OPERATOR'S MANUAL
MILLCREEK ROW MULCHER MODELS:
406, 706, 588 (PTO mechanical)
PUBLICATION DATE: 4/15/04, Rev. 1
MILLCREEK PART # 43802
Millcreek Manufacturing Company
525 Reservoir Road
Honey Brook, PA 19344
Phone: 1-800-311-1323
www.millcreekspreaders.com
WARNING: DO NOT assemble, operate, or maintain this equipment without first
reading and understanding the information provided in this manual and the
ADMA Safety Manual for Agricultural Implement Drivelines. Failure to follow
all safety precautions as stated in these manuals may result in serious personal injury
or death.
