ALDI guarantees that our exclusive brand products are developed to our
stringent quality specifications. If you are not entirely satisfied with this
product, please return it to the nearest ALDI store within 60 days from the
date of purchase, for a full refund or replacement, or take advantage of our
after sales support by calling the supplier's Customer Service Hotline.
AUS
Made in China
FERREX
is a registered trademark of ALDI Stores
®
DISTRIBUTED BY:
ALDI STORES
1 SARGENTS ROAD
MINCHINBURY NSW 2770
www.aldi.com.au
AFTER SALES SUPPORT
837775
1300 855 831
AUS
support@scheppach.com.au
MODEL:
WARRANTY
F-HPW1600
11/2024
User Manual
HIGH PRESSURE WASHER
5
YEAR
Original instructions
CAUTION: Read the instructions before using the machine
Contents
Overview .............................................................................. 03
Package contents/part list ..................................................06
Explanation of symbols ....................................................... 07
Introduction .........................................................................08
Layout ...................................................................................09
Scope of delivery ................................................................. 10
Proper use ............................................................................. 11
Safety instructions ................................................................ 11
Technical data ...................................................................... 14
Unpacking ............................................................................ 16
Before commissioning ..........................................................17
Assembly ...............................................................................17
Starting operation ............................................................... 18
Transport.............................................................................. 20
Cleaning and maintenance ................................................. 20
Storage ..................................................................................21
Electrical connection ............................................................21
Repair & ordering spare parts ............................................ 22
Troubleshooting .................................................................. 23
Disposal and recycling ......................................................... 24
Warranty details .................................................................. 25
Repair and refurbished goods or parts notice .................. 26
Overview
1
1
8
2
11
7
3
4
10
6
5
2
12
13
14
16
17
10
15
20
19
21
18
8
22
25
11
23
7
2
1
27
28
3
9
26
24
Advertisement
Table of Contents
Related Manuals for ALDI FERREX F-HPW1600
Summary of Contents for ALDI FERREX F-HPW1600
-
Page 1: Table Of Contents
If you are not entirely satisfied with this Before commissioning ............17 product, please return it to the nearest ALDI store within 60 days from the Assembly ................17 date of purchase, for a full refund or replacement, or take advantage of our after sales support by calling the supplier’s Customer Service Hotline. -
Page 2: Package Contents/Part List
Package contents/part list Electrical high-pressure cleaner Bow-type handle Holder for mains connection cable Holder for accessories Holder Wheel, 2x Holder for high-pressure hose Variable nozzle Lance Turbo nozzle Spray gun High-pressure hose Water connection coupling Washing brush Patio cleaner Spray bottle Gerni adapter Nozzle cleaning needle Screw, 8x... -
Page 3: Explanation Of Symbols
F-HPW1600 Explanation of symbols Explanation of Symbols General note! Observe and understand all safety notes and hints in this manual. Read the operating instructions to reduce the risk of injury. Wear safety goggles. Wear ear protection. The impact of noise can cause damage to hearing. -
Page 4: Introduction
Introduction F-HPW1600 I. Introduction Congratulations on choosing to buy a FERREX product. ® All products brought to you by FERREX are manufactured to the highest ® standards of performance and safety, and as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 5 Year Warranty. We hope you will enjoy using your purchase for many years to come. -
Page 5: Layout
Introduction/Layout F-HPW1600 In addition to the safety notes contained in the present operating instructions and the special regulations of your country, the generally recognised technical rules for the operation of this high pressure washer must be observed. II. Layout (Fig. 1 + 2) Bow-type handle Holder for mains connection cable On/off switch... -
Page 6: Scope Of Delivery
Scope of delivery F-HPW1600 III. Scope of delivery Electrical high-pressure cleaner (1x) Bow-type handle (1x) Holder for mains connection cable (1x) Holder for accessories (1x) Holder (1x) Wheel (2x) Holder for high-pressure hose (1x) Variable nozzle (1x) Lance (1x) Turbo nozzle (1x) Spray gun (1x) -
Page 7: Proper Use
F-HPW1600 Proper use/Safety instructions IV. Proper use The electrical high-pressure cleaner is used: • For cleaning machines, vehicles, buildings, tools, façades, terraces, garden tools, etc. with high-pressure water jets. • With original accessories and spare parts. • In compliance with the manufacturer’s instructions for the object to be cleaned. The product may only be used in the intended manner. - Page 8 Safety instructions F-HPW1600 • High-pressure cleaners shall not be operated by untrained persons. • In the event of a disruption or fault during use, switch the product off immediately and pull out the mains plug. Then read the Troubleshooting chapter. Working with the product m Caution! It will help you avoid accidents and injuries: High-pressure cleaners can be dangerous when used improperly.
-
Page 9: Electrical Safety
F-HPW1600 Safety instructions pair, always contact our service centre. Electrical safety m Caution! To avoid accidents and injuries due to electric shock: • If an extension lead is used, the plug and coupling must be watertight. m Unsuitable extension cables could be dangerous. There is a risk of persons be- ing injured due to electric shock. -
Page 10: Technical Data
Safety instructions/Technical data F-HPW1600 Residual risks The product has been built according to state-of-the-art and the recognised technical safety rules. However, individual residual risks can arise during op- eration. Despite use as intended, specific risk factors cannot be entirely eliminated. Due to the design and layout of the machine, the following risks remain: •... -
Page 11: Noise And Vibration
F-HPW1600 Technical data Max. supply temperature (T in max) 50°C Rated flow rate (Q) 6 l/min Max. flow rate (Qmax) 7 l/min Noise and vibration m WARNING! Noise can have serious effects on your health. If the machine noise exceeds 85 dB, please wear suitable hearing protection for you and persons in the vicinity. -
Page 12: Unpacking
Technical data/Unpacking F-HPW1600 WARNING! The noise emission values and vibration emission value can vary from the specified values during the actual use of the power tool, depending on the type and the manner in which the electric tool is used, and in particu- lar the type of workpiece being processed. -
Page 13: Before Commissioning
F-HPW1600 Before commissioning/Assembly VIII. Before commissioning In accordance with the applicable regulations, the high-pressure cleaner must nev- er be operated in the drinking water network without a system separator. A suitable system separator in accordance with EN 12729 type BA must be used. Water that has flowed through a system separator backflow prevention device is considered non-potable. -
Page 14: Starting Operation
Assembly/Starting operation F-HPW1600 8. To remove the high-pressure hose (21), actuate the locking button (20) on the spray gun (16) and the locking button (5) on the product and pull out the high-pres- sure hose (21). 9. Screw the coupling for the water connection (22) onto the water connection (9). 10. - Page 15 F-HPW1600 Starting operation Spray bottle (25) Use the spray bottle (25) to spray cleaning agents that are permitted for high-pressure cleaners. Gerni Adapter (28) Use the Gerni Adapter (28) to attach Gerni brand accessories. Switching on m WARNING! Pay attention to the recoil force caused by the emergent water jet. Ensure that you have secure footing and hold the spray gun (13) firmly.
-
Page 16: Transport
Starting operation/Transport/Cleaning and maintenance F-HPW1600 Self-priming function You can also use the product independently of the water supply (e.g. rain barrel) thanks to the integrated water suction function. This function can only be used with a suction hose with filter basket (not included in the scope of delivery). m WARNING! The product itself must not be immersed in the open water source. -
Page 17: Storage
F-HPW1600 Cleaning and maintenance/Storage/Electrical connection Cleaning m WARNING! Do not spray the product with water or clean it under running water. There is a danger of electric shock and the product could be damaged. • Keep protective devices, air vents and the motor housing as free of dust and dirt as possible. -
Page 18: Repair & Ordering Spare Parts
Electrical connection/Repair & ordering spare parts F-HPW1600 Damaged electrical connection cable. The insulation on electrical connection cables is often damaged. This may have the following causes: • Pressure points, where connection cables are passed through windows or doors. • Kinks where the connection cable has been improperly fastened or routed. •... -
Page 19: Service Information
F-HPW1600 Repair & ordering spare parts/Troubleshooting Service information With this product, it is necessary to note that the following parts are subject to natural or usage-related wear, or that the following parts are required as consumables. Wearing parts*: Carbon brushes, washing brush * may not be included in the scope of delivery! XVI. -
Page 20: Disposal And Recycling
Disposal and recycling F-HPW1600 XVII. Disposal and recycling The equipment is supplied in packaging to prevent it from being damaged in transit. The raw materials in this packaging can be reused or recycled. The equipment and its accessories are made of various types of material, such as metal and plastic. Never place defective equipment in your household refuse. -
Page 21: Warranty Details
HIGH PRESSURE WASHER Warranty Details REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION The product is guaranteed to be free from defects in workmanship and parts for a period of 60 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion. -
Page 22: Repair And Refurbished Goods Or Parts Notice
Please be assured though, refurbished parts or replacements are only used where they meet ALDI’s stringent quality specifications. If at any time you feel your repair is being handled unsatisfactorily, you may escalate your complaint.
