mulcher Manual Hydraulics A-14...
  • Page 33 204 Row Mulcher Manual Item# Part# Description 240151 Adapter 8MB-8MJ 240146 Adapter 10MB-8MJ 240245 Adapter 12MB-8MJ 240233 Quick Coupler to Tractor 240296 1/2" Ag Coupler Female 240168 Adapter Straight 8MB-8FJX 240298 10MB-8FPX Adapter 240149 Adapter Tee 8MJ-8MB-8MJ 240286 Tee 8MJ-8MJ-8FJX...
